Minor Maintenance Maintenance Intervals for Minor Main tenance Maintenance Manual SIPLACE X Series 25 4 4 M in o r M a in t e n a n c e Minor Maintenance 4.1 4 . 1 M a in t e n a n c e I n t e r v a ls f o r M in o r M a…
Tools, Consumables, Spare and Wear Parts
Minor and Major Maintenance for X-Series Machines
24 Maintenance Manual SIPLACE X Series
Tools Item no. Supplied in the
service box
ESD wriststrap TYP.OK/WRS 00320279- xx
Set of Phillips screwdrivers
SIPLACE OPERATOR KIT 00349303- xx
Scissors 00378524- xx
Tweezers 00378525- xx
Electronic screwdriver, Phillips 00378527- xx
Electronic screwdriver, slotted 00378526- xx
Vacuum cleaner
Waste bin
Abrasive cleaning agent, universal 80x65mm 00372809- xx
Grease gun with nozzle for X axis (volume applied: approx. 0.13 g) 00374564- xx X
Grease gun with hose for Y axis (volume applied: approx. 0.4 g) 00374563- xx X
A high-precision set of scales (recommended minimum measuring
accuracy: 1 g)
Additionally required documentation Item no. Supplied in the
service box
Service manual X-Series
► You need more tools etc.
German:
00194439-xx
English:
00194440-xx
Spare parts Item no. Supplied in the
service box
Lubrication nipple DIN71412-B-M6 – 45° bent, if required (see also
"5.3.3.2 Greasing the Cutter" [ ➙ 42])
03036943- xx
Lubrication nipple for upper guide carriage (X axis) - bent by 45° 03094503- xx
Lubrication nipple for lower guide carriage (X axis) - straight 03094505- xx
Lubrication nipple DIN71412-A-M6 - straight (Y axis) 03036936- xx
Minor Maintenance
Maintenance Intervals for Minor Maintenance
Maintenance Manual SIPLACE X Series 25
4
4 Minor Maintenance
Minor Maintenance
4.1
4.1 Maintenance Intervals for Minor Maintenance
Maintenance Intervals for Minor Maintenance
2020 - Minor - Basic Machine - X-Series
2120 - Minor - Component S upply - X-Series
2220 - Minor - Optical Systems - X-Series
2320 - Minor - Gantry - X-Series
2420 - Minor - Conveyor - X-Series
See also
1.3.2 Calculation of Maintenance Intervals [ ➙ 15]
Maintenance tasks
Base machine
Duration
[min]
Each
week
Every 3
months
Every 6
months
Every 12
months
Cleaning/Replacing the Filter on the Protective
Covers (X4I Only)
1X
Checking the Fan on the Covers and on the Ma
-
chine Rucksack
1X
Maintenance tasks
Gantry
Duration
[min]
Each
week
Every 3
months
Every 6
months
Every 12
months
Check and clean the magnetic surfaces of the X
and Y axes
2X
Maintenance tasks
Conveyor
Duration
[min]
Each
week
Every 3
months
Every 6
months
Every 12
months
Vacuuming the Conveyors, Conveyor Belts, Sen
-
sors and Lifting Table
1X
Minor Maintenance
Maintenance Tasks for Base Machine 4.2.1 Tools, Consumables, Spare and Wear Parts
26 Maintenance Manual SIPLACE X Series
4.2
4.2 Maintenance Tasks for Base Machine
Maintenance Tasks for Base Machine
4.2.1
4.2.1 Tools, Consumables, Spare and Wear Parts
Tools, Consumables, Spare and Wear Parts
▪ Sheet of DIN A4 paper
▪ ESD wristband [00320279-xx]
▪ Vacuum cleaner with appropriate nozzle
4.2.2
4.2.2 Performing Maintenance Tasks
Performing Maintenance Tasks
4.2.2.1
4.2.2.1 Cleaning/Replacing the Filter on the Protective Covers (X4I Only)
Cleaning/Replacing the Filter on the Protective Covers (X4I Only)
Replacing the filters in the protective covers
► Vacuum the filters in the protective covers of the
SIPLACE X4I from above.
► Check the filters for dirt.
If the filters are very dirty, replace with new ones. (see
below)
► Open the protective cover.
► Loosen the screw (1) on the upper side of the fan.
► Push the fan element up, and fold it down carefully.
CAUTION!
Take care not to damage the fan connection cable!
► Replace the filter with a new metal filter [03076892-
xx].
► Fit the fan and screw tight.
► Close the protective cover.
