MIL-STD-883F

METHOD 1014.11

18 June 2004

2.2 Test condition B, radioisotope fine leak

. Apparatus for this test shall consist of:

a. Radioactive tracer gas activation console.

b. Counting equipment consisting of a scintillation crystal, photomultiplier tube, preamplifier, ratemeter, and

krypton-85 reference standards. The counting station shall be of sufficient sensitivity to determine through the

device wall the radiation level of any krypton-85 tracer gas present within the device. The counting station shall

have a minimum sensitivity corresponding to a leak rate of 10

-9

atm cc/s of krypton-85 and shall be calibrated at

least once every working shift using krypton-85 reference standards and following the equipment manufacturer's

instruction.

c. A tracer gas consisting of a mixture of krypton-85 and dry nitrogen. The concentration of krypton-85 in dry

nitrogen shall be no less than 100 microcuries per atmospheric cubic centimeter. This value shall be determined

at least once each 30 days and recorded in accordance with the calibration requirements of this standard (see

4.5.1 of MIL-STD-883).

2.3 Test condition C, perfluorocarbon gross leak

. Apparatus for this test shall consist of:

a. A vacuum/pressure chamber for the evacuation and subsequent pressure bombing of devices up to 105 psia up to

23.5 hours.

b. A suitable observation container with provisions to maintain the indicator fluid at a temperature of 125°C and a

filtration system capable of removing particles greater than 1 micrometer in size from the fluid (condition C1 only).

c. A magnifier with a magnification in the range between 1.5X to 30X for observation of bubbles emanating from

devices when immersed in the indicator fluid (condition C1 only).

d. Sources of type I detector fluids, and type II indicator fluids as specified in table I.

e. A lighting source capable of producing at least 15 thousand foot candles in air at a distance equal to that which

the most distant device in the bath will be from the source. The lighting source shall not require calibration but the

light level at the point of observation (i.e., where the device under test is located during observation for bubbles),

shall be verified (condition C1 only).

f. Suitable calibrated instruments to indicate that test temperatures, pressures, and times are as specified.

g. Suitable fixtures to hold the device(s) in the indicator fluid (condition C1 only).

h. A perfluorocarbon vapor detection system capable of detecting vapor quantities equivalent to 0.167 or 1/6

microliter of type I fluid (condition C3 only).

i. The vapor detector used for condition C3 shall be calibrated at least once each working shift using a type I fluid

calibration source, and following the manufacturer's instructions.

2.4 Test condition D, penetrant dye gross leak

. The following apparatus shall be used for this test:

a. Ultraviolet light source with peak radiation at approximately the frequency causing maximum reflection of the dye

(3650 Å for Zyglo; 4935 Å for Fluorescein; 5560 Å for Rhodamine B, etc.).

b. Pressure chamber capable of maintaining 105 psia.

c. Solution of fluorescent dye (such as Rhodamine B, Fluorescein, Dye-check, Zyglo, FL-50, or equivalent) mixed in

accordance with the manufacturer's specification.

d. A magnifier with a magnification in the range between 1.5X to 30X for dye observation.

MIL-STD-883F

METHOD 1014.11

18 June 2004

2.5 Test condition E, weight gain gross leak

. Apparatus for this test shall consist of:

a. A vacuum/pressure chamber for the evacuation and subsequent pressure bombing of devices up to 90 psia up to

10 hours.

b. An analytical balance capable of weighing the devices accurately to 0.1 milligram.

c. A source of type III detector fluid as specified in table I.

d. A filtration system capable of removing particles greater than 1 micrometer in size from the perfluorocarbon fluid.

e. Suitable calibrated instruments to measure test pressures and times.

TABLE I. Physical property requirements of perfluorocarbon fluids

. 1/

Property Type I Type II Type III ASTM

test method

Boiling point (°C)

50-95 140-200 50-110 D-1120

Surface tension (Dynes/cm)

at 25°C

< 20

D-971

D-1331

Density at 25°C (gm/ml)

> 1.6 > 1.6 > 1.6 D-941

Density at 125°C (gm/ml)

> 1.5

D-941

Dielectric strength

(volts/mil)

> 300 > 300 > 300 877

Residue (:gm/gm) < 50 < 50 < 50 D-2109

Appearance Clear colorless NA

/ Perfluorocarbons contain no chlorine or hydrogen.

2.6 Test conditions C

and C

- optical gross/fine leak. This test condition applies to individual devices and devices

mounted on printed circuit boards or higher level assemblies. Apparatus required shall consist of suitable pressure or

vacuum/pressure chamber with an integral interferometry leak detector. The optical leak detector shall be preset and

properly calibrated for an equivalent standard leak rate sensitivity sufficient to read measured Helium leak rates of 10

-5

atm-

cc/sec and greater for gross leak detection (C

), and 5 X 10

-9

atm-cc/sec and greater for fine leak detection (C

Note: Prior to performing optical gross/fine leak testing, the test designer will need to know what limits the DUT has.

Extreme pressure/vacuum may cause damage to some devices. The test designer will need to design the test

conditions around such limitations.

2.6.1 Apparatus initial setup

. The optical gross/fine leak test equipment requires system parameter normalization as

determined uniquely for each particular device under test. To accomplish this an initial device package set up and

calibration shall be performed using two or more package specimens with a known hermeticity of <5X10

-8

cc-atm/sec and a

known internal free volume. These device packages shall be of the same type and geometry as the packages to be tested.

These known good packages are tested in the system to calibrate the device stiffness values used in determining the device

leak sensitivity (see 3.6.2).

2.6.2 Process monitoring

. A group of “system check devices” with a known hermeticity of <5X10

-8

cc-atm/sec, maintained

by the test facility, shall be used for system operation verification at the beginning and end of each work shift. This check of

the system’s operation shall be completed using a minimum of two package specimens from the “system check devices”.

MIL-STD-883F

METHOD 1014.11

18 June 2004

3. PROCEDURE

. Fine and gross leak tests shall be conducted in accordance with the requirements and procedures of

the specified test condition. Testing order shall be fine leak (condition A or B or C

) followed by gross leak (condition C

, C

, D, or E) except when C

is used together with A, B, or C

. When specified (see 4), measurements after test shall be

conducted following the leak test procedures. Where bomb pressure specified exceeds the microcircuit package capability,

alternate pressure, exposure time, and dwell time conditions may be used provided they satisfy the leak rate, pressure, time

relationships which apply, and provided a minimum of 30 psia (2 atmospheres absolute) bomb pressure is applied in any

case or for condition C

, a minimum of 10 psi differential test pressure is applied in any case. When test condition A

used, gross leak testing is not required. However A

shall not be used in lieu of the required seal testing of lidded packages.

When batch testing (more than one device in the leak detector at one time) is used in performing test condition A or B and a

reject condition occurs it shall be noted as a batch failure. Each device may then be tested individually one time for

acceptance if all devices in the batch are retested within one hour after removal from the tracer gas pressurization chamber.

For condition B only, devices may be batch retested for acceptance providing all retesting is completed within one hour after

removal from the tracer gas pressurization chamber. For condition C

only, devices that are batch tested, and indicate a

reject condition, may be retested individually one time using the procedure of 3.3.3.1 herein, except that repressurization is

not required if the devices are immersed in detector fluid within 20 seconds after completion of the first test, and they remain

in the bath until retest. For conditions C

and C

only, the package must meet lid stiffness requirements defined in 3.6.1.

This includes devices that are conformal coated such as circuit board assemblies.

3.1 Test condition A

, A

, or A

tracer gas (He) fine leak. Test condition A

is a "fixed" method with specified conditions in

accordance with table II that will ensure the test sensitivity necessary to detect the required measured leak rate (R

) . Test

condition A

is a "flexible" method that allows the variance of test conditions in accordance with the formula of 3.1.1.2 to

detect the specified equivalent standard leak rate (L) at a predetermined leak rate (R

). Test condition A

is a method that

will detect the required measured leak rate (R

) of an unsealed package.

3.1.1 Test conditions A

and A

, procedure applicable to "fixed" and "flexible" methods. The completed device(s), shall be

placed in a sealed chamber which is then pressurized with a tracer gas of 100 +0, -5 percent helium for the required time

and pressure. The pressure shall then be relieved and each specimen transferred to another chamber or chambers which

are connected to the evacuating system and a mass-spectrometer-type leak detector. When the chamber(s) is evacuated,

any tracer gas which was previously forced into the specimen will thus be drawn out and indicated by the leak detector as a

measured leak rate (R

). (The number of devices removed from pressurization for leak testing shall be limited such that the

test of the last device can be completed within 60 minutes for test condition A

or within the chosen value of dwell time t

for

test condition A

Note: Flexible Method shall be used unless otherwise specified in the acquisition document, purchase order, or contract.

3.1.1.1 Test condition A

, fixed method. The devices(s) shall be tested using the appropriate conditions specified in table

II for the internal cavity volume of the package under test. The time t

is the time under pressure and time t

is the maximum

time allowed after release of pressure before the device shall be read. The fixed method shall not be used if the maximum

equivalent standard leak rate limit given in the acquisition document is less than the limits specified herein for the flexible

method.
