- - 2. BASEFRAME COMPONENTS(2) 3 8 3 9 7 5 A A 7 4 4 2 4 2 4 2 4 1 4 1 4 1 4 0 5 0 5 1 4 7 4 8 4 7 4 9 4 3 4 4 7 3 7 2 7 1 7 2 7 0 6 9 5 2 5 9 8 9 3 6 3 7 1 8 1 9 2 5 2 4 2 5 3 5 2 4 3 4 2 3 2 2 2 1 2 0 2 6 2 7 4 5 4…

- -

REF.NO NOTE PARTNO DESCRIPTION Qty

1 EA-9500B01-00 CABLEBAND 50

2 EA-9500B02-00 CABLEBAND150 120

3 HX-0006500-0B CABLEBAND 50

4 HX-0006500-0C CABLEBAND 5

5 HX-0041800-0C SPACER 16

6 E1035-729-000 ADJUSTERFOOT 4

7 400-00519 BASEFRAMENUT 4

8 E1044-729-000-A ADJUSTERNUT36 4

9 400-00403 ADJUSTBOLT 4

10 SM-6126002-TN SCREWM12L=60 12

11 WS-1220002-KN SPRINGWASHER 12

12 WP-1302500-SC WASHER 12

13 SM-6083002-TN SCREWM8L=30 24

14 NM-6080002-SC NUTM8 12

#06

400-13307 FPPUSHER 12

#06

NM-6080001-SC NUTM8X1.25 12

#03

HK-0429900-7A CAP 2

18 PS-0400122-KP SPRINGPIN 10

19 SL-6040892-TN SCREWM4L=8 4

#03

400-00535 BASEFRAMENUT(EN) 4

#01

401-14762 HOLECOVERMASSY 1

#02

401-14536 HOLECOVERLASSY 1

23 400-94739 HOLECOVERCOPLA (1)

#02

SL-6061292-TN SCREW (4)

25 SL-6061292-TN SCREW (4)

#02

401-14021 FLUXERHOLECOVER (1)

#02

401-08665 EXTFRAMEHOLECOVER (1)

#02

SL-6041092-TN SCREWM4L=10 (4)

29 401-08337 FANBR 4

#04

400-92440 BASICFANASM 4

31 SL-4033591-SC SCREWM3X35 12

32 WP-0320501-SC WASHERM3 4

33 NM-6030001-SC NUTM3X0.5TYPE1 4

34 SL-3061232-TN SCREWM6L=12 8

35 401-13993 SMEMABRASM 1

36 400-94462 IFPANELL (1)

37 SL-4030881-SC SCREWM3L=8 (4)

38 401-10047 SMEMAINCABLEASM (1)

39 SL-6061292-TN SCREW 2

#03

HK-0429901-4A CAP 1

#04

401-14758 MTCIFPANEL-RASM

#05

401-36235 MTC_IF_PANEL-R_ASM 1

43 401-10047 SMEMAINCABLEASM (1)

44 SL-4030881-SC SCREWM3L=8 (8)

45 401-20296 EPV_HOLE_COVER (1)

46 PX-9500010-00 PLUG (1)

47 401-09923 MTCPWRWIRERASM (1)

48 400-46640 USBBRACKET (1)

49 400-44522 USBRELAYCABLE (1)

50 SL-6030692-TN SCREWM3L=6 (2)

51 HK-0651200-80 CONNECTOR (1)

52 SM-4860501-SB SCREWM2.5L=5 (2)

53 HX-0032600-0A GROMMET (1)

#05

SL-6030892-TN SCREWM3L=8 (2)

#05

401-33969 MTCPOWERCABLERASM (1)

56 401-20294 IF_PANEL_R_EPV (1)

#04

401-14759 MTSIFPANEL-LASM 1

#05

401-36236 MTS_IF_PANEL-L_ASM 1

59 PX-9500010-00 PLUG (1)

60 SM-4860501-SB SCREWM2.5L=5 (2)

61 401-14123 MTSIFPANEL (1)

62 401-09922 MTCPWRWIRELASM (1)

63 SL-4030881-SC SCREWM3L=8 (4)

64 PJ-2300062-00 UNION (1)

#05

PJ-3040600-04 PARTITIONELBOW (1)

#05

401-33968 MTSPOWERCABLELASM (1)

#03

400-00404 ADJUSTBOLT(EN) 4

68 401-14025 CEILINGCOVER 1

69 SL-6041492-TN SCREW 5

70 HX-0029400-00 FIXEDBASE 4

71 SL-4030681-SC SCREWM3L=6 4

72 SL-6061292-TN SCREW 4

73 401-08661 BANKPCBBR 2

74 400-66568 BANKPCBASM 2

75 SL-4030691-SC SCREWM3L=6 32

#03

HK-0429901-4A CAP 1

#04

E6600-729-000 ADJUSTFOOTN 4

#04

SM-6082502-TN BOLT 12

#04

400-13306 FLICTIONPLATE 12

#04

SM-1030801-SC SCREWM3L=8 36

81 SM-6030602-TN SCREWM3X6 2

82 400-95126 MTCMTSI/FBRCABLEASM 1

83 PJ-3040600-04 PARTITIONELBOW 1

84 SL-6061292-TN SCREWM6L=12 4

85 400-52570 BASERUBBER 2

86 401-08664 CEILINGCOVEREX 1

87 SL-6040892-TN SCREWM4L=8 3

88 E1038-871-000 PLATENLOCKCAMSCREW 5

89 HM-0003300-30 FINGERGUARD 1

90 401-08337 FAN_BR 1

#04

400-92440 BASICFANASM 1

92 SL-4033591-SC SCREWM3X35 4

93 WP-0320501-SC WASHERM3 2

94 NM-6030001-SC NUTM3X0.5TYPE1 2

95 HM-0003300-30 FINGERGUARD 1

96 SL-3061232-TN SCREW 2

#05

401-33768 DCFAN 5

- -

2. BASEFRAMECOMPONENTS(2)

3 8 3 9

7 5

7 4

4 2

4 1

4 0 5 0

5 1

4 7 4 8

4 7 4 9

4 3 4 4

7 3

7 2

7 1

7 2

7 0

6 9

5 2

5 9 8 9

3 6

3 7

1 8 1 9

2 5

2 4

2 5 3 5

2 4 3 4

2 3

2 2

2 1

2 0

2 6 2 7

4 5 4 6

1 0

1 3

1 2

1 7

1 6

1 4

1 1

5 3 6 4

7 8 7 9

8 6

8 8

8 4 8 5

8 2 8 3

8 0 8 1

6 6

6 3

6 7

1 5 6 3

6 2 6 8

6 1 6 5

6 0

5 8

5 7

5 6

5 5

5 4

7 6

7 7

1 7

1 6

1 7

1 6

3 0

2 8 2 9

3 3

3 1 3 2

2 5

2 4

2 5 3 5

2 4 3 4

8 7

- -

REF.NO NOTE PARTNO DESCRIPTION Qty

1 401-14535 BASEPLATEASSY 1

2 401-14022 BASEPLATEL (1)

3 401-08556 BASEPLATEC (1)

4 HX-0066900-0A GROMMET (0.07)

5 401-14019 BASEPLATETRANS (1)

6 401-08555 BASEPLATERR (1)

7 HX-0055700-00 TIEMOUNT (6)

8 HX-0029400-00 FIXEDBASE (8)

9 SM-4040801-SC SCREWM4X0.7L=8 (14)

10 401-08554 BASEPLATEFR (1)

11 SL-6040892-TN BOLT (2)

12 400-94549 HOLECOVER (4)

13 400-98142 CHNUTPLATE (4)

14 SL-6043092-TN BOLT (8)

#03

WP-1052001-SC WASHER10,5X21X2 16

16 400-94475 BPWASHER 38

17 NM-6100001-SC NUTM10X1.5 18

#05

401-14750 ACINPUTUNIT 1

#06

401-33952 ACINPUTUNIT 1

20 401-14740 BLOCKTERMINALPLATE (1)

21 SL-6040892-TN SCREWM4L=8 (4)

22 HK-0699501-10 BLOCKTERMINAL (1)

23 SL-6041642-TN SCREWM4L=16 (2)

#05

HX-0029400-00 TIEMOUNT (5)

#05

SM-4040801-SC SCREWM4X0.7L=8 (5)

#05

401-14739 ACPOWERPLATE (1)

#06

401-34566 AC_POWER_PLATE (1)

#05

HN-0023700-00 NOISEFILTER (1)

#06

HN-0037400-00 NOISEFILTER (1)

30 SL-4040891-SC SCREWM4L=8 (4)

#05

401-13715 ACINPUTNO.08CABLEASM (1)

#06

401-33964 LFCAPACITORASM (1)

33 SL-4041091-SC SCREWM4L=10 (1)

#06

HX-0029400-00 FIXEDBASE (2)

#06

SM-4040801-SC SCREWM4X0.7L=8 (2)

36 E1038-871-000 PLATENLOCKCAMSCREW 2

37 SL-6040892-TN SCREWM4L=8 2

#05

401-14764 REARPCBUNIT 1

#06

401-35631 REAR_PCB_UNIT 1

#05

400-48082 SUPERINPAUSEBOARD (1)

41 HX-0035400-0S SPACER (6)

42 SL-4030681-SC SCREWM3L=6 (6)

#05

401-08316 PCBSETSTAND (1)

#06

401-34637 PCB_SET_STAND (1)

#05

401-08317 PCBSUPPORT (1)

#06

401-34638 PCB_SUPPORT (1)

47 SL-6040892-TN SCREWM4L=8 (4)

#06

SL-6040892-TN BOLT (2)

#06

E1038-871-000 PLATENLOCKCAMSCREW (2)

#06

401-29641 SUPERIMPOSEBOARD (1)

51 SL-6030692-TN SCREWM3L=6 (4)

52 400-94474 TRANSBOLT 2

53 HX-0018800-0F CORDBUSH 1

54 HX-0055700-00 TIEMOUNT 6

55 SM-4061201-SC SCREWM6L=12 6

56 400-80833 SPONGE 16

57 HX-0029400-00 FIXEDBASE 32

58 SM-4040601-SC SCREWM4X0.7L=6 32

#05

401-13682 TRANSFOMER 1

#02

400-94543 CASTER3020 4

#03

400-94544 CASTERPLATE 4

#01

SL-6102042-TN SCREW 16

#01

WP-1052001-SC WASHER10,5X21X2 32

#04

HX-0057900-00 PERFECTROCK 1

#01

400-94545 CASTERPLATEEN 4

#01

400-00406 CASTERSPACER(EN) 4

#01

SL-6104042-TN BOLT 16

#03

SL-6103542-TN SCREWM10L=35 16

69 WS-1220002-KN SPRINGWASHER 2

70 WP-1302501-SC WASHER13X24X2.5 2

71 400-44814 WASHERPLATE 4

#05

400-94475 BPWASHER 4

73 NM-6120001-SC NUTM12X1.75TYPE1 4

74 E1038-871-000 PLATENLOCKCAMSCREW 2

75 SL-6040892-TN SCREWM4L=8 2

76 400-94471 BASESUPPORT 2

77 SL-6061292-TN SCREW 4

#05

401-14760 PCBBOXUNIT 1

#06

401-35775 PCB_BOX_UNIT 1

#05

401-14012 PCBBOXBASE (1)

#06

401-47521 PCB_BOX_BOTTOM (1)

#05

401-14013 PCBCOVERL (1)

#06

401-47522 PCB_BOX_UPPER (1)

#05

SL-6040892-TN SCREWM4L=8 (6)

#06

SL-6040892-TN BOLT (4)

86 HX-0002600-0A BASEPARTS (4)

#06

SL-6030692-TN SCREWM3L=6 (2)

88 SL-6061492-TN SCREWM6L=14 2

#06

401-35052 TRANSFORMER 1
