1OM-1505
6-16
5. PCB Backup Jig (PCB Width W "50<=W<65") : Chap.6
5.4 Variant Drawing for the Component Section (P/N 23-2).
Q-M5 Depth 15
D C
14
34
25.5
2±0.05
6.5±0.05
5
9
+0.3
0
2-13.2
A
TX
10±0.05
S 120±0.03
+0.2
0
F3.6 Depth 8
+0.1
0
2-F3.9 Depth 8
+0.03
0
Z
23-2
Material : A5052
Processing : None
1.6
F1F12
1103-002
1OM-1505
6. PCB Vacuum Jig (PCB Width W "250<=W<=460") : Chap.6
6-17
6. PCB Vacuum Jig (PCB Width W "250<=W<=460")
6.1 Dimension Table
1103-002
W 460 to 250
P W – 41
I W/4 – 13.5
M W/2 – 20
N W/4 – 13.5
L 510 to 420 420 to 332 332 to 262 262 to 204 204 to 142 142 to 92 92 to 50
A 416 L - 4 200
C 360 290 230 166 120 56 30
D 28
L/2 – 147 L/2 – 117 L/2 – 85
40 7
2 85
E L/2 – 182 L/2 – 62 L/2 – 37 L/2 – 17
F 20
8 L/2 – 2 100
S 148 L/2 – 62 40
X 43
L/2 – 132 L/2 – 102 L/2 – 41 61
T 330
260 200 78 78
U L/2 – 1
7
Q 6 4
Z 193 L/2 – 1
7
H L/4 – 13.5
J L/2 – 1
7
K L/2 – 12
R
L/2 – 210
G 416
TT 8
15
T1F4
W : PCB Width
L : PCB Length
1OM-1505
6-18
6. PCB Vacuum Jig (PCB Width W "250<=W<=460") : Chap.6
6.2 Assembly Diagram
Magnets HXU13 (MISUMI)
X4
4-M4L15
*
4 4 4
1.6
R
The two-dot chain line shows the state that the PCB is positioned.
11-4
11-2
11-1
11-3
S1
Q-M5L35
( )
4
CD
E
L/2-2
20
K
U
Z
20
20 N
20M20
9
1
8 18 18
17P
W-7
W
9
8±0.05
55±0.03
30
TT
1
H J 20
8.5
6.5
6.5
5
9
9
11
L/2-2
F
R G
120±0.03S
TX
L-4
L
A
Notes : (a) The part with the P/N S-1 is a part to be purchased.
(b) After assembling each component, process the R-surface so that
the * marked dimensions are met.
(c) The part with the P/N 21-4 and 21-5 are attached after
the processing of R-surface.
(d) The part No. 21-5 is not used for model PXH-1, TPM-100 series,
TPM-200 or TPM-5000.
F12
21-5
Positioning Pin (2 locations) Bonding with LOCTITE
21-4
2-C0.5
2-C0.5
F3.9g6
F3.6
0
-0.1
Material : SUS304
Processing : None
Material : SUS304
Processing : None
12
12
Note d
F1F13
1103-001
