RFS Speedre and RDS Solar Equipment › Low breakage rate › Maximum process stability › High throughput › Minimal maintenance › Optimum temperature proling › Safe and vibration-free transport › Efcient process gas clean…
TECHNOLOGY BENEFITS
技术优势
› Flexible, modular construction
› Versatile production layout
› Low energy consumption, sustainable and ecient
› High throughput for diverse applications
› Intelligent software solutions
› Minimal maintenance
RDS Solar Dryer
Optimum drying processes
in the solar industry.
面向太阳能行业的最佳干燥制程
Speedre Systems
Top quality for the metallisation
of solar cells!
顶级品质，提供最佳太阳能电池覆膜
电路烧结性能
灵活的模块化设计
多样化生产配置
能耗更低，更高的能效及可持续性
高吞吐量，适合多种应用
智能软件解决方案
更低的维护需求和维护成本
RFS Speedre and RDS Solar Equipment
› Low breakage rate
› Maximum process stability
› High throughput
› Minimal maintenance
› Optimum temperature proling
› Safe and vibration-free transport
› Efcient process gas cleaning
› Excellent cooling gradient
99,9 % less VOC – the Thermal Oxidizer makes it possible!
Rehm’s VOC Thermal Oxidizer offers one of the most effective residue manage-
ment systems on the market. The organic compounds released from the pastes
during the heating process (Volatile Organic Compounds – VOC) are cracked and
almost completely converted into carbon dioxide and water. All available systems
operate with a separation of max. 99,9 %. Oxidizer systems with heat recovery,
such as the available Counter Flow Reactor, are also particularly environmentally
friendly.
有效降低99.9%的VOC含量!
锐德VOC直燃式焚烧系统是市场上最高效的残渣管理系统，能够将加热过程中产生的有机
化合物(VOC)彻底分解为二氧化碳和水蒸气，有效降低高达99.9%的VOC含量。此外，配备热
回收功能如逆流反应器 (CFR) 的焚烧系统则更加高效、环保。
RFS Speedre and RDS
Solar Equipment
Not only does Rehm satisfy the most stringent demands in the sphere of electronics products, but we also offer
efcient equipment for photovoltaic systems. Rehm’s Fast Firing Systems RFS Speedre and RDS Solar Dryer for
the typical metallisation of monocrystalline and multicrystalline solar cells have outstanding heating capacity and so
achieve top-class results. Their flexible modular construction facilitates diverse production layouts, while their low
energy use, high throughput and intelligent software solutions make them very versatile.
我们不仅提供应用于高端电子行业的热力解决方案，还为光伏行业提供高效的生产设备。锐德RFS快速烧结炉和RDS光伏干燥炉具有
出色的热性能，适用于各种常见的单晶和多晶太阳能电池覆膜电路烧结工艺，帮助客户实现最佳应用成果。此外，支持多样化生产配
置的模块化设计、低能耗、高产能和智能软件系统也使其成为最理想的通用型光伏解决方案。
Fast Firing Systems
RDS Solar Dryer
99,9 %
less
VOC!
低碎片率
最高制程稳定性
高产能
更低的维护需求和维护成本
最佳温度曲线
安全传输无振动效应
高效的清洁工艺
卓越的冷却性能
MANUFACTURING EQUIPMENT
生产设备
›
VisionXP+ Vac, VisionXC, CondensoXS, Protecto and
RDS (Line), RDS UV
› Templates and paste printers
› Placement system
› Handling system
› Cleaning system
TEST EQUIPMENT
测试设备
› Thermal imaging camera
› X-ray inspection
› BGA inspector, Fly inspector
› Rework station
真空/非真空回流焊接，气相焊接，点胶涂覆及RDS在线式、UV干燥系统
锡膏印刷模板和锡膏印刷机
装配系统
上/下板系统
清洗系统
热成像仪
X-Ray 检测仪
BGA检测仪、飞针测试仪
返修台
