1OM-1505
3. Specifications of Printing Stencil Plate Making : Chap.5
5-16
3. Specifications of Printing Stencil Plate Making
(1) Stencil Frame Size: 750 × 750 mm
570
or more
40
15
085
057
375 ± 1
04
51
750
50
Max. 460 (PCB Size)
50
145 ± 1 (Based on Frontr Reference Point)
Stencil Side
Stencil Plate Center
Stencil Plate Rear Reference Point
Stencil Plate Front Reference Point
Mesh
Metal
Aluminum
Box Tubing
Metal Size 600 or more
Metal Size 610 or more
Max. 510 (PCB Size)
Margin for Paste
(Front Side of Machine)
375 ± 1 (Based on Center Reference Point)
605 ± 1 (Based on Rear Reference Point)
30 to 40
Unit: mm
F1E1
Note
(a) The two-dot chain line shows the external shape of the PCB.
(b) If combined with metal, the metal (600
×
610 mm)
should be located as
shown in F1E1.
1103-003
1OM-1505
3. Specifications of Printing Stencil Plate Making : Chap.5
5-17
(2) Stencil Frame Size: 736 × 736 mm
570 or more
105
637
368 ± 1
736
40
15
51
50
50
04
Stencil Side
Stencil Plate Center
Stencil Plate Rear Reference Point
Stencil Plate Front Reference Point
Mesh
Metal
Metal Size 600 or more
Metal Size 531 or more
Max. 381 (PCB Size)
177.5 ± 1
(Based on Frontr Reference Point)
Aluminum
Box Tubing
Max. 490 (PCB Size)
Margin for Paste
(Front Side of Machine)
368 ± 1 (Based on Center Reference Point)
558.5 ± 1 (Based on Rear Reference Point)
30 to 40
Unit: mm
F1E2
Note
(a) The two-dot chain line shows the external shape of the PCB.
(b) If combined with metal, the metal (600
×
531 mm)
should be located as
shown in F1E2
1103-003
1OM-1505
3. Specifications of Printing Stencil Plate Making : Chap.5
5-18
(3) Stencil Frame Size: 720 × 720 mm
045
027
360 ± 1
720
40
15
04
51
50
50
Stencil Plate Center
Stencil Plate Rear Reference Point
Stencil Plate Front Reference Point
Mesh
Metal
Metal Size 570 or more
Metal Size 570 or more
540 or more
Stencil Side
Max. 381 (PCB Size)
169.5± 1
(Based on Frontr Reference Point)
Aluminum
Box Tubing
Max. 470 (PCB Size)
Margin for Paste
(Front Side of Machine)
360 ± 1 (Based on Center Reference Point)
550.5 ± 1 (Based on Rear Reference Point)
30 to 40
Unit: mm
F1E3
Note
(a) The two-dot chain line shows the external shape of the PCB.
(b) If combined with metal, the metal (570
×
570 mm)
should be located as
shown in F1E3
1103-003
