5. Measured Noise Value
[Measurement Condition]
•
Measuring Position
Position 1 m away and 1.6 m in height from the machine (Both Front and Rear
Sides of Machine)
•
Noise Measuring Instrument
RION Model : NA-60
Results of Measurement:
Max. 68.0 [dB] (Measuring Point b) Background Noise:
40.0 [dB]
Requirements for
Machine Operation
Measured Noise Value [db]
Remarks
Normal Operation
Measuring Point a
67.2 [dB]
•
Temperature 25.5°C
Measuring Point b
65.0 [dB]
Measuring Point c
68.0 [dB]
Measuring Point d
65.8 [dB]
T1E9
1OM-1505
5. Measured Noise Value : Chap.5
5-301103-001
1OM-1505
1103-002 6-A
Chapter 6
Accompanying Materials
This chapter describes the specications of the backup jig.
1. Specications of Backup Jig Making
2. Assembling Table
3. PCB Backup Jig (PCB Width W "250<=W<=460")
4. PCB Backup Jig (PCB Width W "65<=W<250")
5. PCB Backup Jig (PCB Width W "50<=W<65")
6. PCB Vacuum Jig (PCB Width W "250<=W<=460")
7. PCB Vacuum Jig (PCB Width W "65<=W<250")
8. PCB Vacuum Jig (PCB Width W "50<=W<65")
