Power Failure Instantaneous voltage drop due to power failure or lightning will cause the built-in computer to break down and the basic and application programs to corrupt. It is recommended that a DC uninterruptive powe…

100%1 / 217
0906-001
Air Supply
Supply dry and clean air (Pressure: 0.45 to 0.69 MPa (4.6 to 7 kgf/cm
2
)) that does not
contain moisture, oil, and dust to the machine.When the supplied air contains much
moisture, etc., the machine may not work normally due to the moisture, etc., accumulated
in the machine.
Note
Dry and Clean Air
Moisture : Dew Point -17°C or less (Atmospheric Pressure)
Oil : 0.1 mg/m
3
or less (ANR)
Dust : Solid 0.01 µm or less
Data Backup Operation
Data may become unavailable due to breakdown or mishandling of the machine.
It is strongly recommended that the hard disk data be periodically backed up with the
network terminal (option).
Computer Viruses
When a program or data is corrupted abruptly, the computer makes unexpected system
behavior, or an abnormal window appears on the operation panel, the computer may be
infected with a virus.
Computer viruses are bad programs written to deliberately invade a computer system
without its user's permission or knowledge. They can perform a triggered event or corrupt
your precious data.
Antivirus programs are called "Vaccines" and used to remove or repair infected programs
and files.
A virus-infected computer may spread the virus to other computers through
communication systems or by sharing diskettes (data storage media) between different
computers.
Use a vaccine program to check if the built-in computer is infected with a virus if
necessary.
Keep in mind that a computer virus cannot be removed, depending on what type of
vaccine program you are using.
For this case, book the backup of data beforehand.
5. Precautionary Items for Correct Operations
Safe-28
Safety Precautions
1OM-1505
Power Failure
Instantaneous voltage drop due to power failure or lightning will cause the built-in
computer to break down and the basic and application programs to corrupt.
It is recommended that a DC uninterruptive power supply be used as a countermeasure
against instantaneous voltage drop.
Built-In Computer
A computer is built in the machine and used to control each internal mechanism of the
machine, save various data, and realize a user interface.
When the power switch of the machine is turned off while the computer is working
(computer being accessed), the computer may break down, causing the stored data and
application programs to corrupt.
Reference
Refer to "4.2 Power OFF" in "Chapter 2 (Vol. 1: Guide)" for how to turn off the power
switch of the machine.
Note on Startup Operation (Running-In Operation)
After the machine has been stopped for a long period of time, perform a running-in
operation for approximately 30 minutes to smoothly start up the machine.
Reference
Refer to "5. Running-In Operation" in "Chapter 3 (Vol. 1: Guide)" for the detailed
information on the running-in operation.
0906-001
5. Precautionary Items for Correct Operations
Safe-29
Safety Precautions
1OM-1505
About Industrial Alcohol
Industrial alcohol must be used as cleaning solvent for this machine.
It is inammable and acutely toxic.
Do not inhale high-density vapor even for a short period of time nor low-density one
for a long time. Otherwise, organic solvent poisoning will be caused.In addition, vapor
becomes an explosive gas if mixed with air.
When maintenance work is commenced, using industrial alcohol, be sure not to inhale
vapor during the work. Industrial alcohol must also be handled carefully because it can
catch fire very easily due to heat of fire, static electricity, sparks, etc.
Obtain the material safety data sheet (MSDS) from the maker and check the contents
described in detail for correct use of the alcohol.
Use the industrial alcohol described in T1X1 for this machine.
T1X1
Maker Product Name
DAN Chemical Co., Ltd Denatured Ethanol AP-7
Japan Alcohol T
rading Co., Ltd SOLMIX AP-7
When the industrial alcohol in T1
X1 is unavailable, follow the mixture ratio in T1X2.
T1X2
Chemical Element CAS No. Mixture Ratio
Ethyl Alcohol 64-17-
5 80 to 90 %
Normal Propanol 71-23-8 5
to 10%
Isopropyl Alcohol 67-63-0 5
% or less
Neveruseanysolventsotherthanthose(mixedusingthespeciedelements
inaccordancewiththespeciedratio)describedinT1X2.Avoidusingacetone,
methanol (methyl alcohol), and other solvents mixed with water or water and
another solvent.
If such a solvent is used, it will cause safety and functional problems. Any
accidentorbreakdown
duetotheuseofasolventotherthanthespeciedone
causes the given warranty to be invalidated and the manufacturer freed from all
liability.
0906-001
5. Precautionary Items for Correct Operations
Safe-30
Safety Precautions
1OM-1505
