12 4. Conveyor Unit Section 4-4. PCB Guide 4 3 1 2 8 7 9 5 6 4 3 1 2 8 7 9 5 6 No. Part No. Part Name Q'ty Remarks Rank Level 1 LE2-M9605-00 BLOCK,PCB 1 (R Type) / ○ 2 LE2-M9605-10 BLOCK,PCB 1 (L Type) / ○ 3 LE2-M96…
11
4. Conveyor Unit Section
4-3. Shatter
3
2
4, 5
1
3
2
4, 5
1
No. Part No. Part Name Q'ty Remarks Rank Level
1 $TS4-01M JOINT 4 / ×
2 $TL6-01 JOINT 2 / ×
3 LG0-M90AK-00 MUFFLER 4 / ×
4 LE2-M6544-00 SHT(R) SV ASSY 1 / ×
5 LE2-M6545-00 SHT(L) SV ASSY 1 / ×
12
4. Conveyor Unit Section
4-4. PCB Guide
4
3
1
2
8
7
9
5
6
4
3
1
2
8
7
9
5
6
No. Part No. Part Name Q'ty Remarks Rank Level
1 LE2-M9605-00 BLOCK,PCB 1 (R Type) / ○
2 LE2-M9605-10 BLOCK,PCB 1 (L Type) / ○
3 LE2-M9606-00 BLOCK,PCB 1 (R Type) / ○
4 LE2-M9606-10 BLOCK,PCB 1 (L Type) / ○
5 LE2-M9607-00 PLATE,PCB 2 / ○
6 LE2-M960A-00 LEAF SPRING,PCB 2 / ○
7 LE2-M96A1-00 GRIP 2 / ○
8 90990-33J035 BOLT STOPPER 2 / ○
9 90990-28J120 WASHER,PLAIN 2 / ○
13
5. Marker Pen Unit Section (Option)
5-1. Marker Pen Unit (Option)
13
18
14,15
20
19
16,17
21
11
12
5
7
6
4
8
10
9
1
3
2
13
18
14,15
20
19
16,17
21
11
12
5
7
6
4
8
10
9
1
3
2
No. Part No. Part Name Q'ty Remarks Rank Level
1 LE2-M7409-00 HOLDER,PEN(L) 1 / ○
2 LE2-M740A-00 PIN,HINGE 1 / ○
3 90990-47J008 KNURLED KNOB 1 / ○
4 LE2-M740J-00 AIR CYLINDER 1 / ○
5 LE2-M740P-00 AIR CYLINDER 1 / ○
6 LE3-M51A3-00 JOINT,FLEXIBLE 1 / ○
7 $SC4-M5A SPEED CONTROLLER 4 / ○
8 $TS4-M5M JOINT 4 / ○
9 99001-05600 CIRCLIP(E) 1 / ○
10 LG0-M90AK-00 MUFFLER 1 / ○
11 $TL6-01 JOINT 1 / ○
12 LG0-M90AP-00 PLUG 2 / ○
13 LE1-M5107-00 ADPTER 1 / ○
14 LE3-M51D1-20 PEN MARKER(LR) 1 RED / ○
15 LE3-M51D1-30 PEN MARKER(LB) 1 BLUE / ○
16 LE3-M51D2-20 PEN MARKER(SR) 1 RED / ○
17 LE3-M51D2-30 PEN MARKER(SB) 1 BLUE / ○
18 90200-00J11A O-RING 1 (L) / ○
19 90200-00J050 O-RING 1 (S) / ○
20 LE2-M740S-00 CAP(L) 1 / ○
21 LE2-M740S-01 CAP(S) 1 / ○
