Safety Precautions
Safe-27
1OM-1751
1305-002
5. Alert Labels
No. Alert Labels and Description
(10)
CAUTION
Your hand might be caught in the moving section. Do not
put your hand into the cover opening during the machine
operation.
Pay attention to the moving
mechanisms!
10-0249-
Description
Do not put your hand inside the machine while the machine is running.
Otherwise, your hand may be trapped in the moving mechanisms, causing injury.
(11)
10-0339-
CAUTION
When the feeder base is moved up and down
and your finger is put into the moving section,
you might get injured.
Do not put your hand into the moving section.
Your hand or finger might be crushed.
Description
Do not put your hand in the moving area while the feeder base is moving up or
down.
While the LED of a [FEEDER READY] switch is ickering, it indicates that the
feeder base is moving upward or downward.
(12)
10-0334-
Strong Magnetism!
Do not bring any metal close to this.
Otherwise, such metal will easily be
magnetized and attracted,
causing an injury to the operator.
CAUTION
Description
Strong permanent magnets are used in the moving sections of the X/Y beam.
•
Do not bring any metal of high magnetizability close to this. Otherwise, such
metal will easily be magnetized and attracted, causing an injury to the operator
or breakdown of the machine.
•
Do not bring any object such as a magnetic card or a watch close to the
magnets.Such an object can easily be affected by the magnetism. Otherwise, the
data of the magnetic car might be cleared or a watch, etc., may be damaged due
to the strong magnetism.
Safety Precautions
Safe-28
1OM-1751
1305-002
5. Alert Labels
No. Alert Labels and Description
(13)
Description
Do not drop a feeder. Otherwise, a foot injury will result or the feeder itself may be
damaged.
Carefully handle each feeder one by one and do not drop any.
(14)
00-0293-
Description
Because the temperature of this section is very high, do not touch. Doing so might
cause a burn.
(15)
00-0263-
Description
Do not put any feeder sideways nor tools on the feeder bases. Otherwise, the
machine will break down.
(16)
10-0252-
The machine will be break down.
Trained Personnel Only!
Description
If you put your hand or a heavy object on the backup table while working inside the
machine, the backup table may become deformed due to an excessive load.
Safety Precautions
Safe-29
1OM-1751
5. Alert Labels
1305-002
No. Alert Labels and Description
(17)
10-0333-
Never disconnect the connector during
the feeder base lifting operation.
Doing so might cause a system malfunction.
Description
Do not disconnect the connector during the feeder base moving-up operation.
Doing so might cause a malfunction of the system.
(18)
10-0335-
Keep Linear Guide Grooves
Clear of Any Object!
An object in the groove may be trapped in the
moving part, causing the machine to be damaged.
Description
Keep the linear guide grooves clear of any object. Otherwise, an object in the
groove may be trapped in the moving part, causing the machine to be damaged.
(19)
Description
Be sure to read the instruction manual carefully for correct operations before use.
If the machine is operated incorrectly, it might cause a breakdown of the machine.
