YSM10-BOM - 第45页

3 16 2 15 16 13 2 13 1 8 10 12 12 1 4 4 14 14 11 7 9 6 6 9 5 18 18 10 19 17 19 20 22 21 3 16 2 15 16 13 2 13 1 8 10 12 12 1 4 4 14 14 11 7 9 6 6 9 5 18 18 10 19 17 19 20 22 21 ANC Clamp Holder Nozzle Section KMG-1705 6-3…

100%1 / 62
22
7
14
36
38
28
18
38
23
28
40
40
40
17
40
16
36
16
31
29
30
21
27
32
11
29
15
1
6
20
2
10
33
29
39
26
27
29
37
19
31
30
4
12
34
26
13
25
25
35
24
24
22
7
14
36
38
28
18
38
23
28
40
40
40
17
40
16
36
16
31
29
30
21
27
32
11
29
15
1
6
20
2
10
33
29
39
26
27
29
37
19
31
30
4
12
34
26
13
25
25
35
24
24
ANC Stand Assy
Nozzle Section
KMG-1705
6-2
NO
Parts_No.
Parts_Name
Q_ty
Remarks
Compati
Revision_No._date
1
KHN-M9623-50
PIN
2
2
KHW-M916A-00
BUSH
2
3
KHW-M916E-00
BUSH
1
4
KHW-M916G-00
COLLAR, JOINT
1
5
KHW-M916H-00
JOINT, CYL.
1
6
KHY-M45BA-01
ANC CTRL BOARD ASSY
1
P160
7
KHY-M652G-10
CYLINDER ANC ASSY
1
SQ151 : CN 3A 6A : open / SQ152 : CN 5A 7A : close
8
KHY-M9614-00
STOPPER,CYLINDER
1
9
KHY-M9622-03
PLATE,LED SHIELD
1
10
KHY-M9627-00
BLOCK,LINK
1
11
KHY-M9628-00
COLLAR,LINK
1
12
KHY-M9631-00
COLLAR,FLOATING
1
13
KHY-M9632-00
BLOCK,FLOATING
1
14
KKS-M9615-00
PLATE,CYLINDER
1
15
KKT-M9613-00
BLOCK,CYLINDER
1
16
KLW-M96S3-00
SHAFT
4
17
KLW-M96S4-00
PLATE,MIDDLE
1
18
KLW-M96S5-00
PLATE,BASE
1
19
KMG-M9612-00
PLATE,SIDE
1
20
KMG-M96S1-00
HOLDER,BOTTOM
1
21
KMG-M96S2-00
PLATE,SIDE
1
22
KMG-M96S6-00
BOARD,CLEAR
1
23
KMG-M96S8-00
SUPPORT,STAND
1
24
$SC4-M5A
SPEED CONTROLLER
2
25
$US4
JOINT
2
26
90112-2AJ006
BOLT,HEX.SOCKET HEAD
6
27
90933-02J063
BEARING
2
28
90990-32J005
BOLT,FLANGE
2
29
90990-41J185
COLLAR
4
30
91312-03006
BOLT,HEX.SOCKET HEAD
4
31
91312-03010
BOLT,HEX.SOCKET HEAD
2
32
91312-03025
BOLT,HEX.SOCKET HEAD
2
33
91312-04012
BOLT,HEX.SOCKET HEAD
2
34
91312-04016
BOLT,HEX.SOCKET HEAD
1
35
91312-04022
BOLT,HEX.SOCKET HEAD
1
36
91312-05016
BOLT,HEX.SOCKET HEAD
8
37
91312-05020
BOLT,HEX.SOCKET HEAD
1
38
92902-04200
WASHER, PLAIN
3
39
92902-05200
WASHER, PLAIN
1
40
95702-06500
NUT, FLANGE
8
3
16
2
15
16
13
2
13
1
8
10
12
12
1
4
4
14
14
11
9
6
6
5
18
18
10
19
17
19
20
22
21
3
16
2
15
16
13
2
13
1
8
10
12
12
1
4
4
14
14
11
9
6
6
5
18
18
10
19
17
19
20
22
21
ANC Clamp Holder
Nozzle Section
KMG-1705
6-3
NO
Parts_No.
Parts_Name
Q_ty
Remarks
Compati
Revision_No._date
1
KHY-M9620-00
PIN,MARK
2
2
KHY-M9621-A0
BASE,NOZZLE D ASSY
2
with No.13,16
3
KHY-M9630-00
HOOK,BEARING
1
4
KLW-M96HD-A0
SPACER ASSY.
2
with No.14
5
KMG-M9607-00
PLATE,CLAMP
1
6
KMG-M9619-00
PLUG,ANC
10
in case of "HM5 ANC type"
7
KMG-M9624-00
HOLDER,NOZZLE
1
8
KMG-M96H0-A0
CALMP HLD.ASSY.
1
9
KMG-M96H8-00
MIRROR,SIDE
2
10
KMG-M96HA-00
SHEET,CLAMP GUIDE
2
11
90990-19J004
NEEDLE PIN
68
12
90990-19J009
NEEDLE PIN
4
13
90990-19J010
NEEDLE PIN
2
14
91312-03006
BOLT,HEX.SOCKET HEAD
2
15
91312-03025
BOLT,HEX.SOCKET HEAD
6
16
92012-03006
BOLT,BUTTON HEAD
2
17
92012-04010
BOLT,BUTTON HEAD
2
18
98702-03010
SCREW,FLAT HEAD
10
19
98902-03008
SCREW, BINDING HEAD
12
20
KLW-M96SV-00
ANC VALVE ASSY.
1
YV041 : ANC OP
21
KMG-M9656-00
LABEL,ANC HM
1
in case of "HM ANC type" : pasted on to "Cover 9 Assy"
22
KMG-M9656-10
LABEL,ANC HM5
1
in case of "HM5 ANC type" : pasted on to "Cover 9 Assy"
20
6
19
5
9
19
19
8
12
17
21
14
3
4
16
11
21
18
1
10
7
13
15
1
18
16
20
6
19
5
9
19
19
8
12
17
21
14
3
4
16
11
21
18
1
10
7
13
15
1
18
16
Blow ST. Assy
Nozzle Section
KMG-1706
6-4
NO
Parts_No.
Parts_Name
Q_ty
Remarks
Compati
Revision_No._date
1
KLW-M653X-01
SENSOR,BLOW ST.ASSY
1
SQ161A : BLOW POW : emitter / SQ161B : BLOW : receiver
2
KLW-M99B5-00
INLINE FILTER
1
3
KLW-M99B6-00
PLUG
1
4
KLW-M99V1-A0
BLOW VALVE ASSY.
1
YV051 : SIDE BLOW
5
KMC-M99B3-00
BOX,EXHAUST
1
6
KMC-M99B3-A0
EXHAUST BOX ASSY.
1
7
KMC-M99B4-00
BLOCK,BLOW ST.
1
8
KMC-M99B7-00
COVER
1
9
KMC-M99B8-00
PLATE,BOX
1
10
KMC-M99B9-00
COLLAR
5
11
KMC-M99BA-00
TUBE
5
12
KMG-M99B1-00
BASE,BLOW ST.
1
13
$PF
PLUG
1
14
$TL6-01
JOINT
1
15
$TS6-01M
JOINT
1
16
90166-02J210
SCREW, PAN HEAD
4
17
90990-32J008
BOLT,FLANGE
2
18
90990-41J191
COLLAR
4
19
91312-03005
BOLT,HEX.SOCKET HEAD
9
20
91312-03020
BOLT,HEX.SOCKET HEAD
2
21
91312-04008
BOLT,HEX.SOCKET HEAD
4
