1 Saf e sw it c hin g , i s o lat in g an d co nt r o l The high -pe r f or mance , ro bust and c omp act T R ota r y Cam S w itc hes and P S w itc h -disco nnecto rs are used in mac hine b uildin g , in dust r ial and e…
EPLAN is one of the world’s leading design software solutions for machine, plant and panel builders.
You will find in EPLAN all the Eaton’s Switch-disconnectors data you need to safely and efficiently build your panel:
• Product images
• Schematic symbols
• 2D DXF Images
• Weights, dimensions, cable size, torque
settings, catalogue data, electrical parameters
• List of accessories
• 3D Intelligent step files:
• Wiring connection points
• Drill hole patterns
• Mounting faces
Eaton’s Switch-disconnectors
data is available in EPLAN
EPLAN
E
l
e
c
t
r
i
c
a
l
s
c
h
e
m
a
t
i
c
C
u
s
t
o
m
e
r
n
e
e
d
s
B
i
l
l
o
f
m
a
t
e
r
i
a
l
D
e
s
i
g
n
2
EATON P Switch-disconnectors and T Rotary cam switches CA042001EN
1
Safe switching, isolating and control
The high-performance, robust and compact T Rotary Cam
Switches and P Switch-disconnectors are used in machine
building, industrial and engineering applications.
They provide ultimate safe disconnection and endurance with
positive mechanical contact breaking and excellent making &
breaking capabilities. Their IP65 degree of protection enables
use in harsh environments, and with essential global approvals
the T & P range is a perfect switching, isolating and control
solution.
P & T switches are available in an extensive range of complete
pre-built switch/handle and enclosure combinations ex-stock to
suit the specific requirements of our customers. This saves
valuable time in the customer’s assembly process as well as
reducing packaging waste and order administration.
T rotary cam switches are suitable for a wide range of industrial
and machine control applications: change-over and step switches,
star-delta and reversing switches, etc. Several thousand
switching types are available as standard, and customised circuits
can also be produced to meet specific customers’ needs, contact
buletechnical@eaton.com for further information.
3EATON P Switch-disconnectors and T Rotary cam switches CA042001EN
Table of contents
P Rotary cam switches overview 6
T Rotary cam switches overview 10
Flush mounting switch-disconnectors 16 - 46
Description 16
Range overview 17
On-Off switch-disconnectors 18
Main switch-disconnectors 24
Changeover switch-disconnectors 28
Coding switch-disconnectors 32
Manual/auto switch-disconnectors 33
Multi speed switch-disconnectors 34
Reversing switch-disconnectors 35
Selector switch-disconnectors 37
Star delta switch-disconnectors 38
Step switch-disconnectors 39
Step switch-disconnectors for heating 43
Universal control switch-disconnectors 44
Accessories 45
Centre mounting switch-disconnectors 47 - 67
Description 47
Range overview 48
On-Off switch-disconnectors 49
Changeover switch-disconnectors 52
Coding switch-disconnectors 55
Control switch-disconnectors 56
Group switch-disconnectors 57
Manual/auto switch-disconnectors 58
Multi speed switch-disconnectors 59
Reversing switch-disconnectors 60
Reversing star delta switch-disconnectors 61
Selector switch-disconnectors 62
Step switch-disconnectors 63
Step switch-disconnectors for heating 67
Rear mounting switch-disconnectors 68 - 94
Description 68
Range overview 69
On-Off switch-disconnectors 70
Main switch-disconnectors 73
Main switch-disconnectors with 400 mm metal extension shaft 77
Changeover switch-disconnectors 81
Manual/auto switch-disconnectors 83
Multi speed switch-disconnectors 84
Reversing switch-disconnectors 85
Selector switch-disconnectors 86
