4. Test Print and Automatic Operation

4.1 Test Print

Print a PCB in each of backward and forward printing mode, and check the print

result. If any positional deviation is found, correct the parameters for "Printing

Correction (Back)" and "Printing Correction (For.)" in the "Print" tab sheet in the

"Pattern Program" edit window.

Note

The correction of inaccurate position data can be performed using the teaching

operation.

Reference

Refer to "7.1 Inaccurate Posn. Correction" in "Chapter 3 (Vol. 2)" for details.

4.2 Automatic Operation

Display the "Product." window on the touch screen and press the [START] button

on the operation panel to start the PCB production.

1OM-1505

4-20

4. Test Print and Automatic Operation : Chap.4

1002-001

1OM-1505

1103-003 5-A

Chapter 5

Basic Information

This chapter describes the basic information.

1. Specications

2. Option

3. Specications of Printing Stencil Plate Making

4. Fiducial Marks

5. Measured Noise Value
