2OM-1751
1-11303-001
1. Outline of Menus for Automatic Operation
The following shows the hierarchical structure of the menus (including the
submenus and windows) for the automatic operation.
"Product." Window
"Comp.Reload" Window
"OPERATION" Window
"Prod.Dt." Submenu
"Manage" Submenu
"Recall" Submenu
Run Mode Tab Sheet 4.1
Opr.Mode Tab Sheet 4.2
Test Mode Tab Sheet 4.3
Altn Mode Tab Sheet 4.4
PP.Data Chapter 2
Comp Lbry Chapter 3
Temp. Chng. Comp Lbry "2" in "Chapter 3"
Device Err "2" in "Chapter 5"
Comp Rcg Err "3" in "Chapter 5"
Comp Err(Sens) "4" in "Chapter 5"
Mach Info "5" in "Chapter 5"
Disp. Rcg Img dt "6" in "Chapter 5"
Mng.Dt "2" in "Chapter 4"
Cmt.PP.Mng.Dt "3" in "Chapter 4"
Msg Rate Data "4" in "Chapter 4"
Reference Item Nos.
Automatic Operation Main Menu Bar
2
3
F2A1
Menus for Automatic Operation
1. Outline of Menus for Automatic Operation
2OM-1751
1-21303-001
2. "Product" Window
2.1 Local Window
This window enables you to view the current operation status and production
condition such as the production model names (pattern program names), etc.,
and the information on the prospective number of nished PCBs and presumable
deterioration in the operation rate based on pickup errors, etc.
[1]
[3]
[4]
[5]
[2]
F2A2
Graphic
Development
2. "Product" Window
2OM-1751
1-31303-001
[1] "Product." Main Menu Bar
[Product.]
Main Menu
Opens the "product" window. In normal cases,
this window opens as an initial one.
[Comp.Reld.]
Main Menu
Opens the "Comp.Reload" window.
Refer to "3. "Comp.Reload" Window"
for details .
[Operation]
Main Menu
Opens the "OPERATION" window.
Refer to "4. "OPERATION" Window"
for details.
[Prod.Dt.]
Main Menu
Opens the "Prod.Dt." window.
:
[Manage]
Main Menu
Opens the "Manage" window.
Refer to "Management Data in chapter 4" for
details.
:
[Recall]
Main Menu
:
:
:
:
Reference
Reference
Reference
Opens the "Recall" window.
Refer to "Recall in chapter 5" for details.
Reference
Refer to "Pattern Program in chapter 2" and
"Component Library in chapter 3" for details.
Reference
"Product." Main Menu Bar F2A3
2.1 Local Window
