RFS Speedre and RDS Solar Equipment
› Low breakage rate
› Maximum process stability
› High throughput
› Minimal maintenance
› Optimum temperature proling
› Safe and vibration-free transport
› Efcient process gas cleaning
› Excellent cooling gradient
99,9 % less VOC – the Thermal Oxidizer makes it possible!
Rehm’s VOC Thermal Oxidizer offers one of the most effective residue manage-
ment systems on the market. The organic compounds released from the pastes
during the heating process (Volatile Organic Compounds – VOC) are cracked and
almost completely converted into carbon dioxide and water. All available systems
operate with a separation of max. 99,9 %. Oxidizer systems with heat recovery,
such as the available Counter Flow Reactor, are also particularly environmentally
friendly.
有效降低99.9%的VOC含量!
锐德VOC直燃式焚烧系统是市场上最高效的残渣管理系统，能够将加热过程中产生的有机
化合物(VOC)彻底分解为二氧化碳和水蒸气，有效降低高达99.9%的VOC含量。此外，配备热
回收功能如逆流反应器 (CFR) 的焚烧系统则更加高效、环保。
RFS Speedre and RDS
Solar Equipment
Not only does Rehm satisfy the most stringent demands in the sphere of electronics products, but we also offer
efcient equipment for photovoltaic systems. Rehm’s Fast Firing Systems RFS Speedre and RDS Solar Dryer for
the typical metallisation of monocrystalline and multicrystalline solar cells have outstanding heating capacity and so
achieve top-class results. Their flexible modular construction facilitates diverse production layouts, while their low
energy use, high throughput and intelligent software solutions make them very versatile.
我们不仅提供应用于高端电子行业的热力解决方案，还为光伏行业提供高效的生产设备。锐德RFS快速烧结炉和RDS光伏干燥炉具有
出色的热性能，适用于各种常见的单晶和多晶太阳能电池覆膜电路烧结工艺，帮助客户实现最佳应用成果。此外，支持多样化生产配
置的模块化设计、低能耗、高产能和智能软件系统也使其成为最理想的通用型光伏解决方案。
Fast Firing Systems
RDS Solar Dryer
99,9 %
less
VOC!
低碎片率
最高制程稳定性
高产能
更低的维护需求和维护成本
最佳温度曲线
安全传输无振动效应
高效的清洁工艺
卓越的冷却性能
MANUFACTURING EQUIPMENT
生产设备
›
VisionXP+ Vac, VisionXC, CondensoXS, Protecto and
RDS (Line), RDS UV
› Templates and paste printers
› Placement system
› Handling system
› Cleaning system
TEST EQUIPMENT
测试设备
› Thermal imaging camera
› X-ray inspection
› BGA inspector, Fly inspector
› Rework station
真空/非真空回流焊接，气相焊接，点胶涂覆及RDS在线式、UV干燥系统
锡膏印刷模板和锡膏印刷机
装配系统
上/下板系统
清洗系统
热成像仪
X-Ray 检测仪
BGA检测仪、飞针测试仪
返修台
Technology Center
Experience the soldering process live.
How is it possible to create the ideal temperature proles? Or
which technology is best for avoiding voids in soldered joints?
Rehm can answer these questions.
In autumn 2013, a high-tech applications and demonstration
centre was opened on an area of 460 m
2
at the company’s
headquarters in Blaubeuren. Here, customers can test modules
in direct application of convection, condensation and vacuum
soldering processes, create individual temperature proles and,
aided by our applications specialists, dene the optimal para-
meters for the production process.
Additionally, the Technology Center is tted with a complete
state-of-the-art SMT production line – from the paste printer
through placement machines to a reflow soldering system. A
complete coating line for selective conformal coating demons-
trates secure protection of modules from environmental influ-
ences. At Rehm, there is also extensive equipment for module
testing and for test results analysis.
You are welcome to arrange an appointment with us via info@
rehm-group.com to visit the Technology Center and experience
the soldering process live.
如何创建最佳温度曲线？应该采用何种技术方案才能避免焊接空洞？
锐德给您答案。
2013年秋季，锐德在德国布劳博伊伦总部设立了技术应用及演示中心。
在这里，客户可以直接测试电子组件的回流、凝热及真空焊接制程，创
建个性化温度曲线，并在应用专家的帮助下为生产制程制定最佳参数。
此外，锐德技术中心还配备了目前最先进的，涵盖从锡膏印刷到装配系
统再到回流焊系统等设备的完整SMT生产线。还拥有一套完整的点胶涂
覆生产线为您展示如何安全保证组件不受环境因素影响。最后，该技术
中心还提供广泛的测试和分析设备，方便您进行组件测试和测试结果分
析。
欢迎您发送邮件至info@rehm-group.com进行预约，在我们的技术中心
现场体验焊接制程。
30 years
success by
Know-how
