1. Dispensing Uniform and precise application of a highly thixotropic material 2. Spraying Coating of large areas with a low splatter and mist spraying procedure 3. Jetting Pinpoint lacquer application of up to 120 minia…
TECHNOLOGY BENEFITS
技术优势
› Greatest possible process reliability
› All-in-One lacquering and highly selective coating
› Flexible lacquering options thanks to multifunctional lacquer applicator
› Minimal maintenance
› Effective lacquering and drying in a line concept
› Quick, intuitive programming with dependable software tools
Selective Conformal Coating Line
选择性点胶涂覆生产线
1.
2.
3. 4.
5.
7.
6.
8.
9.
10.
1. 上料机
2. 手动工作台
3. 底部遣返传输
4. Protecto点胶系统
5. 翻转台
6. 测试台
7. RDS干燥炉
8. 传输系统
9. 涂料检验
10.下料机
1. Loading
2. Manual work station
3. Underoor return transport
4. Protecto
5. Turning station
6. Test station
7. RDS drying system
8. Removal conveyor
9. Lacquer prole inspection
10. Unloading
更高的制程稳定性
多效合一的选择性喷涂制程
多功能喷涂器提供灵活的喷涂方案
更低的维护需求和维护成本
高效的喷涂及干燥整线解决方案
可靠的软件工具支持快速直观地编程控制
1. Dispensing
Uniform and precise application of a highly thixotropic material
2. Spraying
Coating of large areas with a low splatter and mist spraying
procedure
3. Jetting
Pinpoint lacquer application of up to 120 miniature dots per
second through rapid opening and closing of the valve
4. Curtain Coating
Spraying and fog-free coating of large surfaces at very high
process speed
1.
点胶
适用于均匀、准确地喷涂高触变性材料
2.
喷涂
大面积喷涂，采用无喷溅和雾化工艺
3.
喷射
通过喷射阀快速开关，实现最高120微型胶点/秒的精确喷涂
4.
帘式涂淋
更快速进行大面积喷雾式喷涂，无喷溅和雾化工艺
1.
3.
2.
4.
Protecto Coating
Protecto
Coating
The Protecto conformal coating process from Rehm reliably protects sensitive electronic modules with a
protective lacquer from damage by corrosion or other environmental influences, such as humidity, chemicals
or dust. Coating the PCB after soldering secures the functionality of the electronics, which may be used in end
products of critical safety importance, such as in the automotive, aviation or medical industries.
The multifunctional lacquer applicator and the patented Stream Coat
®
nozzles enable all standard protective
lacquers to be precisely applied by dispensing, spraying, jet or curtain coating, depending on the application,
even where the gaps between components are very small. With up to 4 coating applicators, you can synchronise
several modules simultaneously to apply the coating or directly apply with up to 4 different materials without
set-up time. Protecto is available as a production line design with RDS lacquer dryer that will add flexibility and
efciency to your production.
锐德Protecto点胶涂覆系统可以有效保护敏感组件免受腐蚀或其他环境干扰（如湿气、化学物质或粉尘）的侵害。针对关键性
安全应用（例如汽车、航空航天和医疗行业）的终端产品，对焊接后的PCB板进行喷涂能够为电子元器件提供可靠的保护。
多功能喷涂系统和获得专利的Stream Coat®喷嘴支持所有类型的标准防护涂料，可根据不同的应用要求进行点胶、喷涂、喷
射或帘式涂淋，并且可以在组件之间的狭窄空间内高效作业。该系统配备的喷涂器多达4个，可以同时对4个电子元器件进行
喷涂或同时进行4种不同类型涂料的喷涂制程。该系统还可以与RDS干燥系统进行联线，进一步提高生产灵活性和生产效率。
6. 测试台
7. RDS干燥炉
8. 传输系统
9. 涂料检验
10.下料机
RSS Special Systems
Individual systems, adapted to
the needs of our clients.
个性化系统解决方案，精确满足客
户需求
Reel-to-Reel System
for continuous thermal
treatment of exible substrates
适用于柔性基板的批量化热处理解
决方案
TECHNOLOGY BENEFITS
技术优势
› Individual system solutions, adapted to your requirements
› Expert, high-quality mechanical engineering
› Skilled process consultation
› Flexible options for your manufacturing
› More than 30 years experience in the industry
Flexible
and
individual
满足个性化需求的客制化系统解决方案
专家级高品质机械设计
专业的制程咨询
适应各种生产应用的灵活选项
30年高品质机械制造经验
