Introduction
Staff Qualifications and Training 1.4.5 Release History
18 Maintenance Manual SIPLACE X Series
1.4.5
1.4.5 Release History
Release History
1.4.6
1.4.6 SIPLACE on the World Wide Web (WWW)
SIPLACE on the World Wide Web (WWW)
Log into our SIPLACE
®
homepage at http://www.siplace.com.
► You can choose between the German and English versions.
The different sections contain information about our products, services and contact persons.
In addition, registered customers can also access the
SIPLACE User Group
. Here you can call up spe
-
cial information about our placement systems e.g.
▪ Technical documentation,
▪ Technical information,
▪ Spare parts lists etc.
Registration for the user group is very simple:
► Click on the Register link.
► Fill in the registration form and send it off to us.
Soon afterwards, you will receive your access authorization with USER ID and password.
1.5
1.5 Staff Qualifications and Training
Staff Qualifications and Training
Qualified or adequately trained personnel means that these people are familiar with the setting up, op
-
eration and maintenance of automatic placement systems and add-on devices and are suitably qualified,
e.g.:
▪ Have been trained, instructed or authorized to switch on and off, isolate, earth and identify electrical
circuits and system components in accordance with normal safety standards.
▪ Have been trained or instructed in the upkeep and use of appropriate safety equipment in accord
-
ance with normal safety standards.
▪ Have received first aid training.
Document
SIPLACE X Series
Maintenance Manual
Release Changes
06/2010 Revision
02/2011 Revision
05/2014 Revision
▪ Introduction of a new minor/major concept
▪ Head topics separated into individual manuals
▪ Greasing the Tape Cutter
▪ Cleaning the Tape Cutter
▪ Checking the Safety Features
▪ Cleaning the IC and FC Cameras
▪ Greasing the Locator Bearing on the Component Trolley for X Feeders
▪ Greasing the Centering Strip on the Component Trolley for X Feeders
▪ Cleaning and Preserving the Conveyor
▪ Conveyor Maintenance
▪ Checking/Cleaning the Filters (Cooling Air Filter, Protective Covers, Machine
Rucksack, Axis Unit, Computer Unit)
Introduction
1.4.6 SIPLACE on the World Wide Web (WWW) Abbreviations
Maintenance Manual SIPLACE X Series 19
1.6
1.6 Abbreviations
Abbreviations
Abbreviations Description
PA Placement area
CO Component
COT Changeover table
COT-i Changeover table insert
C&P Collect&Place
C&P12, CP12 Collect&Place head with 12 segments
C&P20, CP20 Collect&Place head with 20 segments
C&P6, CP6 Collect&Place head with 6 segments
CPP Collect&Pick&Place head
CPx Collective term for CPP, CP20, CP12 and/or CP6
DC Dual conveyor with two lanes
ESD Electrostatic sensitive device
EMC Electromagnetic compatibility
SC Single conveyor with one lane
PCB Board
P&P, PP Pick&Place
QC Quad lane conveyor with four lanes
SC Station computer
TH TwinHead
VS Vision system type
Introduction
Abbreviations 1.4.6 SIPLACE on the World Wide Web (WWW)
20 Maintenance Manual SIPLACE X Series
