We are grateful to you for purchasing Hitachi screen printer.
This instruction manual describes the functions, handling, and operations of the machine
for those who have finished the basic training of the screen printer.
Wrong handling of the machine and a cleaning solvent (industrial alcohol) may result in
not only incorrect printing but also personal injury.
Before operating the machine, please read this instruction manual carefully to fully
understand the instructions and precautionary measures for safety purposes.
After reading through this manual, please use this manual as an occasional reference and
keep it within reach.
0906-001
2
1OM-1505
About the Instruction Manual
This instruction manual is divided into the following five volumes (booklets) on
subjective basis.
Volume 1: Guide
This describes the basic usage of the machine and is prepared for those
who will read this manual for the first time or have never used any screen
printer.
[Coverage]
"Checking Items", "Safety Precautions", "Guide Map for Machine and
Operations", "Functions", "Procedures from Preparation to Completion
of Automatic Operation", and "Specifications"
Volume 2: Automatic Operation & Product Change Menu
This describes the automatic operation menu and product change menu for
those who have read "Volume 1: Guide".
[Coverage]
"Checking Items", "Safety Precautions", "Automatic Operation",
"Program/Product Change Operations", "Pattern Programs", "Machine
Performance Data", etc.
Volume 3: Maintenance Menu
This describes the maintenanse menu for those who have read "Volume 1:
Guide".
[Coverage]
"Checking Items", "Safety Precautions", "Device Check", "Various
Operations", "Machine Adjustment before Delivery", "System Setup",
etc.
Volume 4: Maintenance & Troubleshooting
This describes the periodic maintenance and troubleshooting for the
machine operators.
[Coverage]
"Checking Items", "Safety Precautions", "Periodic Maintenance",
"List of Consumables and Servicing Parts", "Remedial Measures after
"ERROR" Window", etc.
