MIL-STD-883F

METHOD 5010.4

18 June 2004

APPENDIX I

30.7. How is interface with foundries and customers, or both done

Data formats?

Media (e.g., magtapes, modems, DDN/Arpanet)?

Qualification of foundry via test chips?

Are evaluation chips available for customers to assess performance?

30.8. Who tests the chips

At wafer level?

After packaging?

Burn-in?

Life testing?

What automatic test equipment types are used?

30.9. Masks

a. What are the procedures for mask making, inspection, verification, and repair?

b. Is the design transferred to the fab house via an actual mask set or via software?

c. If design transfer is via software, what are the procedures used to verify the mask design?

30.10. Wafer acceptance

a. What wafer inspection/accept-reject criteria are currently used (i.e., how is process control/stability

demonstrated)?

b. Which of the following process control indicators are used?

Kerf test structure measurements? (What structures are in the kerf; how many kerf sites are measured; what data

are taken; tolerances allowed?)

Drop-ins: (What does the drop-in design consist of? How many drop-ins per wafer? Allowed parameter

tolerances?)

Visual test structures?

c. How is high magnification inspection being accomplished? Are voltage stress tests used in lieu of some of the

high mag inspections?

MIL-STD-883F

METHOD 5010.4

18 June 2004

APPENDIX I

30.11. Reliability evaluation

a. How is the reliability of the process proven? It is done via:

Standard evaluation chips (SECs) or reliability evaluation chips?

Test dice with specialized/optimized test structures?

b. If such vehicles do not exist, how is the processing shown to be free of reliability hazards?

c. How can the power buses be guaranteed to be within current density specifications at all times and under all

conditions?

d. For CMOS technology, how is a latch-up free process assured?

e. For bipolar technology, is any radiation hardness characterization done?

30.12. Documentation

a. What are the procedures for certifying and controlling the configuration of software?

b. What are the procedures outlining in detail the process flows for computer-aided

design/manufacture/engineering/test (CAD/M/E/T)?

c. If neither of above is available, when will they be available?

MIL-STD-883F

METHOD 5010.4

18 June 2004

APPENDIX II

WAFER LOT ACCEPTANCE

10. SCOPE

10.1 Scope

. This appendix establishes the requirement for wafer lot acceptance of microcircuit wafers intended for class

level B and level S use. The performance of each wafer shall be evaluated individually and independently of the

performance of other wafers in the lot. This wafer lot acceptance procedure is based on fabrication specification adherence

(in accordance with appendix A of MIL-PRF-38535 and the manufacturer's documented fabrication procedures), physical

testing, and electrical testing of suitable process monitors (PM's).

This method can be used only on a fabrication line that has Appendix A of MIL-PRF-38535 certification or control and has

successfully instituted the required checks. Wafers failing any process specification (with the exception of acceptable

rework instances) shall be removed from further processing.

This method is restricted to a well characterized and baselined process. By characterized, it is meant that a fabrication line

has been adequately described in relation to the capabilities of the process. Baselined refers to the existence of a well

defined process parameter target value with associated variances (based on characterization data) against which the actual

wafer to wafer process data is measured to determine acceptability.

A collection of test structures which can provide the parametric data as well as additional yield indicators is referred to as a

"process monitor" (PM). A statistically valid number of PM's shall be provided on each wafer. The PM may be either

stepped onto every wafer in dedicated drop-in die locations, incorporated into kerf locations, or located on each die, such

that they can be probed at the conclusion of processing up to and including final metallization and passivation (glassivation).

Table I presents a minimum listing of structures which make up a PM. The manufacturer shall see PM parametric limits as

called for by design rules and process rules, or both. Probe pads shall be designed to conform to the 2 x N (NIST)

dimensions.

20. APPLICABLE DOCUMENTS. (This section is not applicable to this document.)

30. APPARATUS. Suitable electrical measurement equipment necessary to determine compliance with applicable

acquisition documents and other apparatus as required in the referenced test methods.

40. PROCEDURE. There are three phases to wafer acceptance:

a. Processing to the manufacturer's fabrication baseline and documented fabrication procedures.

b. Visual/SEM inspection.

c. PM evaluation.

Wafers failing any test (with the exception of acceptable rework instances in accordance with appendix A of

MIL-PRF-38535) shall be removed from the lot.
