1OM-1505 6-26 7. PCB V acuum Jig (PCB Width W "65<=W<250") : Chap.6 7.4 V ariant Drawing for the Component Section (P/N 12-2). 0.03 A A 0.03 12-2 Material : A5052 Processing : None 2-C1 Fine Chamfering (F…

100%1 / 217
1OM-1505
7. PCB Vacuum Jig (PCB Width W "65<=W<250") : Chap.6
6-25
7.3 Variant Drawing for the Component Section (P/N 12-1).
b
b
0.03 A
A
0.03
4-C1
Fine Chamfering (Fringe)
2-C1
2-C1
R(Optional)
Q-F6 F9.5 Counterbore Depth 6
12-1
Material : A5052
Processing : None
Engraved mark for center position
L-4
CE
G
15.0
20±0.1
R
5
1
1
5
5
1
17P
W-7
1
L/2-2 L/2-2
5
6
5
12
U
1.6
1.6
View b-b
90°
1
Suction Hole Coordinates and Diameter
Make appropriate suction holes
based on the PCB shape.
F1F19
1103-002
1OM-1505
6-26
7. PCB Vacuum Jig (PCB Width W "65<=W<250") : Chap.6
7.4 Variant Drawing for the Component Section (P/N 12-2).
0.03 A
A
0.03
12-2
Material : A5052
Processing : None
2-C1
Fine Chamfering (Fringe)
2-C1
Q-F6
F12
1.6
1.6
L-4
10±0.1
C
17
17P
W-7
11
1
1
E
R G
L/2-2
U
F1F20
1103-002
1OM-1505
7. PCB Vacuum Jig (PCB Width W "65<=W<250") : Chap.6
6-27
7.5 Variant Drawing for the Component Section (P/N 12-3).
Q-M5 Depth 15
1.6
D C
A
X T
9
9
18
Z
F
2-F5 F8 Counterbore Depth 5
F12
25.5
5
2±0.05
9
6.5±0.05
+0.3
0
2-13.2
+0.2
0
F3.6
120±0.03S
10±0.05
Depth 8
+0.1
0
2-F3.9 Depth 8
+0.03
0
Material : A5052
Processing : None
12-3
F1F21
1103-002
