2OM-1751 1-61 1303-001 4.3 "T est Mode" T ab Sheet When the [Test Mode] tab is pressed in the "OPERATION" window, the following tab sheet appears. [1] [2] [1] [2] " Test Mode " Tab Sheet F2A…
2OM-1751
1-601303-001
4.2.12 Multi Head
When the [Multi Head] button is pressed on the "Opr. Mode" tab sheet, the
following window appears.
[1] [2]
F2A42
[1] Simultaneous pick
The multi-functional head is used when the nozzle pitch of head agrees with
the tape feeder pitch for component pickup.
Enable
: When selected, the component simultaneous pickup is performed.
Disable
: When selected, the component simultaneous pickup is not
performed.
[2] Multi Nzl ID check befor RUN
Enable
: When selected, the ID of the nozzle housed in the nozzle stocker
for the multi-functional nozzle, is identied and the data is re-
written in the case that the identication result is not the same as
that on the placement nozzle/head data.
Also, it is checked whether if all the nozzles required for the
production, have been prepared.
Disable
: When selected, the nozzle ID recognition function is not used.
4.2 "Opr.Mode" Tab Sheet
2OM-1751
1-611303-001
4.3 "Test Mode" Tab Sheet
When the [Test Mode] tab is pressed in the "OPERATION" window, the
following tab sheet appears.
[1]
[2]
[1]
[2]
"
Test Mode
"
Tab Sheet F2A43
The number of test run patterns to be saved is up to three.
[1] TEST PATTERN
The pattern where the test operation mode has been designated, is selected in
this data box.
4.3 "Test Mode" Tab Sheet
Graphic
Development
2OM-1751
1-62
[2] [Pattern #1], [Pattern #2], and [Pattern #3] Buttons
Select one of the buttons to specify the desired pattern for designation of the
test mode.
Notice
Wrong selections (test run in wrong modes) will cause various
deciencies such as component picks by vacuum nozzles,
scattering of components, or collision with the chute, etc.
4.3 "Test Mode" Tab Sheet
