- - 9. BASEFRAME ELECTRICA PPARATUSCOMPO NENTS(5) 3 8 3 7 4 1 4 4 3 9 4 0 4 5 4 4 4 3 4 2 3 1 3 7 2 7 2 8 3 4 2 5 2 9 2 9 2 6 3 3 2 9 1 5 2 4 2 2 2 3 3 0 1 6 3 6 3 6 3 6 3 5 3 6 3 3 3 2 1 7 1 9 2 1 2 0 1 8 1 2 9 1 …

100%1 / 284
- -
REF.NO NOTE PARTNO DESCRIPTION Qty
1 401-14754 BUDRIVERUNIT 1
2
#01
401-14755 BUDRIVERUNIT(EN) 1
3 401-14030 STEPDRVBASE (1)
4 401-13995 BUDRIVERASSY (1)
5
#01
400-94918 BUDRIVERASSYEN (1)
6 HX-0042000-00 5PHASESTEPDRIVER (1)
7
#01
HX-0054500-00 5PHASESTEPDRIVER (1)
8 400-00534 BACKUPDRIVPLATE (1)
9 SL-4040891-SC SCREWM4L=8 (3)
10 E1038-871-000 PLATENLOCKCAMSCREW (1)
11 SL-4040891-SC SCREWM4L=8 (2)
12 401-14029 STEPDRVCOVER (1)
13 SL-6030692-TN SCREWM3L=6 (4)
14 HX-0029400-00 FIXEDBASE (4)
15 SL-4030691-SC SCREWM3L=6 (4)
16 SL-6041092-TN SCREWM4L=10 3
17
#02
401-14757 CTRLUNIT 1
18
#03
401-35630 CTRL_UNIT 1
19 401-49647 ETHER-MAINPCBASM (1)
20 400-44540 16AXIS2CHSERVOCONTROLLER (1)
21 401-14039 CTRLUNITFRAME (1)
22
#02
401-08564 CTRLBASE (1)
23
#03
401-34636 CTRL_BASE_L (1)
24
#02
HX-0002600-00 GUIDERAIL (10)
25
#03
HX-0002600-00 GUIDERAIL (14)
26 400-94396 BACKBORDBAR (1)
27 SL-4031491-SC SCREWM3X14 (3)
28 400-48002 CPCIBACKBOARD (1)
29
#02
SL-4851091-SC SCREW (26)
30
#03
SL-4851091-SC SCREW (24)
31 SL-4040891-SC SCREWM4L=8 (8)
32 400-71300 IPX7ASM (1)
33
#02
400-92440 BASICFANASM (2)
34
#03
401-33768 DCFAN (2)
35 SL-4033091-SC SCREWM3L=30 (4)
36
#02
401-13723 CPUBOARD (1)
37
#03
401-35432 CPUBOARD (1)
38 SM-4040601-SC SCREWM4X0.7L=6 (2)
39 E1038-871-000 PLATENLOCKCAMSCREW (2)
40
#02
401-08565 CTRLBASEU (1)
41
#03
401-34635 CTRL_BASE_U (1)
42
#02
400-48003 IEEE1394BOARD (1)
43
#03
401-50021 IEEE1394BOARD (1)
44 HM-0003300-30 FANGUARD (2)
45 HX-0029400-00 FIXEDBASE (2)
46
#02
400-32319 BLANKPANELB (4)
47
#03
400-32319 BLANKPANELB (3)
48
#03
401-35433 8-PORTCOMBOARD (1)
49 SL-6030892-TN SCREWM3L=8 2
- -
9. BASEFRAMEELECTRICAPPARATUSCOMPONENTS(5)
3 8
3 7
4 1
4 4
3 9
4 0
4 5
4 4
4 3
4 2
3 1
3 7
2 7
2 8
3 4 2 5
2 9
2 9
2 6
3 3
2 9
1 5
2 4
2 2
2 3
3 0
1 6
3 6
3 6
3 6
3 5
3 6
3 3
3 2
1 7
1 9
2 1
2 0
1 8
1
2
9
1 4
1 3
1 2
1 2
1 1
1 1
1 0
6
3
8
8
7
4
5
1 3
- -
REF.NO NOTE PARTNO DESCRIPTION Qty
1 401-14751 ATXUNIT 1
2 401-14761 ATXPSUUNIT (1)
3 400-48006 ATXPSU (1)
4 401-14023 ATXBR (1)
5 400-48047 INCHSCREW (4)
6 SL-6040892-TN BOLT (2)
7 HX-0029400-00 FIXEDBASE (2)
8 SL-4030891-SC SCREWM3X8 (4)
9 401-10498 ATXBATTERYUNIT (1)
10 400-48007 BATTERYUNIT (1)
11 401-08561 ATXBATTERYBR (2)
12 400-48047 INCHSCREW (8)
13 E1038-871-000 PLATENLOCKCAMSCREW 2
14 E1038-871-000 PLATENLOCKCAMSCREW 2
15 SL-4030891-SC SCREWM3X8 4
16 SL-4030891-SC SCREWM3X8 4
17 401-14756 STPMOTORDRIVERUNIT 1
18 401-14120 CARRYDRVBR (1)
19 HM-0013200-00 MOTORDRIVER (3)
20 SL-4030691-SC SCREWM3L=6 (6)
21 SL-6030692-TN SCREWM3L=6 (3)
22 401-14806 BASECARRYPCBUNIT 1
23 401-14014 PCBPLATEIO (1)
24 400-71680 BASEIOPCBASM (1)
25 400-47557 ETHER-SLAVEPCBASM (1)
26 HX-0041800-0C SPACER (5)
27 HX-0029400-00 FIXEDBASE (3)
28 SL-4030691-SC SCREWM3L=6 (3)
29 SL-4030691-SC SCREWM3L=6 (19)
30 401-14807 XYRELAYPCBUNIT 1
31 SL-4030691-SC SCREWM3L=6 (3)
32 401-11659 PCBPLATESXY (1)
33 401-06795 S-XYRELAYPCBASM (1)
34 400-47557 ETHER-SLAVEPCBASM (1)
35 HX-0041800-0C SPACER (5)
36 SL-4030691-SC SCREWM3L=6 (19)
37 HX-0029400-00 FIXEDBASE (3)
38 401-14809 FEEDERPCBUNIT 1
39 400-63489 FEEDERPCBPANEL (1)
40 SL-4030891-SC SCREWM3X8 (2)
41 401-14024 FEEDERPCBBOX (1)
42 400-47560 FEEDERPCBASM (1)
43 400-47557 ETHER-SLAVEPCBASM (1)
44 SL-4030691-SC SCREWM3L=6 (16)
45 HX-0041800-0C SPACER (5)
