T ab le o f co nte nts Rear mounting switch- disconnector s 68 - 9 4 Star delta switch-disconnectors 87 Step switch-disconnectors 88 Universal switch-disconnectors for heating 90 Accessories 91 Ser vice distribution boar…
Table of contents
P Rotary cam switches overview 6
T Rotary cam switches overview 10
Flush mounting switch-disconnectors 16 - 46
Description 16
Range overview 17
On-Off switch-disconnectors 18
Main switch-disconnectors 24
Changeover switch-disconnectors 28
Coding switch-disconnectors 32
Manual/auto switch-disconnectors 33
Multi speed switch-disconnectors 34
Reversing switch-disconnectors 35
Selector switch-disconnectors 37
Star delta switch-disconnectors 38
Step switch-disconnectors 39
Step switch-disconnectors for heating 43
Universal control switch-disconnectors 44
Accessories 45
Centre mounting switch-disconnectors 47 - 67
Description 47
Range overview 48
On-Off switch-disconnectors 49
Changeover switch-disconnectors 52
Coding switch-disconnectors 55
Control switch-disconnectors 56
Group switch-disconnectors 57
Manual/auto switch-disconnectors 58
Multi speed switch-disconnectors 59
Reversing switch-disconnectors 60
Reversing star delta switch-disconnectors 61
Selector switch-disconnectors 62
Step switch-disconnectors 63
Step switch-disconnectors for heating 67
Rear mounting switch-disconnectors 68 - 94
Description 68
Range overview 69
On-Off switch-disconnectors 70
Main switch-disconnectors 73
Main switch-disconnectors with 400 mm metal extension shaft 77
Changeover switch-disconnectors 81
Manual/auto switch-disconnectors 83
Multi speed switch-disconnectors 84
Reversing switch-disconnectors 85
Selector switch-disconnectors 86
4
EATON P Switch-disconnectors and T Rotary cam switches CA042001EN
Table of contents
Rear mounting switch-disconnectors 68 - 94
Star delta switch-disconnectors 87
Step switch-disconnectors 88
Universal switch-disconnectors for heating 90
Accessories 91
Service distribution board mounting switch-disconnectors 95 - 113
Description 95
Range overview 96
On-O switch-disconnectors 97
Changeover switch-disconnectors 101
Coding switch-disconnectors 103
Manual/auto switch-disconnectors 104
Multi speed switch-disconnectors 105
Reversing switch-disconnectors 106
Selector switch-disconnectors 107
Star delta switch-disconnectors 108
Step switch-disconnectors 109
Step switch-disconnectors for heating 111
Universal control switch-disconnectors 112
Accessories 113
Enclosed switch-disconnectors 114 - 152
Description 114
Range overview 115
On-O switch-disconnectors 116
Main switch-disconnectors 124
Changeover switch-disconnectors 135
Coding switch-disconnectors 139
Manual/auto switch-disconnectors 140
Multi speed switch-disconnectors 141
Reversing switch-disconnectors 142
Safety switch-disconnectors 143
Selector switch-disconnectors 146
Star delta switch-disconnectors 147
Step switch-disconnectors 148
Step switch-disconnectors for heating 149
Universal control switch-disconnectors 150
Accessories 151
Universal accessories 153
Non standard cam switches and switch-disconnectors 164
Standards 178
Characteristic curves 182
Technical data 183
Dimensions 194
Index 209
5EATON P Switch-disconnectors and T Rotary cam switches CA042001EN
P Switch-disconnectors - Overview
P1 P3 P5
Rated current (Amps) 25 32 40 63 80 100 125 160 250 315
Rated voltage (V a.c.) 690 690 690 690 690 690 690 690 690 690
Max motor rating AC-23A, 400/415 V, 50/60 Hz 13 kW 15 kW 15 kW 37 kW 50 kW 45 kW 55 kW 90 kW 110 kW
Switch-disconnectors type
Main switches maintenance/manual override switches
On-Off switches
Safety switches with warning labels
Switches with interlocks type
With cylinder lock SVA
With padlocking feature SVC
On-Off switch without emergency stop function
Mounting forms
‘E’ Flush mounting
‘EA/SVB’ Flush mounting main switch
‘EZ’ Centre mounting
‘Z’ Rear mounting
‘V/SVB’ Rear mounting main switches
‘M4/SVB’ Rear mounting main switches with extension
shaft
‘IVS’ Service distribution board mounting
‘I’ Surface mounting switch-disconnector fitted in Ci-K
Enclosure
‘MBS’ Surface mounting switch-disconnector fitted in
Ci-K Enclosure, with pre-assembled EMC screen
‘SE’ Surface mounting fitted in steel enclosures
Range overview by switch-disconnectors type and mounting forms
System overview
1. Service distribution board mounting
2. Rear mounting
3. Flush mounting
4. Neutral conductors, auxiliary
contacts
5. Surface mounting
6. Main switch (kit) for use as emer-
gency switching o device
7. Main switch (kit)
8. Thumb grip for use as emergency
switching o device
9. Thumb grip
10. Coupling drive
P1 and P3 Swtich-disconnectors
6
EATON P Switch-disconnectors and T Rotary cam switches CA042001EN
