2OM-1751 4-18 1303-001 2.4 "Handling/Plac." T ab Sheet When the [Handling/Plac.] tab is pressed in the "MNG.DT." window, the following tab sheet appears inside the window. [1] [2] [3] "Handling/P…
2OM-1751
4-171303-001
[9] C:Comp. Vertical
Each text box shows the number of vertical component errors detected by the
linear measure detection sensor for each individual nozzles.
[10] D:Comp. Recog
Each text box shows the number of errors detected through recognition
operation for each individual nozzles.
[11] E:Comp. Thick
Each text box shows the number of errors in component thickness detected
by the linear measure detection sensor for each individual nozzles.
[12] F:Pick-up Diff
Each text box shows the number of pickup difference errors detected in the
recognition process for each individual nozzles.
[13] G:Comp. Posture
Each text box shows the number of reversed component and polarity
judgment errors detected in the recognition process for each individual
nozzles.
[14] H:Meas. Error
Each text box shows the total times of measured value error in each feeder.
[15] K:Copla. Error
Each text box shows the total times of detected "Coplanarity Error" in each
feeder. This error is detected in the option attachment.
[16] L:Obv / Reverse
The "judged front/rear error" for each nozzle, detected using the linear
measure is displayed in this data box.
[17] Nozzle Clear/Change Date
Each text box shows the clear date for each individual nozzles.
2.3 "NozMng." Tab Sheet
2OM-1751
4-181303-001
2.4 "Handling/Plac." Tab Sheet
When the [Handling/Plac.] tab is pressed in the "MNG.DT." window, the
following tab sheet appears inside the window.
[1]
[2]
[3]
"Handling/Plac." Tab Sheet F2D12
[1] Z:Total components
Shown is the number of component picks.
*A:component missing[sensor]
Shown is the number of component missing errors detected by the
component linear measure detection sensor.
(Case: "NG" (No Good) in Component Recognition and Linear Measure
Detection Sensor)
*B:component missing[recognition]
Shown is the number of component missing errors detected through
component recognition operation.
*C:component vertical[sensor]
Shown is the number of components judged "NG" (No Good) by the linear
measure detection sensor although they are judged "OK" through component
recognition process.
*G:component posture[recognition]
Shown is the number of reversed component and polarity judgment errors
detected in the recognition process.
*L:obverse/reverse[sensor]
The "judged front/rear error" times for each feeder, detected using the linear
measure, is displayed in these data boxes.
2.4 "Handling/Plac." Tab Sheet
2OM-1751
4-191303-001
2.4 "Handling/Plac." Tab Sheet
*D:component recognition
Shown is the number of components judged "NG" (No Good) through
recognition process.
*E:component thickness
Shown is the number of errors in compo
*F:pick-up difference
Shown is the number of components judged "NG" (No Good) through
recognition process.
*H:measurement error
Each text box shows the total count of measurement error in each individual
feeder.
*K:coplanarlty
The times of error decided in the coplanarity error detection is shown in this
data box.
The percentage of error detected in the optional device installation, is
displayed in this data box.
[2] Component chuck
[((*total comp.-(*A+*B+*C+*G+*L))/*Total comp.) × 100] (%)
The value (%) is determined by the following formula.# of Picks -
(Counts in "A" + Counts in "B" + Counts in "C"
+ Counts in "G" + Conuts in "L")
×100
# of Picks
[3] Component placement
[((*total comp.-(*A+*B+*C+*D+*E+*F+*G+*H+*K+*L))/*Total comp.)
× 100] (%)
The value (%) is determined by the following formula.
# of Picks - (Counts in "A" + Counts in "B" + Counts in "C"
+ Counts in "D"+ Counts in "E"+ Counts in "F"+ Counts in "G
+ Counts in "H"+ Counts in "K"
+ Conuts in "L"
)
×
100
# of Picks
Note
About Data Counting (Counting of "*A: component missing [sensor]"
and "*B: component missing [recognition]")
The machine stops in an error condition according to the number of times
(the number of continuous component missing errors to be counted to stop
the machine in an error condition) set in the "1" text box of "Error process"
in the "Control Data" tab sheet of a "Component Library" window.
In this case, the number of missing component errors is not added to the
number of picks and the number of chuck errors.
