Technical data
P5-125 P5-160 P5-250 P5-315
Switching capacity
AC Voltage
Rated making capacity cos φ = 0.35 A 850 1050 1700 2050
Rated breaking capacity, motor load switch cos
φ = 0.35
230 V A 800 900 1600 1800
400/415 V A 750 850 1380 1650
500 V A 650 850 1250 1550
690 V A 340 340 400 400
Rated operational current 440V, load-break switch AC-21A I
e
A 125 160 250 315
AC-3 motor load switch motor load 230 V P kW 22 30 37 45
400 V P kW 37 45 55 75
690 V P kW 30 37 45 45
AC-23A motor load switch motor load 230 V P kW 30 30 37 55
400 V P kW 45 55 90 110
690 V P kW 37 37 45 45
DC Voltage
DC-1, load switch L/R = 1 ms Rated operational current I
e
A 125 160 250 315
Voltage per contact connected in series V 42 42 42 42
DC-23A, motor load switch
L/R = 15 ms
24 V Rated operational current I
e
A 125 160 250 315
Voltage per contact connected in series Number 3 3 3 3
48 V Rated operational current I
e
A 125 160 250 315
Contacts Number 3 3 3 3
60 V Rated operational current I
e
A 125 160 250 315
Contacts Number 3 3 3 3
120 V Rated operational current I
e
A 125 160 250 315
Contacts Number 3 3 3 3
P5 Switch-disconnectors
Notes: Main switch characteristics to IEC/EN 60204; positive opening of contacts, operator element positively located on shaft. Rated uninterrupted current Iu is
specified for max cross-section.
For terminal capacity solid, stranded and flexible: Max. 2 cross-section sizes difference admissible when using 2 conductors.
HI...-P1(P3)... HI...-P5...
Auxiliary contacts
Standards Control circuit isolator to IEC/EN 60947-5
Rated insulation voltage U
i
V AC 500 500
Rated uninterrupted current I
U
A 10 10
Rated operational current
AC-15 at 230 V I
e
A 6 6
400 V / 415 V I
e
A - -
DC-13
125 V I
e
A 1.1 0.23
250 V I
e
A 0.55 0.1
Short-circuit training
Max fuse A gG/gL 10 10
Terminal capacity
Solid mm
2
1 x 0.75 - 2.5
2 x 0.75 - 1.5
1 x 0.75 - 2.5
2 x 0.75 - 1.5
Flexible with ferrule to DIN 46228 mm
2
1 x 0.5 - 1.5
2 x 0.5 - 1.5
1 x 0.5 - 1.5
2 x 0.5 - 1.5
Tightening torque Nm 0.6 0.8
Control circuit reliability at 24 V d.c., 10 mA H
F
< 10-5, < 1 failure for 100,000 switching operations
186
EATON P Switch-disconnectors and T Rotary cam switches CA042001EN
Technical data
P5-125 P5-160 P5-250 P5-315
Rating data for approved types
UL File No E36332
Contacts
Rated operational voltage U
e
600 600 600 600
Rated impulse withstand voltage
(1)
U
imp
V a.c. 8000 8000 8000 8000
Rated uninterrupted current
(2)
I
u
A 125 160 250 300
Rated operational current
Ampere rating Off switch I
e
A 125 160 250 300
Changeover switches I
e
A 125 160 X X
Non inductive and slightly inductive loads
Rated switching duty
DOL rating (similar to AC-3)
3-phase, 3-pole
120 V HP 15 20 30 40
240 V HP 30 40 60 75
480 V HP 60 60 75 100
600 V HP 60 60 75 100
Short-circuit rating
Max back-up fuse, gL characteristics A 125 160 250 315
Rated short-time withstand current (1s current) A 2500 3000 4600 5000
Terminal capacity
Cu cable
Solid or stranded for box terminal AWG 3/0 3/0 X X
MCM X X 350 350
Flexible without ferrule AWG 2/0 2/0 X X
MCM X X 300 300
Connection with cable lug or busbar M10 x M10 x M10 x M10 x
Terminal screw 20 20 20 20
Max. width 20 20 20 20
Max width with terminal cover 25 25 25 25
Ambient temperature Open on 100% I
U
/I
th
50
o
C over 24 hours with peaks up to 55
o
C
Enclosed on 100% I
the
35
o
C over 24 hours with peaks up to 40
o
c
(1) Valid for mains with grounded star point, overvoltage category III, pollution degree 3, (2) Valid for connection with cable for 75
o
C
P5 Switch-disconnectors
HI11 HI21-P5-125(160) HI21-P5-250(315)
Auxiliary contacts
Standards
Rated uninsulated voltage U
i
V a.c. 600 600
Rated uninterrupted current I
u
A 10 10
Rated operational current I
e
Pilot duty P600 P600 P600
Heavy pilot duty A600 A600 A600
General use 10 A - 600 V a.c
Ampere rating
Non inductive and slightly inductive loads - 10 10
Short-circuit rating
Max. fuse gL characteristic A - 16 16
Terminal capacity
Solid or stranded AWG - 12 12
Flexible without ferrule AWG - 14 14
Devices for world markets IEC, UL/CSA
187EATON P Switch-disconnectors and T Rotary cam switches CA042001EN
Technical data
TM Mini cam switches
TM
General
Standards IEC/EN 60947, VDE 0660, CSA, UL
Control switch to IEC/EN 60947-5-1
Control circuit isolators to IEC/EN 60947-5-1
Control circuit isolator (IEC/EN 60947-5-1) Max 6 contacts, switching angle 90
o
Lifespan mechanical Operations x 10
6
>1
Maximum operating frequency Operations/h 3000
Climatic proofing Damp heat. constant to IEC 60068-2-78;
Damp heat, cyclic to IEC 60068-2-30
Ambient temperature
(for derating information contact buletechnical@eaton.com)
Open
o
C -25 -50
Enclosed
o
C -25 -40
Mounting position Any
Contacts
Mechanical data
Contacts Number Max. 16
Contacts units (BE) Max 8
Switching angle
o
90, 60, 45, 30
Smallest switching angle for ON-OFF-ON
o
60
Max switch position ≤ ≤12
Electrical characteristics
Rated operational voltage U
e
V a.c. 500
Rated impulse withstand voltage U
imp
V a.c. 4000
Overvoltage category/pollution degree III/3
Rated insulation voltage Ui V a.c. 500
Rated insulation voltage to UL/CSA V a.c. 300
Rated conditional short-circuit current Load side I
q
kA 0
Supply side I
q
kA -
Rated uninterrupted current I
u
A 10
Switching capacity
AC-23 motor load switch 230 V a.c. 3-pole kW 1.8
440 V a.c. 3-pole kW 3
230 V a.c. 1-pole kW 0.75
440 V a.c. 1-pole kW 1.1
AC-15 control switch 230 V a.c. 1-pole A 2.5
400 V a.c. 1-pole A 1.5
440 V a.c. 1-pole A 1
DC-13, control switch L/R = 50 ms Rated operational current I
e
I
e
A 3
Voltage per contact connected in series V 32
Switching capacity (UL489, CSA 22.2 No 5.1) 240 V a.c. 3-pole HP 1
277 V a.c. 1-pole HP ¾
300 V a.c. Heavy-duty A 10
Max short-circuit protection device
Fuse A gG/gL 10
Terminal capacity
Solid or stranded mm
2
1 x 1.5 / 2 x 1.5
Flexible without ferrule mm
2
1 x 1.5 / 2 x 1.5
Solid or stranded AWG 1 x 14 / 2 x 14
Flexible AWG 1 x 16 / 2 x 16
Terminal screw M2.5
Tightening torque Nm 0.35
188
