4 Setting up and commissioning User manual SIPLACE X-Series 4.3 Setting up the machine From softwa re version 710.0 Edition 12/2016 226 4.3.3 Fitting att ached p art s The machine is delivered with th e monitor , operati…
User manual SIPLACE X-Series 4 Setting up and commissioning
From software version 710.0 Edition 12/2016 4.3 Setting up the machine
225
4
4
4
4
WARNING
Risk of damage due to excessive fork spacing!
Increased fork spacing, which means that the machine is raised at points outside its con-
tact surface, can lead to deformation of the machine frame and cause damage to cables
and lines.
The forks may only be opened to a degree which ensures that they are still within
the contact area of the machine underside (see fig. 4.1 - 3
, page 211).
WARNING
Risk of damage due to one-sided loading!
One-sided loading of the machine feet e.g. from tilting the machine, can lead to deforma-
tion of the machine feet.
Make sure that the forks are evenly loaded when you lift the machine.
Use a firm support layer between the forks and the machine.
Enlist the help of a second person to watch while you lift the machine and make sure
that the machine does not tip over to one side.
WARNING
Risk of damage!
The thread for the machine feet in the machine frame could be damaged by being
dragged along the floor or from impact.
When you are transporting the machine, make sure that all the feet are clear of the
floor.
WARNING
Risk of damaging the exhaust air duct for the vacuum pump!
Vacuum pumps can be fitted in placement area 1. The exhaust air duct is fitted under the
machine base. This exhaust air duct could be damaged during transportation with the
fork-lift.
Dismantle the exhaust air duct before you transport the machine with the fork-lift.
4 Setting up and commissioning User manual SIPLACE X-Series
4.3 Setting up the machine From software version 710.0 Edition 12/2016
226
4.3.3 Fitting attached parts
The machine is delivered with the monitor, operating panel, keyboard and indicator lamp disman-
tled. To fit these components, proceed as follows:
– To fit the indicator lamps see section 4.3.3.2
, page 226
– To fit the operating panel see section 4.3.4, page 227
– To fit the monitors see section 4.3.3.4, page 226
– Hook up the keyboard fixture and connect the keyboard.
4.3.3.1 Checking and setting the protective cover switch
Check the function of the protective cover switch (see 2.5.1 on page 77).
Adjust the protective cover switch if necessary (see service manual).
4.3.3.2 Fitting the indicator lamp
Insert the indicator lamp into the hole until the lamp tube projects sufficiently into the terminal
beneath.
Connect the cable for the indicator lamps to the connector. The cable with connector is lo-
cated in the tube.
Tighten the two screws on the terminal so that the indicator lamp is clamped into place.
4.3.3.3 Fitting the operating panel
Use the 4 fastening screws to fix the operating panel to the monitor mount and then connect
the cable.
Check the cable connections.
4.3.3.4 Fixing the monitors
Use the 4 fastening screws to fix the monitor to the monitor mount and then connect the cable.
Check the cable connections.
User manual SIPLACE X-Series 4 Setting up and commissioning
From software version 710.0 Edition 12/2016 4.3 Setting up the machine
227
4.3.4 PCB conveyor height on the machine
The machine can be set to the following PCB conveyor heights:
900 mm ± 15 mm 4
930 mm ± 15 mm (standard height) 4
950 mm ± 15 mm (SMEMA height) 4
4
4.3.5 Tools and equipment
You will need the following tools and equipment to adjust the height of your machine:
You will need the following tools and equipment to adjust the height of your machine:
– Fork wrench SW 36, Item no. 00096286-01
– Wrench of width 36 for the setting screw M24x2x120 used to adjust the height of the machine
feet.
– Hook wrench 135 - 145 for adjusting the middle machine feet,
Item no. 00376519-xx
– Single head wrench SW 65, Item no. 00353827-0, width 65 for the hexagonal lock nut M24
on the middle machine foot
– Allen wrench, size 10, Item no. 00373926-01 for hexagon socket-head screws M12x80 for
fastening the spacers on the middle machine feet
– Allen wrench, size 19, Item no. 00373928-01 for hexagon socket-head screw M24x90 for
temporary fixture of clamping pieces for the four outer machine feet
– Torque wrench with hexagonal pin, size 19, tightening torque 130 Nm
for final fastening of four outer machine feet
– Machine spirit level: accuracy 0.02 mm/m
– Fork lift truck (specification see 4.1.4.3 on page 208).
– Air cushion transport system: SIPLACE HSxx, Item No. 00119002-S01 (optional)
PLEASE NOTE
The PCB conveyor height is the distance between the top edge of the PCB conveyor belt
and the bottom edge of the machine feet.
