YSM10-BOM - 第19页
3 1 4 2 7 8 9 6 6 11 11 9 10 9 6 5 6 11 12 11 9 10 5 12 7 8 FDR. Floating Detection Bank Section 3-3 Sensor Distinction 3 1 4 2 7 8 9 6 6 11 11 9 10 9 6 5 6 11 12 11 9 10 5 12 7 8 KMG-1706 NO Parts_No. Parts_Name Q'…
2
1
5
10
6
10
9
10
9
10
9
9
7
9
11
9
8
8
4
3
12
12
12
12
Hole Cover Assy
Bank Section
KMG-1705
3-2
2
1
5
10
6
10
9
10
9
10
9
9
7
9
11
9
8
8
4
3
12
12
12
12
NO
Parts_No.
Parts_Name
Q_ty
Remarks
Compati
Revision_No._date
1
KMG-M3440-00
HOLE COVER ASSY.
1
STD Feeder
2
KMG-M3440-10
HOLE COVER 2 ASSY.
1
O/P sATS15
3
KMG-M3441-00
BLOCK,HOLE BASE
1
4
KMG-M3442-00
COVER,HOLE BASE
1
5
KMG-M3445-00
BLOCK,HOLE BASE 2
1
6
KMG-M3446-00
COVER,HOLE BASE 2
1
7
KMG-M3447-00
COVER,HOLE BASE 3
1
8
91312-04006
BOLT,HEX.SOCKET HEAD
2
9
91312-05010
BOLT,HEX.SOCKET HEAD
6
10
91312-05030
BOLT,HEX.SOCKET HEAD
4
11
91312-06008
BOLT,HEX.SOCKET HEAD
1
12
91312-06025
BOLT,HEX.SOCKET HEAD
4
3
1
4
2
7
8
9
6
6
11
11
9
10
9
6
5
6
11
12
11
9
10
5
12
7
8
FDR. Floating Detection
Bank Section
3-3
Sensor Distinction
3
1
4
2
7
8
9
6
6
11
11
9
10
9
6
5
6
11
12
11
9
10
5
12
7
8
KMG-1706
NO
Parts_No.
Parts_Name
Q'ty
Remarks
Compati
Revision_No._date
1
KMG-M3910-00
FDR.FLT.DET.L
1
<Preset> Front-1 bank (F1 / front-left) : SQ131A & SQ131B
2
KMG-M3910-10
FDR.FLT.DET.R
1
<Preset> Front-2 bank (F2 / front-right) : SQ132A & SQ132B
3
KMG-M3910-00
FDR.FLT.DET.L
1
<OP> Rear-1 bank (R1 / rear-right) : SQ133A & SQ133B
4
KMG-M3910-10
FDR.FLT.DET.R
1
<OP> Rear-2 bank (R2 / rear-left) : SQ134A & SQ134B
5
KMG-M3911-00
BRKT.,SENSOR 1
4
6
KMG-M3912-00
BRKT.,SENSOR 2
8
7
KMG-M653K-00
SENSOR,LASER
2
FLT POW (SQ13?A : emitter) & FLT (SQ13?B : receiver)
8
90K41-001620
LABEL,CAUTION
2
"LASER radiation. Do not stare into beam." pictogram
9
91312-04005
BOLT,HEX.SOCKET HEAD
16
10
91312-04008
BOLT,HEX.SOCKET HEAD
8
11
92902-04200
WASHER, PLAIN
8
12
97602-03314
SCREW,PAN HEAD W/W
8
Reel Holder 60
Bank Section
KMG-1706
2
2
3
4
4
4
4
27
30
21
1
26
25
21
33
33
33
33
18
18
5
6
31
33
33
33
33
23
31
23
18
18
18
19
28
19
17
21
22
6
8
7
8
13
14
8
8
11
10
9
9
12
20
20
19
19
17
29
29
23
31
24
16
15
30
32
32
No. Part No. Part Name Q'ty Remarks Compati. Revision No.-date
1 KHY-M3S00-00 REEL HOLDER 60 ASSY 1
2 KHY-M3S07-01 TRIM 2
3 KHY-M3S08-00 UNDER COVER 1
4 KHY-M3S09-00 SHAFT, ROLLER 4
5 KHY-M3R10-02 REEL PUT 30
6 KHY-M3R14-01 COLLAR 2 Φ 30
7 KHY-M3R14-11 WASHER 31 Φ 21
8 KHY-M3R15-00 ROLLER 98
9 KHY-M3S15-00 ROLLER 2 2
10 KHY-M3R16-00 PARTITION 15
11 KHY-M3R22-00 GUIDE, PARTITION 7
12 KHY-M3S22-00 GUIDE 2, PARTITION 1
13 KHY-M3R23-00 COLLAR, PARTITION 29
14 KHY-M3S23-00 COLLAR 2, PARTITION 1
15 KHY-M3S20-S1 RH FRAME SUB ASSY 1
16 KHY-M373C-10 CHAIN ASSY 1
17 KHY-M374C-00 CASTER 2
18 91312-06012 BOLT HEX. SOCKET HEAD 8 M6X12
19 91312-06008 BOLT HEX. SOCKET HEAD 16 M6X10
20 91312-03012 BOLT HEX. SOCKET HEAD 16 M3X12
21 91312-03005 BOLT HEX. SOCKET HEAD 12 M3X5
22 92902-03200 WASHER PLAIN 8
23 91312-04008 BOLT HEX. SOCKET HEAD 17
24 90172-00J040 WASHER,EXTL.TOOTHED 1
25 KHY-M3R01-00 SIDE PLATE, R 1
26 KHY-M3R02-00 SIDE PLATE, L 1
27 KHY-M3S06-04 STOPPER PLATE 1 Hole position change
28 KHY-M3S20-00 RH. FRAME ASSY 1
29 KM0-M3741-00 CASTER 63 2
30 KHY-M3S0A-01 STAY,SHAFT 2
31 92902-04200 WASHER, PLAIN 16
32 92902-04600 WASHER, PLAIN 4
33 92902-06600 WASHER, PLAIN 8
3-4
