RV-2 PRODUCT SPECIFICATIONS
5
7. Option
7-1. Optional Software
Item
Specification
Main system
• Character-recognition (OCR/OCV)
• Code reader (1D, 2D)
• Communication license
* Required when connecting to a data server
Peripherals
* It is your responsibility to
prepare a PC.
• Remote judgment (CCC mode)
• Remote judgment (OLR mode)
• Repair station
• SPC
• Offline editor
• Quality Traceability
Server system
* It is your responsibility to
prepare a PC.
• Data server
* Required when connecting an optional peripheral software.
• Data share (Release plan: Please contact us for details.)
7-1-1. Optional Main System Software
Character-recognition (OCR/OCV)
This OCR (Optical Character Recognition) is a support tool that recognizes an alphanumeric character
string written on the board or part and converts it into the character data that can be handled on the
computer so as to make the judgment.
Resistance constants, IC characters, etc., can be recognized.
This OCV (Optical Character Verification) is a support tool that recognizes characters using the pattern
matching.
RV-2 PRODUCT SPECIFICATIONS
6
Code reader (1D, 2D)
The cameras on the inspection machine can recognize 1D (barcodes) and 2D (2D codes).
◆ Recognizable size
• 1D (barcode) ：Maximum 50 mm
• 2D (2-dimensional code) ：Maximum 25 mm x 25 mm * Minimum cell size: 0.1 mm square
◆ Recognizable code list
• 1D (barcode)
2/5 Industrial, 2/5 Interleaved, Codabar (NW-7), Code 128, Code 39, Code 93,
EAN-13 (JAN-13), EAN-8 (JAN-8), MSI, Pharma Code, GS1 Databar (RSS), UPC-A, UPC-E
• 2D (2-dimensional code)
Data Matrix ECC 200, QR Code, Micro QR Code, PDF417, Aztec
SPI feedback
I add up a solder test result in SPI (examination of solder printing machine) and collect the statistics and
can notify you of movement instructions and print position revision quantity for a press based on the result.
RV-2 PRODUCT SPECIFICATIONS
7
7-1-2. Optional Peripheral Software
This is a suite of software applications that provide various functions to support the operation of the RV-2-3D.
By connecting the TOPSS server with the devices and the terminal with the applicable function via a network,
the entire
RV-2-3D operations within the factory can be managed together.
Remote judgment
This function enables the operator to identify the parts that are judged by RV-2-3D and determined as NG
on any terminal other than the machine.
Remove judgment can be performed in the following two modes that share the same judgment screen and
operability.
• CCC mode
Multiple RV-2-3D units can be connected to a single terminal to perform judgment.
RV-2-3D
RV-2-3D
RV-2-3D
TOPSS server
NG information
Judgment
result
TOPSS server
SPC
Offline editor
Remote
judgment
Repair station
Quality
Traceability
RV-2-3D
