Vision Teach Station User Manual 1 Overview
11/2013 Edition 1.3 Which component cameras are supported?
101
1.3 Which component cameras are supported?
The vision teach station supports the following component cameras:
1
Tab. 1.3 - 1 Component cameras supported by the vision teach station
Component camera Component range Used on which placement machine?
C&P, type 23, 6x6 ,
digital
01005 to 6 x 6 mm²
X series:
Head camera for the C&P20 head
C&P, type 28, 18 x 18,
digital
0402 to 18 x 18 mm²,
PLCC 44 including BGA, μBGA,
flip-chip, TSOP, QFP,
SO to SO32, DRAM
X/D series:
Head camera for the C&P12 head
C&P, type 29, 27 x 27,
digital
0201 to 27 x 27 mm²
PLCC, SO, QFP, TSDP, SOT,
MELF, CHIP, IC, BGA
X/D series:
Head camera for the C&P6 and C&P12
heads
C&P, type 30, 27 x 27,
digital
01005 to 27 x 27 mm²
PLCC, SO, QFP, TSDP, SOT,
MELF, CHIP, IC, BGA
X/SX/D series:
Head camera for the CPP and C&P12
headsf
P&P, stationary, type 33,
55 x 45, digital
0402 to 55 x 45 mm²,
MELF, SO, PLCC, QFP,
electrolytic capacitors, BGA,
connectors
X/D series:
Stationary camera for ICs and connec-
tors
P&P, stationary, type 25,
16 x 16, digital
0201 to 16 x 16 mm²,
SO, PLCC, QFP, sockets, plugs,
BGA, special components, bare
dies, flip-chips, shields
X/D series:
Stationary camera for flip-chip compo-
nents
P&P, stationary, type 36,
32 x 32, digital
(Is supported from SIPLACE
Pro 4.1 onwards)
0603 to 32 x 32 mm²
SO, PLCC, QFP, BGA, special
components, bare die, flip-chip
D1:
Stationary camera for ICs
2 Safety instructions Vision Teach Station User Manual
1.3 Which component cameras are supported? 11/2013 Edition
102
2 Safety instructions
WARNING 2
The safety instructions from the “Operational safety” chapter of the user manual and the service
manual take precedence over these instructions.
The vision teach station is supplied with main power voltage. Consequently parts of these systems
carry dangerous voltages! Incorrect use of the system or contact with voltage-carrying parts can
lead to death or severe injury.
– Always follow the applicable accident prevention and DIN/EN regulations.
– Always follow any safety regulations specific to your country.
– Follow the ESD regulations as described in the operational safety section of the operating in-
structions.
– Never make changes, however minor, unless you are totally aware of the effect they will have
on the overall functioning of the system.
– The vision teach station must always be set up, retooled and maintained by appropriately trai-
ned personnel.
– Only use original spare parts and authorized accessories from ASM Assembly Systems. The
use of other parts will affect safety and may invalidate the liability for any consequential da-
mage.
– The vision teach station is only guaranteed to be safe to use if it is used for the intended pur-
pose and if the user manual is followed.
– Vision teach station operators must only carry out work for which they have been adequately
trained and with which they are totally familiar.
– If particularly hazardous situations are identified while the vision teach station is in use, the ma-
chine owner must immediately notify the manufacturer in writing so that appropriate action can
be taken to reduce the potential danger.
The base module is heavy.
– So make sure that you place the module on a stable surface.
– Ask a second person to help you carry the base module.
– Always make sure that the cameras are firmly bolted to the base module.
Vision Teach Station User Manual 3 Ordering information and package supplied
11/2013 Edition 3.1 Vision teach station
103
3 Ordering information and package supplied
The vision teach station configuration depends on the selected camera type. The package sup-
plied will therefore vary according to the situation.
3.1 Vision teach station
3.1.1 Vision teach station - item number
3
3
3.1.2 Vision teach station - bill of materials
Order designation Item no.
Vision teach station, SIPLACE X/D/SX series 00119788-xx
Order designation Item no. Number
Vision Teach Station
03039501-xx 1
Component cameras and assembly kits
see Section
3.2 , page 106 1
PC for Vision Teach Station
03040354-xx 1
CAN card, Power CAN PCI
a
03079973-xx 1
Hotlink interface, PCI-A14-K01
a
03032343-xx 1
19" TFT monitor, LCD TOP-P19-2
a
00375806-xx 1
Camera cable, vision teach station, 3m
03040359-xx 1
CAN cable, teach station PC, 3m
03040362-xx 1
Connecting cable, EU 3 x 1.0 mm², 3m
00304984-xx 1
