User manual SIPLACE X-Series 6 Station extensions From software version 710.0 Edition 12/2016 6.10 3D coplanarity laser module 379 6.10 3D coplanarity laser module Item no. 519807-xx 3-D coplan, X2 S / X3 S / X4 S The 3D…
6 Station extensions User manual SIPLACE X-Series
6.9 SIPLACE High-Force Head From software version 710.0 Edition 12/2016
378
6.9 SIPLACE High-Force Head
Item no. 00119736-xx High-Force Head
This item number only applies when ordering a new placement machine with a high force
head instead of a standard TwinStar. 6
6.9.1 Description
The SIPLACE high force head is an advanced development of the standard TwinStar. It can pro-
cess the same component range and also offers the possibility of achieving set-down forces up to
30 N. The SIPLACE high force head can use all the same nozzles and grippers as the standard
TwinStar.
6.9.2 Technical data
6
Al other technical data are identical for the TwinStar and high force head (see section 3.5.7.2,
page 155
).
Programmable set-down force 2.0 N to 10 N ± 10 %
greater than 10 N up to 30 N ± 15 %
User manual SIPLACE X-Series 6 Station extensions
From software version 710.0 Edition 12/2016 6.10 3D coplanarity laser module
379
6.10 3D coplanarity laser module
Item no. 519807-xx 3-D coplan, X2 S / X3 S / X4 S
The 3D coplanarity laser module works with a line of laser light. This enables you to generate and
analyze the height profile of a two-dimensional arrangement of component leads e.g. BGA, QFP
etc. This analysis provides data about the coplanarity (contact plane) and collinearity (contact line
straightness) of component leads or balls.
For more details, refer to the "Assembly Instructions 3D Sensor", German+English [Item. no.
00197084-xx]
6.10.1 Safety instructions for coplanarity module sensor
The sensor works with a semiconductor laser which has a wave length of 670 nm (visible/red).
The maximum optical output is 60 mW.
The sensor is classified as laser class 3B.
– When using the sensor, always observe the IEC 60825-1:2014 regulations about "Safety of
Laser Equipment" and the accident prevention guidelines for "Laser Radiation" (DGUV Reg-
ulation 11), applicable in Germany.
– Also observe the accident prevention regulations of your own country!
The following warning labels are attached to the front and back of the sensor housing:
6
Fig. 6.10 - 1 Laser class 3B classification for the sensor
6 Station extensions User manual SIPLACE X-Series
6.10 3D coplanarity laser module From software version 710.0 Edition 12/2016
380
6
6
6
6
WARNING
Laser radiation is hazardous for the eyes
The accessible laser radiation is dangerous for your eyes and, in certain circumstances,
also poses a hazard to skin.
The radiation issued by class 3B lasers (medium output strength) is dangerous during
direct contact with your eyes and also when it is reflected by a mirror. At higher output
levels, this laser could also damage skin.
Avoid looking directly into the laser beam.
The 3D coplanarity module is installed and secured in the machine in a manner
which, if used correctly (short radiation periods), fulfills the laser class 2 limits for ac-
cessible radiation and is therefore non-hazardous for your eyes.
WARNING
Encapsulated class 2 laser equipment
When in a fixed installation, the placement machine is classified as a so-called "encap-
sulated" class 2 laser device
The 3D sensor is integrated into the emergency OFF circuit.
Never disable the emergency OFF circuit!
The 3D sensor may only be operated inside the placement machine!
WARNING
Repairs and service
For repair and service work, always send the sensors to ASM Assembly Systems
GmbH & Co. KG.
