10 4. Conveyor Unit Section 4-2. PCB Stopper 5 7 6 5 4 3 8 10 2 9 1 12 5 7 6 5 4 4 4 4 4 4 4 4 3 8 10 2 9 1 12 No. Part No. Part Name Q'ty Remarks Rank Level 1 LE2-M9402-01 BLOCK,STOPPER 1 / × 2 LE2-M9409-00 BRACKET…
9
4. Conveyor Unit Section
4-1. Conveyor, Side Clamp
No. Part No. Part Name Q'ty Remarks Rank Level
1 LE2-M90B3-40 BELT,CONV. 1 / ×
2 LE2-M90C0-00 CYLINDER ASSY 3 / ×
3 LE2-M90C1-00 CYLINDER 1 / ×
4 LE2-M6523-01 W MOTOR ASSY. 1 / ×
5 LC2-M9130-00 DC MOTOR COMB. TYPE 1 / ×
6 LE2-M6531-00 SENSOR ASSY. 1 / ×
7 LE2-M6532-00 SENSOR ASSY. 1 / ×
8 LE2-M6539-00 SENSOR ASSY. 1 / ×
9 LE2-M653A-00 SENSOR ASSY. 1 / ×
10 LE2-M90E0-00 VALVE ASSY 1 / ×
11 $UT4M JOINT 6 / ○
12 $USD6-4M JOINT 1 / ○
13 $UT-6M JOINT 1 / ○
14 LE2-M9029-00 JOINT A 1 / ×
15 LE2-M902A-00 JOINT B 1 / ×
16 LE2-M902B-00 SHAFT A 1 / ×
17 LE2-M900T-01 BRKT,SENSOR 1 / ×
18 LE2-M900U-01 BRKT,SENSOR 1 / ×
19 LE2-M900V-00 BRKT,SENSOR 2 / ×
20 LE2-M90D0-00 CYLINDER ASSY 2 Side Clamp / ×
21 LG0-M99B1-00 REGURATOR 1 / ○
22 $UY4M FITTING 1 / ×
23 LG3-M26C4-00 SOLENOIDVALVE 1 / ×
24 $TL6-01 JOINT 1 / ×
25 LG0-M90AK-00 MUFFLER 2 / ×
26 $SC4-01A CTRL,SPEED 2 / ×
27 LE2-M90C1-00 CYLINDER 1 / ×
28 $TL4-M5M JOINT 2 / ×
29 $TSH4-M5M JOINT 2 / ×
30 LE2-M90D1-00 CYLINDER 1 Side Clamp / ×
31 LE2-M90D2-01 JOINT 1 Side Clamp / ×
10
4. Conveyor Unit Section
4-2. PCB Stopper
5
7
6
5
4
3
8
10
2
9
1
12
5
7
6
5
4
4
4
4
4
4
4
4
3
8
10
2
9
1
12
No. Part No. Part Name Q'ty Remarks Rank Level
1 LE2-M9402-01 BLOCK,STOPPER 1 / ×
2 LE2-M9409-00 BRACKET,SENSOR 1 / ×
3 LE2-M940A-00 AIR CYLINDER 1 / ×
4 $TL4-01M JOINT 2 / ○
5 LG3-M26C4-00 SOLENOIDVALVE 1 / ○
6 $TL6-01 JOINT 1 / ○
7 LG0-M90AK-00 MUFFLER 2 / ○
8 $SC4-M5A SPEED CONTROLLER 2 / ×
9 LE2-M9407-01 STAY,SENSOR 1 / ×
10 LE2-M9408-00 BRACKET,SENSOR 1 / ×
11 LE2-M6535-00 SENSOR ASSY. 1 / ×
12 LE2-M26H1-01 PHOTO SENSOR 2 / ×
13 LE2-M6538-00 SENSOR ASSY. 1 / ×
11
4. Conveyor Unit Section
4-3. Shatter
3
2
4, 5
1
3
2
4, 5
1
No. Part No. Part Name Q'ty Remarks Rank Level
1 $TS4-01M JOINT 4 / ×
2 $TL6-01 JOINT 2 / ×
3 LG0-M90AK-00 MUFFLER 4 / ×
4 LE2-M6544-00 SHT(R) SV ASSY 1 / ×
5 LE2-M6545-00 SHT(L) SV ASSY 1 / ×
