5.5 Blower Unit (Vacuum Source)

The machine is equipped with a blower that generates vacuum for stencil cleaning

and PCB picks.

5.6 Cleaning Function

This function is used to clean the stencil in three modes (combinations of "Dry",

"Wet", and "Vacuum") for stable printing.

Reference

Refer to "4. Cleaning" Tab" in "Chapter 1 (Vol.2)" for details.

5.7 Conveyor Width Automatic Adjustment Function

This function is used to automatically adjust the widths of the L/R conveyors

according to the parameters registered in the pattern program.

5.8 Table Chute Width Automatic Adjustment Function

This function is used to automatically adjust the width of the table chutes

according to the parameters registered in the pattern program.

5.9 PCB Stopper Position Automatic Adjustment Function

This function is used to automatically adjust the position of the PCB stopper

according to the parameter registered in the pattern program.

5.10 PCB Backup Pin Up/Down or Jig Automatic Adjustment

Function

This function is used to automatically adjust the up/down movement (distance)

of the PCB backup pins or the jig according to the parameters registered in the

pattern program.

5.11 Backup Pin Automatic Replacement Function

This function is used to move and store automatically the backup pins stocked in

advance on the backup plate, to and in the required locations.

Note

All the manual backup operations are performed using the optional functions.

1OM-1505

5. Various Functions : Chap.1

1-270907-002

5.12 Printing Pressure Feedback Function

This function works to get the result of subsequent printing close to the specied

value by changing the pressure of air supplied to the cylinder that generates

printing pressure based on the difference between the specied value of the

printing pressure and the actual printing pressure (mean value in the printing

range).

When the automatic operation starts, this function automatically reads "0" (zero)

of the printing pressure and corrects the deviation of "0" (zero).

Note

This function is optional.
