MIL-STD-883F METHOD 5012.1 27 July 199 0 4 3.1.3 G- logic and B-logi c part itions . Si mple component s of the l ogic model (logi c pri mitives such as AND, OR, NAND, NOR, XOR, buf fers , or flip- flops ; generall y the…

MIL-STD-883F

METHOD 5012.1

27 July 1990

2. APPARATUS

2.1 Logic simulator

. Implementation of this test procedure requires the use of a facility capable of simulating the behavior

of fault-free digital logic in response to a test vector sequence; this capability is herein referred to as logic simulation.

In order to simulate sequential digital logic, the simulator must support simulation of a minimum of four logic states: zero (0),

one (1), high-impedance (Z), and unknown (X). In order to simulate combinational digital logic only, the simulator must

support simulation of a minimum of two logic states: 0 and 1.

At the start of logic simulation of a logic model of a DUT containing sequential logic, the state of every logic line and

component containing memory shall be X; any other initial condition, including explicit initialization of any line or memory

element to 0 or 1, shall be documented and justified in the fault simulation report.

In order to simulate wired connections or bus structures, the simulator must be capable of resolving signal conflicts

introduced by such structures. Otherwise, modeling workarounds shall be permitted to eliminate such structures from the

logic model (see 3.1.2).

In order to simulate sequential digital logic, the simulator must support event- directed simulation. As a minimum, unit-delay

logic components must be supported.

Simulation of combinational-only logic, or simulation of sequential logic in special cases (such as combinational logic

extracted from a scannable sequential logic model) can be based on nonevent-directed simulation, such as levelized,

zero-delay, or compiled-code methods. The fault simulation report shall describe why the selected method is equivalent to

the more general event-directed method.

2.2 Fault simulator

. In addition to the capability to simulate the fault-free digital logic, the capability is also required to

simulate the effect of single, permanent, stuck-at-zero and stuck-at-one faults on the behavior of the logic; this capability is

herein referred to as fault simulation. Fault simulation shall reflect the limitations of the target ATE (see 3.4.1). It is not

necessary that the fault simulator directly support the requirements of this test procedure in the areas of hard versus

potential detections, fault universe selection, and fault classing. However, the capability must exist, at least indirectly, to

report fault coverage in accordance with this procedure. Where approximations arise (for example, where fault classing

compensates for a different method of fault universe selection) such differences shall be documented in the fault simulation

report, and it shall be shown that the approximations do not increase the fault coverage obtained.

3. PROCEDURE

3.1 Logic model

3.1.1 Level of modeling

. The DUT shall be described in terms of a logic model composed of components and

connections between components. Primary inputs to the logic model are assumed to be outputs of an imaginary component

(representing the ATE's drivers), and primary outputs of the logic model are assumed to be inputs to an imaginary

component (representing the ATE's comparators). Some logic simulators require that the ATE drivers and comparators be

modeled explicitly; however, these components shall not be considered to be part of the logic model of the DUT.

3.1.2 Logic lines and nodes (see 1.1g)

. All fan-out from a node in a logic model is ideal, that is, fan-out branches

associated with a node emanate from a single point driven by a fan-out origin. All fan-in to a node in a logic model is ideal;

that is, multiple fan-in branches in a node drive a single line. Figure 1 shows a node that includes fan-in branches, a fan-out

origin, and fan-out branches. Because fan-in and fan-out generally are not ideal in actual circuit layout, the actual topology

of the circuit should be modeled, if it is known, by appropriately adding single-input noninverting buffers to the logic model.

Modeling workarounds may be used to eliminate fan-in to a node. This may be required if the simulator does not directly

model wired connections or bus structures. Some simulators may permit internal fan-in, but require that bidirectional pins to

a DUT be modeled as separate input and output functions.

MIL-STD-883F

METHOD 5012.1

27 July 1990

3.1.3 G-logic and B-logic partitions. Simple components of the logic model (logic primitives such as AND, OR, NAND,

NOR, XOR, buffers, or flip-flops; generally the indivisible primitives understood by a simulator) are herein referred to as gate

logic (G-logic). Complex components of the logic model (such as RAM, ROM, or PLA primitive components, and behavioral

models - relatively complex functions that are treated as "black boxes" for the purpose of fault simulation) are referred to

herein as block logic (B-logic).

For the purpose of fault simulation, the logic model shall be divided into nonoverlapping logic partitions; however, the entire

logic model may consist of a single logic partition. The logic partitions contain components and their associated lines;

although lines may span partitions, no component is contained in more than one partition. A G-logic partition contains only

G-logic; any other logic partition is a B-logic partition.

A logic partition consisting of G-logic, or B-logic, or G-logic and B-logic that, as a unit, is testable using an established testing

algorithm, with known fault coverage or test effectiveness, may be treated as a single B-logic partition.

3.1.4 Model hierarchy

. The logic model may be hierarchical (that is, consisting of macro building blocks), or flat (that is, a

single level of hierarchy with no macro building blocks). Hierarchy does not impose structures on lines; for example, there is

no implied fan-out origin at a macro input or output. Macros that correspond to physical partitions in a model shall use

additional buffers (or an equivalent method) to enforce adherence to the actual DUT's fan-out.

3.1.5 Fractions of transistors

. The fraction of transistors comprising each G-logic and B-logic partition, with respect to the

total count of transistors in the DUT, shall be determined or closely estimated; the total sum of the transistor fractions shall

equal 1. Where the actual transistor counts are not available, estimates may be made on the basis of gate counts or

microcircuit area; the assumptions and calculations supporting such estimates shall be documented in the fault simulation

report. The transistor fractions shall be used in order to weight the fault coverage measured for each individual logic

partition (see 3.5).

3.2 Fault model

3.2.1 G-logic

. The fault model for G-logic shall be permanent stuck-at-zero and stuck-at-one faults on logic lines. Only

single stuck-at faults are considered in calculating fault coverage.

3.2.2 B-logic

. No explicit fault model is assumed for B-logic components. However, an established test algorithm shall

be applied to each B-logic component or logic partition. If a B-logic partition contains logic lines or G-logic components, or

both, justification shall be provided in the fault simulation report as to how the established test algorithm that is applied to the

B-logic partition detects faults associated with the logic lines and G-logic components.

3.2.2.1 Built-in self-test

. A special case of B-logic is a partition that includes a linear-feedback shift register (LFSR) that

performs signature analysis for compression of output error data. Table I lists penalty values for different LFSR degrees. If

the LFSR implements a primitive GF(2) polynomial of degree "k", where there is at least one flip-flop stage between inputs to

a multiple-input LFSR, then the following procedure shall be used in order to determine a lower bound on the established

fault coverage of the logic partition:

Step 1: Excluding the LFSR, but including any stimulus generation logic considered to be part of the logic partition,

determine the fault coverage of the logic partition by fault simulation without signature analysis; denote this fault

coverage by C.

Step 2: Reference table I. For a given degree "k" obtain the penalty value "p". The established fault coverage of the

logic partition using a LFSR of degree "k" shall be reported as (1-p)C. That is, a penalty of (100p) percent is incurred

in assessing the effectiveness of signature analysis if the actual effectiveness is not determined.

MIL-STD-883F

METHOD 5012.1

27 July 1990

3.3 Fault universe selection and fault equivalence classing

. Fault coverage shall be reported in terms of equivalence

classes of the detectable faults. This section describes the selection of the initial fault universe, the partitioning or collapsing

of the initial fault universe into fault equivalence classes, and the removal of undetectable faults in order to form the

detectable fault universe. These three stages constitute the fault simulation reporting requirements; however, it is generally

more efficient to obtain the set of faults that represent the fault equivalence classes directly without explicitly generating the

initial fault universe.

3.3.1 Initial fault universe

. The initial fault universe shall consist of single, permanent, stuck-at-zero and stuck-at-one

faults on every logic line (not simply on every logic node) in the G-logic partitions of the logic model. A bus, which is a node

with multiple driving lines, shall be considered, for the purpose of fault universe generation, to be a multiple-input,

single-output logic gate. The initial fault universe shall include stuck-at-zero and stuck-at-one faults on each fan-in and

fan-out branch and the fan-out origin of the bus (see figure 1).

The fault universe does not explicitly contain any faults within B-logic partitions. However, all faults associated with inputs

and outputs of B-logic components either are contained in a G-logic partition or shall be shown to be considered by

established test algorithms that are applied to the B-logic partitions.

No faults shall be added or removed by considering or not considering logic model hierarchy. No extra faults shall be

associated with any primary input or output line, macro input or output line, or logic line that spans logic partitions where the

logic partitions do not correspond to a physical boundary. No more than one stuck-at-zero and one stuck-at-one fault per

logic line shall be contained in the initial fault universe.

3.3.2 Fault equivalence classes

. The initial fault universe shall be partitioned or collapsed into fault equivalence classes

for reporting purposes. The fault equivalence classes shall be chosen such that all faults in a fault equivalence class cause

apparently identical erroneous behavior with respect to the observable outputs of the logic model. One fault from each fault

equivalence class shall be selected to represent the fault class for reporting purposes; these faults shall be called the

representative faults.

For the purpose of implementing this test procedure it is sufficient to apply simple rules to identify structurally-dependent

equivalence classes. An acceptable method for selecting the representative faults for the initial fault universe consists of

listing all single, permanent, stuck-at faults as specified in table II. Any other fault equivalencing procedure used shall be

documented in the fault simulation report. If a bus node exhibits wired-AND or wired-OR behavior in the applicable circuit

technology, then faults associated with that bus shall be collapsed in accordance with the AND or OR fault equivalencing

rules, respectively. Otherwise, no collapsing of faults associated with a bus shall be performed.

3.3.3 Detectable fault universe

. Fault coverage shall be based on the detectable fault universe. Undetectable faults shall

be permitted to be dropped from the set of representative faults; the remaining set of representative faults comprises the

detectable fault universe. In order for a fault to be declared as undetectable, documentation shall be provided in the fault

simulation report as to why there does not exist any test vector sequence capable of guaranteeing that the fault will cause

an error at an observable primary output (see 1.1m.). Any fault not documented in the fault simulation report as being

undetectable shall be considered detectable for the purpose of calculating fault coverage.
