F lush m o u nt in g - On- O f f sw itc h- dis connec to rs w ith au xilia ry contac t s Number of poles Auxili ar y contact s Su it abl e fo r ex po r t to No r th A mer ic a (U S an d Canada) Padlockable handle Front p…
Flush mounting - On-Off switch-disconnectors without auxiliary contacts
Front
plate
Number
of poles Suitable for
export to
North America
(US and
Canada)
Padlockable
handleContact sequence
Rated
current Part number
Article
number
Pack
qty
1 20 A T0-1-8200/E-RT 009474 1
X
32 A T3-1-8200/E-RT 017025 1
X
63 A T5B-1-8200/E-RT 094280 1
X
100 A T5-1-8200/E-RT 097225 1 X X
2 20 A T0-1-102/E-RT 009046 1
X
32 A T3-1-102/E-RT 016318 1
X
63 A T5B-1-102/E-RT 094470 1
X
3 20 A T0-2-1/E-RT 011082 1
X
25 A P1-25/E-RT 002388 1
X
32 A P1-32/E-RT 003197 1
X
40 A P1-40/E-RT 199902 1 X X
63 A P3-63/E-RT 005743 1
X
80 A P3-80/E-RT EP-400932 1
X
100 A P3-100/E-RT 007189 1
X
3 + N 20 A T0-2-8900/E-RT 207399 1
X
Panic switch-disconnector fitted with a SVA Cylinder lock
Supplied with two keys
3 20 A T0-2-1/E/SVA(S)-RT 228291 1
3 25 A P1-25/E/SVA(S)-RT 050967 1
3 32 A P1-32/E/SVA(S)-RT 050971 1
Panic switch-disconnectors fitted with SVC Padlocking feature
Supplied with two keys
If the locking device is padlocked in position 1 the switch can be switched off but not on again without removing the padlock.
Lockable with max 3 padlocks
3 20 A
T0-2-1/E/SVC(S)-RT 044973 1
3 25 A
P1-25/E/SVC(S)-RT 044974 1
3 32 A
P1-32/E/SVC(S)-RT 044975 1
FS 908
ON
OFF
1
2
01
1
2
3
4
01
1
2
3
4
5
6
01
1
2
3
4
5
6
7
8
01
207399
N/O
1
2
3
4
5
6
01
FS 908 GE
1
0
044975
With emergency switch o/emergency stop function
1
2
3
4
5
6
01
FS 908 GE
1
0
050967
