ASYMTEK Forte® Series Spares List
February 2024 8
SCREW, M3X.05 FLAT
12
392120
SENSOR,BOARD,LOW PROFILE
2
7209626
RETAINER,BELT,CMP
8
7213118
INSERT,TOP,FLAT BLT,CHAIN,S920
2
7214220
ASSY,S-9XX 6MM BELT PULLEY
8
7214226
BELT,FLAT,5.7X1.4X2350
4
7214245
ASSY,STOP PIN,S-9XX
2
7217639
ASSY,RAIL EXT. SET,6MM BELT
2
7219179
KIT,DISP,STN COMMON PARTS
1
7241106
KIT, T1 S2-900 4MM
BELT CNVYR, 1 STN
6112734
SCREW, M4X0.7 SOCKET FLAT X 12
20
388012
RETAINER,BELT,CMP
8
7213118
BELT,FLAT,3.6X1.4X1350,ESD
4
7213124
INSERT,TOP,O-RING,S-920
2
7214221
ASSY,S-9XX 4MM BELT PULLEY
8
7214236
KIT,DISP,STN COMMON PARTS
1
7241106
KIT, T1 S2-900 4MM
BELT CNVYR, 2 STN
6112736
SCREW, M4X0.7 SOCKET FLAT X 12
22
388012
SCREW, M4 X 0.7, SOCKET X 10
4
388027
SENSOR,BOARD,LOW PROFILE
1
7209626
RETAINER,BELT,CMP
8
7213118
BELT,FLAT 3.6X1.4X1850,ESD
4
7213125
INSERT,TOP,O-RING,S-920
2
7214221
ASSY,S-9XX 4MM BELT PULLEY
8
7214236
ASSY,STOP PIN,S-9XX
1
7217639
KIT,DISP,STN COMMON PARTS
1
7241106
ASSY,RAIL EXT.SET,4MM BELT
1
7241107
KIT, T1 S2-900 4MM
BELT CNVYR, 3 STN
6112737
SCREW, M4X0.7 SOCKET FLAT X 12
24
388012
SCREW, M4 X 0.7, SOCKET X 10
8
388027
SENSOR,BOARD,LOW PROFILE
2
7209626
RETAINER,BELT,CMP
8
7213118
BELT,FLAT 3.6X1.4X2340,ESD
4
7213126
INSERT,TOP,O-RING,S-920
2
7214221
ASSY,S-9XX 4MM BELT PULLEY
8
7214236
ASSY,STOP PIN,S-9XX
2
7217639
KIT,DISP,STN COMMON PARTS
1
7241106
ASSY,RAIL EXT.SET,4MM BELT
2
7241107
ASSY, LIFT CLAMP
6120496
CLEVIS, ACTUATOR, LIFT CLAMP
1
6120483
BASE, BOLT ON LIFT CLAMP
1
6120486
DRIVE ARM, BOLT ON LIFT CLAMP
2
6120487
CLAMP, BOLT ON LIFT CLAMP ASSY
1
6120488
SPACER, 25 OD, 10 ID, 2mm THK
2
6120492
PIVOT MOUNT, ACTUATOR,LT CLAMP
1
6120493
ASSY, DOUBLE CLEVIS, M5
1
6120494
ASSY, CLEVIS, M6
1
6120495
BEARING, BALL FLANGED, .625OD
4
383396
SHAFT,ADJUSTMENT
1
195551
NUT, HEX M5 X 0.8
3
388055
ELBOW,FLOW CONTROL,METER OUT
2
234182
SCREW, M4 X 0.7, SOCKET X 10
2
388027
WASHER, FLAT M4
3
387998
SCREW, M4X0.7 SOCKET FLAT X 12
4
388012
BEARING, .1875 ID x .375 OD
4
383392
SCREW, M4X0.7 SOCKET FLAT X 10
2
7245171
NUT,SQUARE,M4,7X7X2
2
7207258
SCREW, M4 X 0.7 SOCKET X 16
2
388030
AIR CYLINDER,2 INCH STROKE
1
7200044
KEEPER, LIFT CLAMP
2
6122514
RETAINING CLIP, STND, 3/16" SHAFT
1
6122516
CLIP, C, 3/16
3
7265001
ASYMTEK Forte® Series Spares List
February 2024 9
CLIP, C, 3/16
4
7265001
ASSY, STOP PIN
7217639
AIR CYLINDER,15MM STROKE
1
392794
FITTING,UNION,10-32THD-1/8TUBE
2
387427
WASHER, FLAT M3
2
387964
SCREW, M3 X 0.5 SOCKET X 8
2
387980
SCREW, M4X0.7 SOCKET FLAT X 12
2
388012
NUT,SQUARE,M4,7X7X2
2
7207258
STOP PIN THIN LEAD FRAME
1
7217598
MOUNT,STOP PIN,EXTENDED
1
7217615
FRU, PWA, CM
SERVO AMP
6105630
PWA,CM SERVO AMP
1
7232320
ASSY, SERVO
POWER SUPPLY
1000W
6117222
CABLE TIE,4",BLACK
3
382767
CABLE, POWER SUPPLY AC
1
7243487
PLATE, 1000W POWER
1
6117196
POWSUP,UNIV VAC TO 48VDC 1000W
1
6117232
SCREW,M4X0.7 BUTTON HEAD,X6
3
7226304
CABLE,SERVO SPS 1000W DC OUT
1
6117258
CABLE TIE,NYLONG,RED
1
7205965
KIT, FUSES
6655199
FUSE-TH,5A 125V 280MIL PICO II
10
7204226
FUSE, 6.35A,5X20MM,250V,SLOW
10
7204794
FUSE-TH, 3A, 125V, 280 MIL PICO II
10
382230
ASSY, PZD II
PROGRAMMED
7283790
SCREW, M3 X 0.5 SOCKET X 6
4
387979
LABEL,BLANK, FOR PLD
1
7275814
PCA,PZD GEN 2
1
7252520
LABEL,RISK,ELECTRIC SHOCK,SEMI
1
7280690
COVER,PZD II,SHEET METAL
1
6124648
KIT, CONV PNEUM
PNL, MAN FLOW,
FORTE
6117183
SCREW, M4 X 0.7, SOCKET CAP,X8
4
388026
ASSY,CNV PN.PNL.,MANUAL FLOW
1
6117184
ASSY,FIBER
ARRAY,90 DEG
196577
NUT, M4 SQUARE M-800
1
385751
PIN,062MLX,24-30AWG,5A,20SN,CR
3
194481
CONTROLLER,FIBER OPTIC,E3XMC11
0
196580
FIBER ARRAY DIFFUSED,90 DEG
1
196581
SPACER,FIBER ARRAY,90DEG
1
198530
SCREW,M4X0.7 BUTTON X 12
1
7241929
PLUG-F,3P/1RW,062MLX,FH,DETNTS
1
7247572
HEATSHRINK,12MM,4:1,ADHESIVE
0.1
7275588
AMPLIFIER,FIBER,E3XHD
1
7296782
FRU, PCA, HOME
SENSOR, EXT
6110223
PCA,HOME SENSOR EXT
1
7283730
BAG, SEALTOP 3X5, 2 MIL, W/WHT
1
383161
Individual Part List
The following items are sold individually.
Part Description
Lookup Part Number
BEAMSPLITTER, VOF LIGHTBOX
7214512
LENS, 25MM F1.4, "C"-MNT, 5G
7269305
SENSOR,BOARD,LOW PROFILE
7209626
BRUSH, STRIP, CLN STN, ADSZ, 50PKG
6101344
ASYMTEK Forte® Series Spares List
February 2024 10
ASSY,CONVEYOR CONTROLLER, HEAT
6110180
CLAMP, JET CLEAR
7218030
MAIN AIR REGULATOR
6120507
PWA, SERVO POWER CONTROL
6105641
PCA,EXPANSION MOTOR,TESTED"
6111075
ASSY, SYSTEM PCA, FORTE
6115684
PWA, CM CONVEYOR CONTROLLER
7241300
PWA,LED DRIVER 1.25A
7216705
PCA,SYSTEM PROGRAMMED,FORTE
6127465
BOOT,VAC .120 ID OLIVE
381523
O-RING, 1 7/8 OD X 1/16
381649
TILE,XY OFFSET, 3X6,PCB
6115952
