KE-3010_KE-3020V_KE-3020VR-Rev06 - 第173页
- - REF.NO NOTE PARTNO DESCRIPTION Qty 1 400-47171 LCDBRACKETR 1 2 SL-6041092-TN S CREW 4 3 400-47170 LCDBRACKETF 1 4 SL-6041092-TN S CREW 4 5 SD-0640246-SP H INGESCREWD=6.35H=2.4 2 6 161-87007 …
- -
82.REARMONITORCOMPONENTS
4 6
2 6
2 7
3 0
9 1 1
1 4
1 4
1 3
1 4
3 4
3 6
3 5
3 7 3 9
4 4 4 5
3 2
1 9 2 1
1 8
2 3
3 3
1 6 1 7
2
1 2
1 5
1 4
1 3
1 4
2 4 2 5
2 2
1 4
1 3
4 1
4 2 4 3
5
1
7
8
6
4 0
3 1
2 8
2 9
3
4
- -
REF.NO NOTE PARTNO DESCRIPTION Qty
1 400-47171 LCDBRACKETR 1
2 SL-6041092-TN SCREW 4
3 400-47170 LCDBRACKETF 1
4 SL-6041092-TN SCREW 4
5 SD-0640246-SP HINGESCREWD=6.35H=2.4 2
6 161-87007 WINGBOLT 1
7 WP-0641601-SC WASHER 1
8 WS-0610002-KN SPRINGWASHER6.1X12.2X1.5 1
9
#03
401-36130 ASM_KEYBOARD_UNIT 1
10
#01
400-93771 ASM_KEYBOARD_UNIT 1
11
#02
401-14866 ASM_KEYBOARD_UNIT 1
12 400-47173 KBSTAND (1)
13 E1349-721-000 KEYBOARDHINGE (3)
14 SM-0030401-SC SCREWM3L=4 (12)
15 E1346-721-000 KEYBOARDMAGNET (2)
16
#02
400-03318 KEYBOARDSPASM (1)
17
#03
401-32159 PS2KEYBOARDSPASM (1)
18 HX-0002400-0E WIREHARNESSPARTS (1)
19
#03
401-23712 KB_BRACKET (1)
20
#01
400-93805 KB_BRACKET (1)
21
#02
401-11301 KB_BRACKET (1)
22 SL-4040891-SC SCREWM4L=8 (2)
23 HX-0009600-0A GROMMET (0.5)
24
#02
400-01440 KBCLAMP (1)
25
#03
401-23713 KBCLAMP (1)
26 400-03281 MOUSE/KEYBOARDSELECTOR 1
27 HX-0035400-0A SPACER 4
28 HA-0055300-10 LENSGREEN 2
29 HA-0055300-2A BEZEL 2
30 SL-4030691-SC SCREWM3L=6 4
31
#02
400-80173 OPTICALSCROLLMOUSE 1
32 400-97767 KBSTANDMTS 1
33 E5348-033-100 CABLEPROTECTOR106MM 0.16
34 SL-4030691-SC SCREWM3L=6 2
35 400-99500 KBSTAYB 1
36 SM-3040652-TN SCREWM4L=6 2
37
#03
401-34633 KB_STAY_CD 1
38
#01
400-93709 KB_STAY 1
39
#02
401-11302 KB_STAY 1
40
#02
401-23609 MOUSECASE 1
41
#02
E2506-716-000 MOPMAGNET 1
42
#03
401-22812 15INCHLCDMONITOR 1
43
#02
400-48083 15INCHLCDMODULE 1
44
#01
SL-6040892-TN BOLT 2
45 SL-6041092-TN SCREW 3
46 400-52570 BASERUBBER 1
- -
83.MINIPAT&SOTCHECKTABLECOMPONENTS(1)
3
6
2
4
5
1
1
