Universal accessories
Neutral terminals
Description Flex cable Part number
Article
number
Std.
pack
Suitable for
export to
North America
(US and
Canada)* Suitable for Mounting
Neutral terminal for connection of a 5th
conductor
1-4 mm² K-CI-K1/2* 207451 20
P1 Surface mounting I2
T0 Surface mounting I1
T3 Surface mounting I3
1.5-16 mm² K-CI-K4 206916 20
T5B Surface mounting I4
P3 Surface mounting I4
10-35 mm² K-CI-K5 218488 20
T5 Surface mounting I5
P3 Surface mounting I5
* UL/CSA certication not required
206916
218488
Set of external brackets
Description Part number
Article
number
Std.
pack
Suitable for
export to
North America
(US and
Canada)* Suitable for Mounting
Set of external fixing brackets, for fixing CI-K4
and CI-K5 directly on walls.
One set contains 4 brackets
AB-CI-K4/5 206914 1
T5B Surface mounting I4
P3-63 Surface mounting I4
T5 Surface mounting I5
P3-100 Surface mounting I5
* UL/CSA certication not required
Photos are representative
163EATON P Switch-disconnectors and T Rotary cam switches CA042001EN
Non standard Cam switches and Switch-disconnectors
%
%
5
5
,
,
(
(
)
)
5GTXGFOCTMGVU
+PFWUVTKCN
/1'/
7VKNKV[
4GPGYCDNG
%QOOGTEKCN
%WUVQOGT
PGGFU
$TKGH
%QPUWNV
&GUKIP
/CPWHCEVWTG
;
2))
21
2))
21
Customised switch-disconnectors design service
Eaton supports custom solutions to suit your application needs thanks to over 50 years of expert
knowledge in Switch-disconnectors design.
Our services include:
• Customised mounting connections.
• Acquire UL/IEC/CCC/CSA certificates.
• Customised testing such as temperature rise or vibration.
• Special plating for connection terminal.
• Modification of enclosures.
• Additional earthing arrangements.
• Custom printed face plates.
• Unique control switching configurations.
Contact us today...
buletechnical@eaton.com
164
EATON P Switch-disconnectors and T Rotary cam switches CA042001EN
Non standard Cam switches and Switch-disconnectors
T0 Cam switches
Rated
current
Number of contact
chambers Mounting option
Main
switch
Handle
colour Part number
Article
number
Suitable for
export to North
America (US
and Canada)
20 A 1
Flush mounting Red T0-1-SOND*/E 907765
Flush mounting
Red T0-1-SOND*/EA/SVB 907776
Flush mounting
Black T0-1-SOND*/EA/SVB-SW 908043
Centre mounting Red T0-1-SOND*/EZ 907787
Surface mounting in size 1 Ci-K Enclosure Red T0-1-SOND*/I1 207480
Surface mounting in size 1 Ci-K Enclosure
Red T0-1-SOND*/I1/SVB 207481
Surface mounting in size 1 Ci-K Enclosure
Black T0-1-SOND*/I1/SVB-SW 207482
Service distribution board Red T0-1-SOND*/IVS 907806
Rear mounting
Red T0-1-SOND*/ V/SVB 907817
Rear mounting
Black T0-1-SOND*/V/SVB-SW 908054
Rear mounting Red T0-1-SOND*/Z 907839
2 Flush mounting Red T0-2-SOND*/E 907766
Flush mounting
Red T0-2-SOND*/EA/SVB 907777
Flush mounting
Black T0-2-SOND*/EA/SVB-SW 908044
Centre mounting Red T0-2-SOND*/EZ 907788
Surface mounting in size 1 Ci-K Enclosure Red T0-2-SOND*/I1 207483
Surface mounting in size 1 Ci-K Enclosure
Red T0-2-SOND*/I1/SVB 207484
Surface mounting in size 1 Ci-K Enclosure
Black T0-2-SOND*/I1/SVB-SW 207485
Service distribution board Red T0-2-SOND*/IVS 907807
Rear mounting
Red T0-2-SOND*/ V/SVB 907818
Rear mounting
Black T0-2-SOND*/V/SVB-SW 908055
Rear mounting Red T0-2-SOND*/Z 907840
3 Flush mounting Red T0-3-SOND*/E 907767
Flush mounting
Red T0-3-SOND*/EA/SVB 907778
Flush mounting
Black T0-3-SOND*/EA/SVB-SW 908045
Centre mounting Red T0-3-SOND*/EZ 907789
Surface mounting in size 1 Ci-K Enclosure Red T0-3-SOND*/I1 207486
Surface mounting in size 1 Ci-K Enclosure
Red T0-3-SOND*/I1/SVB 207487
Surface mounting in size 1 Ci-K Enclosure
Black T0-3-SOND*/I1/SVB-SW 207488
Service distribution board Red T0-3-SOND*/IVS 907808
Rear mounting
Red T0-3-SOND*/V/SVB 907819
Rear mounting
Black T0-3-SOND*/V/SVB-SW 908056
Rear mounting Red T0-3-SOND*/Z 907841
4 Flush mounting Red T0-4-SOND*/E 907768
Flush mounting
Red T0-4-SOND*/EA/SVB 907779
Flush mounting
Black T0-4-SOND*/EA/SVB-SW 908046
Centre mounting Red T0-4-SOND*/EZ 907790
Surface mounting in size 1 Ci-K Enclosure Red T0-4-SOND*/I1 207489
Surface mounting in size 1 Ci-K Enclosure
Red T0-4-SOND*/I1/SVB 207490
Surface mounting in size 1 Ci-K Enclosure
Black T0-4-SOND*/I1/SVB-SW 207491
Service distribution board Red T0-4-SOND*/IVS 907809
Rear mounting
Red T0-4-SOND*/V/SVB 907820
Rear mounting
Black T0-4-SOND*/V/SVB-SW 908057
Rear mounting Red T0-4-SOND*/Z 907842
Note: Please use the ‘Ordering non-standard contact sequences’ order form when ordering for the first time. When placing repeat orders, specifiy the contact
sequence number together (e.g. 47110GB).
For Standard information please refer to pages 180 and 181
