1.5 Operator levels From software version 710.0 Edition 12/2016
38
1.5 Operator levels
Certain functions or menus may only be executed or accessed by specially trained personnel. A
differentiation is made between the following operator levels:
– Production
– Advanced production
– Service (customer)
– Service (SIPLACE)
The operator levels "Advanced production" and "Service (customer)" can be password protected.
The operator level "Service (SIPLACE)" is already password protected.
Production 1
This operator level includes those people who have been trained to operate the machine. These
people are authorized to use any functions associated with operating the machine and may call
up any menus needed to use the machine.
Advanced production 1
People with this operator level have completed special training and are authorized to perform
setup tasks e.g. creating setup configurations or determining Vision parameters etc.
Service (customer) 1
People with this operator level are specially trained technicians at the customer end, who can, for
example, define machine option settings.
Service (SIPLACE) 1
People with this operator level are trained to perform service work, such as the conversion and
retrofitting of machines.
User manual SIPLACE X-Series 1 Introduction
From software version 710.0 Edition 12/2016 1.6 Important notes on the user manual
39
1.6 Important notes on the user manual
1.6.1 Contents and filing of the user manual
This user manual contains basic information that must be observed when setting up, operating
and maintaining the machine. The service engineers, qualified staff, operators and users plus sys-
tem owner must therefore read it before commencing installation and commissioning. The instruc-
tions must be kept permanently accessible where the machine is used.
In addition, the user must ensure that the employees have fully understood the contents of the
user manual.
1.6.2 Danger notes
1
1.6.3 Manufacturer's/supplier's liability
We hereby confirm that the contents of this user manual are of a descriptive and explanatory na-
ture only and do not contain any contractual conditions or guaranties. The liability and obligations
assumed by ASM Assembly Systems GmbH&Co.KG can be found exclusively in the relevant
contract agreement concerning the supply of the machine described in this manual. This applies
in particular to all statements regarding performance or service life and the agreed liability for
faults or defects. The provisions of the contract regarding the liability for faults or defect are neither
extended nor restricted by any statements in this user manual.
WARNING
Read the user manual!
Tasks may only be performed by qualified staff who have completed the relevant
training.
Only perform tasks on the machine if you have precise knowledge of the relevant
section in the user manual.
Observe all warnings, caution notes and hazard notes.
Please also read chapter 2 of this user manual through carefully.
1 Introduction User manual SIPLACE X-Series
1.6 Important notes on the user manual From software version 710.0 Edition 12/2016
40
1.6.4 Revision table
1
1.6.5 Further information about and contents of the documentation package
1.6.5.1 How to get information
If you have any further questions concerning this manual or if you would like additional information
on a particular topic, please get in touch with your local SIPLACE dealer or contact us directly at:
ASM Assembly Systems GmbH&Co.KG
Rupert-Mayer-Str. 44
81379 Munich 1
Edition Amendments
03/2013 First edition
10/2013 Station software SC 707.0
SIPLACE X4 S micron / X4i S micron
SIPLACE X2 S
SIPLACE SpeedStar - variant M (C&P 20 M)
Component camera, type 41
04/2014 Station software SC 707.1
SIPLACE SpeedStar - variant P (C&P 20 P) with nozzle changer
Waffle pack changer (WPC5/WPC6)
SIPLACE JTF-S/JTF-M
03015 placement
SIPLACE X4 S micron / X4i S micron with SIPLACE MultiStar (CPP)
New options
10/2014 New sales numbers for machine types
SIPLACE SmartFeeder 8 mm X
Universal nozzle changer for SIPLACE CPx
05/2015 New power supply
Status display and its meaning for signaling lamps and horn.
Overview of maintenance work - chapter 7
05/2016 Station software SC 709.01
Laser class 2 and warning labels
SIPLACE MultiStar (CPP) with component camera, type 45
Formal adjustments, minor corrections and supplements
12/2016 Station software SC 710.0
Formal adjustments, minor corrections and supplements
SIPLACE SmartFeeder 24 mm to 104 mm X
SIPLACE PowerConnector X
