CP40LV Technical Reference_CS_Ver - 第116页
B oard Ass’y 116 Page SAMSUNG TECHWIN Part Photo J1201033 HEX SUPPORT [M315 (BOLT-NUT)] J4801013A MOTHER BOARD[COMMATE A370VB] J2101716 FAN BRACKET [0131-614118-P1] J4809020A SCM2 [LAHD WIDE M] J4309002A VME CPU BOARD BA…
Part List
B
oard 5 Ass’y
115 Page
SAMSUNG TECHWIN
NO. LEVEL PART NO. PART NAME Q'TY TYPE Old No. Stock Reference
1
2
1
1
J9801541
J3152006A
CONVEYOR PACK BOARD ASS'Y
STEP MOTOR DRIVER [PMM-BD-4502-1]
30-CONV3-10 BOARD(2)
PMM-BD-4502-1
B
oard Ass’y
116 Page
SAMSUNG TECHWIN
Part Photo
J1201033 HEX SUPPORT [M315 (BOLT-NUT)]
J4801013A MOTHER BOARD[COMMATE A370VB]
J2101716
FAN BRACKET [0131-614118-P1]
J4809020A SCM2 [LAHD WIDE M]
J4309002A VME CPU BOARD BATTERY[CR2032]
J4809043A
VME CPU BOARD[MVME 162PA-252SE]
B
oard Ass’y
117 Page
SAMSUNG TECHWIN
Part Photo
J4901008A_AS CPU[INTEL CELERON733Mhz]
J9060097A SSA-VIS-FIX-IF ASS'Y [SSA-VISION-FIX-IF]
J9060022B VME IO DPRAM VERSION 2 BOARD ASSY[C30-Z]
J9060149A
40 VIS BOARD REV 1.0 [J9060149A]
J9060093A CA IF BOARD ASS'Y
J9060157B VME AXIS(2) BOARD ASSY(SMD) [J9060157B]
