Chapter 6

Accompanying Materials

This chapter describes the specications of the backup jig.

1. Specications of Backup Jig Making

2. Assembling Table

3. PCB Backup Jig (PCB Width W "250<=W<=460")

4. PCB Backup Jig (PCB Width W "65<=W<250")

5. PCB Backup Jig (PCB Width W "50<=W<65")

6. PCB Vacuum Jig (PCB Width W "250<=W<=460")

7. PCB Vacuum Jig (PCB Width W "65<=W<250")

8. PCB Vacuum Jig (PCB Width W "50<=W<65")

1OM-1505

0906-001 6-B

1OM-1505

1. Specications of Backup Jig Making : Chap.6

6-1

1. Specications of Backup Jig Making

It is required to make a PCB backup jig or a vacuum jig in accordance with the

PCB width and the condition of the PCB when printing is performed, using the

backup jig.

PCB Backup Jig

The whole area (back side) of the PCB must be supported by one block. When the

back of the PCB does not have any protuberance, this jig can be used effectively.

•

PCB Backup Jig (PCB Width W "250<=W<=460")

Reference

Refer to "3. PCB Backup jig (PCB Width W "250<=W<=460")" for details.

•

PCB Backup Jig (PCB Width W "65<=W<250")

Reference

Refer to "4. PCB Backup jig (PCB Width W "65<=W<250")" for details.

•

PCB Backup Jig (PCB Width W "50<=W<65")

Reference

Refer to "5. PCB Backup jig (PCB Width W "50<=W<65")" for details.

PCB Vacuum Jig

The PCB is absorbed and clamped. This is applicable for a thin or a warped PCB.

Note

When a PCB has many through holes, it may not be picked up. In this

case,consult the marketing department or sales agency of Hitachi High-

Technologies for details.

•

PCB Vacuum Jig (PCB Width W "250<=W<=460")

Reference

Refer to "6. PCB Vacuum Jig (PCB Width W "250<=W<=460")" for details.

•

PCB Vacuum Jig (PCB Width W "65<=W<250")

Reference

Refer to "7. PCB Vacuum Jig (PCB Width W "65<=W<250")" for details.

•

PCB Vacuum Jig (PCB Width W "50<=W<65")

Reference

Refer to "8. PCB Vacuum Jig (PCB Width W "50<=W<65")" for details.
