4.2.5 Speed
Whether or not the speed upper limit is set, is selected for the operation speed
in each unit, which has been designated in the component library data (speed
reduction rate to the maximum speed).
[1]
[3]
[4]
[2]
[9]
[10]
[5]
[6]
[7]
[8]
[11]
F2A31
[1] Mode
The following buttons can be selected to determine whether or not the
running speed reduction mode should be used.
Note
When "Not Save" is selected, the other items cannot be set.
No Designate
When selected, this button disables you to designate the reduction of the
running speed.
Designate
When selected, this button enables you to designate the reduction of the
running speed.
In this case, as the following buttons become available, set the rate of each
speed reduction.
[2] All Setting
When this button is pressed, the [All Setting] window opens. In this window,
set the speed reduction rate in the data entry eld. The set speed reduction
rate is reected on all other settings.
4.2 "Opr.Mode" Tab Sheet
2OM-1751
1-431303-001
[3] X/Y Beam
When this button is pressed, the "X/Y Beam" entry window is displayed. In
this window, set the speed reduction rate for the X/Y beam in the data entry
led.
[4] Nozzle Pickup Descent
When this button is pressed, the "Nozzle Pick-Up Descent" edit window
opens.
Set the rate of speed reduction in the data entry eld for the descending
movement of the nozzle (nozzle movement to pick up a component from the
feeder).
[5] Nozzle Pickup Ascent
When this button is pressed, the "Nozzle Pick-Up Ascent" edit window
opens.
Set the rate of speed reduction in the data entry eld for the ascending
movement of the nozzle (nozzle movement after the nozzle has picked up a
component from the feeder).
[6] Nozzle Plcmnt Descent
When this button is pressed, the "Nozzle Plcmnt Descent" edit window
opens.
Set the rate of speed reduction in the data entry eld for the descending
movement of the nozzle (nozzle movement to place a component on the
PCB).
[7] Nozzle Plcmnt Ascent
When this button is pressed, the "Nozzle Plcmnt Ascent" edit window opens.
Set the rate of speed reduction in the data entry eld for the ascending
movement of the nozzle (nozzle movement after the nozzle has placed a
component on the PCB).
[8] Nozzle Select
When this button is pressed, the "Nozzle Select" edit window opens.
Enter the rate of speed reduction in the data entry eld for a series of
operations performed when the nozzle is changed.
[9] Head Up/Down
When this button is pressed, the "Head Up/Down" edit window opens.
Enter the rate of speed reduction in the data entry eld for the head upward
and downward movement.
4.2 "Opr.Mode" Tab Sheet
2OM-1751
1-441303-001
4.2 "Opr.Mode" Tab Sheet
[10] Head Rotation
When this button is pressed, the "Head Rotation" edit window opens.
Enter the rate of speed reduction in the data entry eld for the head rotation.
Note
(a) If a higher speed than that specied in this window is set in the component
library data, it is regulated to the specied upper limit.
(b) If a lower speed than that specied in this window is set for some
components in the component library data, it becomes valid.
[11] Retention time bfr Pl descent
The stop time before the moving down for the placement, is set in this data
box.
Rang
: 0 to 255 ms
Value
: 0 ms
