Centre mounting switch-disconnectors Description Cent re mo unt ing s w itch - d isco nne c tor s ca n be ea sil y ins t all ed , usin g 22. 5 mm sin gl e- ho le m ount ing , o nto do or s, p ane ls , lids , enc los ures…
Flush mounting dedicated accessories
Flush mounting to centre mounting convertor
•
For single hole fitting 22.3 mm
•
To convert a Flush mounting switch into a Centre mounting switch
Description
Part
number
Article
number
Std.
pack
Suitable for
export to
North America
(US and
Canada)* Suitable for Mounting
For cam switches with existing front plate - quick
installation with snap fitting system
EZ-T0 081622 1
T0, T3 Flush mounting /E
Mounting diameter 22.3 mm, one man mounting with
screw fixing
EZ-P1 091455 1
TO, T3, P1 Flush mounting /E
* UL/CSA certication not required
081622 091455
Shrouds
Description Part number
Article
number
Std.
pack
Suitable for export
to North America
(US and Canada)* Suitable for Mounting
For flush mounting switches with up to 4 contact units
Cable entries
Quantity: 2 x Ø 20 mm + 2 x Ø 15 mm
Cross section: 5 x 6 mm
2
, 5 x 2.5 mm
2
H3-T0 093828 1
TO, T3 Flush mounting /E
* UL/CSA certication not required
093828
Description
Number of
contact units Part number
Article
number
Std.
pack
Suitable for
export to
North America
(US and
Canada) Suitable for Mounting
IP65 insulated enclosure - With metric
knockouts
1-2 CI-K4-T5B-2* 207439 1
T5B Flush mounting /E
IP65 Insulated enclosures
* For converting T5../Z into T5-../I5 and T5B-../E into T5B-.../I4, order AW-T5-... extension terminal additionally. 1 contact unit = 2 contacts
Product standards UL 60947-4-1
CSA - C22-.2 No 14-05, CSA - C22-2 No 94
IEC/EN 60947-3
CE Marking
UL File No E54120
UL CCN MITW2
CSA File No 12528
CSA Class No 3211-07
NA Certification UL Listed, CSA Certified
Degree of protection IEC: IP65
UL/CSA Type 1, 3R, 4X, 12, 13 - indoor and outdoor
use
207439
Photos are representative
46
EATON P Switch-disconnectors and T Rotary cam switches CA042001EN
Centre mounting switch-disconnectors
Description
Centre mounting switch-disconnectors can be easily installed,
using 22.5 mm single-hole mounting, onto doors, panels, lids,
enclosures in machinery. switchboard and switchgear.
Standards/Approvals
See details page 178
Technical data
•
Voltage: 690 V a.c.
•
Current: 10 A to 40 A
•
Mounting method: 22.5 mm single-hole mounting
Features
•
Available with or without emergency switching off/emergency stop
function
•
Available with and without auxiliary contacts
•
Available with red rotary handle and yellow locking collar and black
rotary handle and locking collar
•
1-pole to 8-pole options
TM Center
mounting
T0 Center mounting
Photos are representative
47EATON P Switch-disconnectors and T Rotary cam switches CA042001EN
Centre mounting - Range overview
Rated current 10 A 20 A 25 A 32 A 40 A
On-Off switch-disconnectors TM T0 P1 P1 T3 P1
Without auxiliary contacts
With auxiliary contacts
Changeover swtich-disconnectors TM T0 T3
Without auxiliary contacts
Coding switch-disconnectors TM
Without auxiliary contacts
Control switch-disconnectors T0
Without auxiliary contacts
Heater switch-disconnectors T0
Without auxiliary contacts
Group switch-disconnectors TM
Without auxiliary contacts
Manual/auto switch-disconnectors TM T0
Without auxiliary contacts
Multi speed switch-disconnectors T0 T3
Without auxiliary contacts
Reversing switch-disconnectors T0 T3
Without auxiliary contacts
Reversing star delta switch-disconnec-
tors
T0 T3
Without auxiliary contacts
Selector switch-disconnectors T0
Without auxiliary contacts
Step switch-disconnectors TM T0
Without auxiliary contacts
48
