Service distribution board mounting switch-disconnectors Description Se r v ice di st ri bu tio n bo ard s wi tch - di scon nec tor s ca n be ea sil y ins t all ed d irec t l y onto t he DI N- R ail in sid e the d is tr …
Rear mounting dedicated accessories
Description
Number of
contact units Part number
Article
number
Std.
pack
Suitable for
export to
North America
(US and
Canada) Suitable for Mounting
IP65 insulated enclosure - With push-through
cable entry diaphragm*
1-2 CI-K1-T0-2 207435 1
X TO Rear mounting /Z
3-4 CI-K1-T0-4 207436 1
X
1-2 CI-K2-T3-2 207437 1
T3 Rear mounting /Z
3-4 CI-K2-T3-4 225325 1
5 CI-K2-T3-5 207438 1
IP65 insulated enclosure - With metric
knockouts
1-2 CI-K1H-T0-2 105854 1
X T0 Rear mounting /Z
3-4 CI-K1H-T0-4 105855 1
X
1-2 CI-K2H-T3-2 269462 1
X T3 Rear mounting /Z
3-4 CI-K2H-T3-4 105859 1
X
5 CI-K2H-T3-5 105860 1
X
3-4 CI-K4-T5B-4** 207440 1
T5B Rear mounting /Z
1-2 CI-K5-T5-2** 207441 1
T5 Rear mounting /Z
3-4 CI-K5-T5-4** 207442 1
IP65 Insulated enclosures
* The diaphragm can be pierced with the cable. 1 contact unit = 2 contacts.
** For converting T5../Z into T5-../I5 and T5B-../E into T5B-.../I4, order AW-T5-... extension terminal additionally. 1 contact unit = 2 contacts
Product standards UL 60947-4-1, CSA - C22-.2 No 14-05, CSA - C22-2 No 94
IEC/EN 60947-3, CE Marking
UL File No E54120
UL CCN MITW2
CSA File No 12528
CSA Class No 3211-07
NA Certification UL Listed, CSA Certified
Degree of protection IEC: IP65
UL/CSA Type 1, 3R, 4X, 12, 13 - indoor and outdoor use
207435 / 207436
105855 /
207437 / 269462
105859 / 105860
225325
207438
105854
207440 207441
Photos are representative
94
EATON P Switch-disconnectors and T Rotary cam switches CA042001EN
Service distribution board mounting switch-disconnectors
Description
Service distribution board switch-disconnectors can be easily
installed directly onto the DIN-Rail inside the distribution board
enclosure.
Standards/Approvals
See details page 178
Technical data
•
Voltage: 690 V a.c.
•
Current: 10 A to 100 A
Features
•
Available with or without emergency switching off/emergency stop
function
•
Available with and without auxiliary contacts
•
Available with red rotary handle and yellow locking collar and black
rotary handle and locking collar
•
1-pole to 8-pole options
T0 Service distribution
board mounting
T0 Service distribution
board mounting
Photos are representative
95EATON P Switch-disconnectors and T Rotary cam switches CA042001EN
Service distribution board mounting - Range overview
Rated current 10 A 20 A 25 A 32 A 40 A 63 A 100 A
On-Off switch-disconnectors T0 P1 P1 P1 P3 P3
Without auxiliary contacts
With auxiliary contacts
Changeover swtich-disconnectors T0
Without auxiliary contacts
Coding switch-disconnectors T0
Without auxiliary contacts
Heater switch-disconnectors T0
Without auxiliary contacts
Manual/auto switch-disconnectors TM T0
Without auxiliary contacts
Multi speed switch-disconnectors T0
Without auxiliary contacts
Reversing switch-disconnectors T0
Without auxiliary contacts
Selector switch-disconnectors T0
Without auxiliary contacts
Star delta switch-disconnectors T0
Without auxiliary contacts
Step switch-disconnectors T0
Without auxiliary contacts
Universal switch-disconnectors T0
Without auxiliary contacts
