ASYMTEK Forte® Series Spares List

February 2024 5

STANDOFF,M4X31MM,FEM/MALE,HEX

1

7205992

SCREW,M4X0.7X10MM,BUT HD,SS

3

7246519

SCREW, M6 X 1.0 SOCKET X 12

8

7242203

WASHER, FLAT,.88"OD x.515"id

4

7286704

WASHER, FLAT M6

4

388088

SCREW, M3 X 0.5 PH.FLAT X 5

2

387973

ASSY,Z-AXIS,FORTE

1

6109480

STANDOFF,M-F,M5X20

1

6653660

ASSY, LIGHT BOX,

40W VOF

6100356

BAG,SEALTOP4X6,2 MIL,W/WHT

1

7257493

LOCTITE 222MS,50ML BOTTLE

1

7252898

CABLE TIE, 3/16" ROUND

1

387910

SCREW,M2X.40X6 FLTHD. PH. REC.

4

387957

SCREW,M2-0,4X6 SOCKET CAP

8

7275113

SCREW, M3X.05 FLAT

1

392120

LENS,FRESNEL,RECT.LIGHTBOX

1

7214495

DIFFUSER,RECT.LIGHTBOX

1

7214496

BEAMSPLITTER,VOF LIGHTBOX

1

7214512

SCREW,FLAT,M2 X 0.4 X 4SST

2

7217764

BLOCK,VOF LIGHT BOX 40W

1

7239586

BLOCK, BEAMSPLITTER, LIGHTBOX

1

7269826

ASSY,RGB LZP, 40W

1

6133145

SETTING, STAR LED LIGHTBOX 40W

1

6135678

KIT,NANO CAM &

RGB LIGHT,FORTE

6105897

ASSY,NANO CAMERA & LIGHT,RGB

1

6109461

PWA,LED DRIVER 1.25A

1

7216705

CABLE,RGB PWA TO 5CH CT ADAPTR

1

7254961

SCREW, M3 X 0.5 SOCKET X 8

4

387980

KIT, STANDARD

SCALE, FORTE

6105899

LABEL,3"X1"

2

196170

TUBING,170ID X .250OD,POLYURE

1

6126523

CABLE TIE,4",BLACK

1

382767

SCREW, M4X0.7, BUTTON HEAD, X8

8

388040

SCREW, M6 X 1.0 SOCKET X 12

4

7242203

FERRITE,SNAP-ON,10MM DIA

2

7252912

WIRE MARKERS DISPENSER

1

7257508

TOOL,BREEZE SHIELD LID LEVEL

0

7241336

SCREW,M4X0.7X10MM,BUT HD,SS

2

7246519

SCREW,M4X0.7 BUTTON HEAD,X6

3

7226304

ASSY,SCALE W ELEC,LEFT

1

6127933

KIT, INSTALL, SCALE

.01MG, FORTE

6138271

ASSY, PRECISION SCALE, .01MG,

FORTE

1

6138270

WEIGHT,CAL, 20G

1

7258792

TWEEZERS,CAL WEIGHT

1

7258793

CABLE,PRECISION SCALE SHUTTER

1

7298851

PLUG-M,14S,PHOENIX 3.81mm,SCRW

1

199257

FITTING, 1/4"Y, QUIK-DISCON.

1

381675

PURGE CUP,AL FOIL,100PK

1

7234093

SCREW,M6X1.0,SOCKET X20,SS

4

388103

TUBING,170ID X .250OD,POLYURE

4

6126523

LABEL,SELF LAMINATING 1X2.25"

2

7216610

SCREW, M6 X 1.0 SOCKET X 12

2

7242203

CABLE TIE,4",BLACK

6

382767

CABLE-P,CAT-6,ETHERNET,2M

1

7215887

CABLE,24VDC, SCALE POWER

1

6146817

DIN RAIL FOR TF,80MM

1

7251106

KIT, SCALE PARTS,

SERVICE

6655168

COVER,CM,BREEZE SHIELD

1

7241171

BASE,CM,BREEZE SHIELD

1

7241172

ASYMTEK Forte® Series Spares List

February 2024 6

PEDESTAL, CM, SCALE

1

7241173

KIT, SERVICE

STATION

6655194

COVER, PURGE CUP, CLEAR

1

194701

O-RING, 1 7/8 OD X 1/16

10

381649

TACTILE CAP/CERAMIC TILE

1

6112270

SCALE LID W/ FIDUCIALS

1

7238690

ASSY,NEEDLE X-Y LOCATOR

1

392435

TILE CALIBRATION & DUAL OFFSETS

1

6138731

KIT, ENCODER

SCALE, FORTE

6655195

ENCODER, SCALE, 8 X 80MM, 50-REF,

SS

1

6120476

ENCODER, SCAL, 8 X 450MM, 50-REF,

SS

1

6120477

ENCODER, SCALE, 8 X 600MM, 50-

REF, SS

1

6120478

ENCODER,OPTICAL,1um,2MHZ,225m

m

1

6120475

KIT, LASER HS,

FORTE

6105898

SPRING,LEAF

1

194547

CABLE TIE,4",BLACK

2

382767

SCREW, M3X6 BUTTON HEAD

2

7244697

WASHER, FLAT M3

2

387964

SCREW M3X0.5 SOCKET X 4

1

387977

SCREW, M4 X 0.7, SOCKET CAP,X8

2

388026

COVER,QUARTZ,LHS,SHIELD,32mm

1

7254822

ASSY,uEPSILON LHS,ILD1420(203)

1

7294336

BRKT,LASER COVER,M-EPSILON1420

1

6109477

ASSY, LEFT FRONT

PULLEY, FORTE

6652428

ASSY,RIGHT REAR PULLEY,FORTE

1

7286670

ASSY,LEFT REAR PULLEY,FORTE

1

7286669

ASSY,LEFT FRONT PULLEY,FORTE

1

7286667

ASSY,RIGHT FRONT PULLEY,FORTE

1

7286668

NUT,HEX M6X1.0,SS

6

388086

BRKT.,Y SWITCH

1

7286680

KIT,PNEUMATIC

SOLENOID FOR

VALVE, FLUID AND

PURGE

6655196

VALVE, 3 WAY, 24V

3

382928

FITTING, ELBOW,1/8NPT-1/4TUB

6

387432

MUFFLER, 1/8 MPT

3

6114637

KIT,PNEUMATIC

SOLENOID FOR MAIN

1 AND MAIN 2

6655197

VALVE, 3 WAY, HIGH FLOW

2

383240

FITTING, ELBOW, 3/8 TUBE O.D

2

383432

FITTING, 1/8M X 1/8F X 1/8FNPT

2

7244870

FITTING,MALE,3/8TUBE X1/8 NPT

2

7243915

FITTING,1/8NPT X DUAL-Y 1/4OD

2

392803

MUFFLER, 1/8 MP

2

6114637

KIT, VALVE,

COOL/COAX

6655198

REGULATOR, E/P, 0-130PSI, 0-5V

1

6109468

MUFFLER, 1/8 MPT

1

6114637

ELBOW, 1/4MNPT X ¼ Q-DISC, SWIV

2

381674

FTG, DOUBLE BRANCH ELBOW, 3/8"

1

6109469

ASSY, 30A CM

POWER MANAGER

6101430

KIT,PWR MGR,DUAL IJ RETROFIT

1

6101636

ASSY, 30A CM POWER MANAGER C30

1

6100927

ASYMTEK Forte® Series Spares List

February 2024 7

ASSY,30A POWER

MGR,JAPAN

6110186

SCREW, M4X0.7, BUTTON HEAD, X8

9

388040

SLEEVE,SILICONE RUBBER,6AWG

1

7268601

PLATE, TERMINAL BLOCK MOUNT

1

6109545

TERMINAL BLOCK,12P,55A

1

7253998

SCREW, M3X.5 X 8MM LNG.BUTTON

2

7244069

WASHER, FLAT M3

2

387964

SCREW, M4 X 0.7, SOCKET X 20

4

388032

LABEL, 30A PWR MGR, INTERRUPT

CAP 1.5KA

1

7296109

C.BR.,EL,30A,2_POLE,30MA,1.5K

1

211108

BRACKET,ELCB,POWER MANAGER

1

200410

LABEL, MARKER, HEAT SHRINK TUB

4

7246599

FERRULE,10AWG,12MM PIN LENGTH

2

7213072

PLATE, INLET ADAPTER, SS

1

6109546

SCREW,M5-08X8 BUTTON HEAD

4

7242329

WASHER, #10 INTERNAL STAR

4

7246513

STRAIN RELIEF,OLFLEX S2121

1

7246123

TERMINAL, RING #8 X 10 AWG

1

7279904

FERRULE,10AWG,12MM PIN LENGTH

2

7213072

CABLE-B,10F,3C,UNSH,.709BK/NEO

15

7242543

WASHER, #8 INTERNAL STAR

2

381697

PLUG, 250V, 30A, TWIST LOCK

1

7275563

LABEL, BLANK, GREY MYLAR

1

7252393

ASSY,30A CM POWER MANAGER

1

6101430

FRU KIT,CM LIGHT

BEACON

7296781

SPACER, 5/16" X 3/4" ALUM.

4

7275054

SCREW, M4X0.7, SOCKET CAP, X30

4

388034

BEACON,60MM RAGB&ALARM

W/CONN

1

7263560

FRU, CM SYSTEM

LIGHT, 12V

6112644

CLIP,WIRE HARNESS,.250 ID

1

194981

SCREW,M4X0.7 BUTTON HEAD,X6

2

7226304

SCREW, M4X0.7, BUTTON HEAD, X8

2

388040

ASSY,LED SYS LIGHT,12V,6"

1

7266340

BRACKET,LIGHT ADAPTER

1

7294903

KIT, T1 S2-900 6MM

BELT CNVYR, 1 STN

6112738

SCREW, M4X0.7 SOCKET FLAT X 12

20

388012

SCREW, M3X.05 FLAT

12

392120

RETAINER,BELT,CMP

8

7213118

INSERT,TOP,FLAT BLT,CHAIN,S920

2

7214220

ASSY,S-9XX 6MM BELT PULLEY

8

7214226

BELT,FLAT,5.7X1.4X1350,ESD

4

7214243

KIT,DISP,STN COMMON PARTS

1

7241106

KIT, T1 S2-900 6MM

BELT CNVYR, 2 STN

6112739

SCREW, M4X0.7 SOCKET FLAT X 12

22

388012

SCREW, M4 X 0.7, SOCKET X 10

4

388027

SCREW, M3X.05 FLAT

12

392120

SENSOR,BOARD,LOW PROFILE

1

7209626

RETAINER,BELT,CMP

8

7213118

INSERT,TOP,FLAT BLT,CHAIN,S920

2

7214220

ASSY,S-9XX 6MM BELT PULLEY

8

7214226

BELT,FLAT,5.7X1.4X1850

4

7214244

ASSY,STOP PIN,S-9XX

1

7217639

ASSY,RAIL EXT. SET,6MM BELT

1

7219179

KIT,DISP,STN COMMON PARTS

1

7241106

KIT, T1 S2-900 6MM

BELT CNVYR, 3 STN

6112741

SCREW, M4X0.7 SOCKET FLAT X 12

24

388012

SCREW, M4 X 0.7, SOCKET X 10

8

388027
