X -Y Frame Ass’y 36 Page SAMSUNG TECHWIN Part Photo J3108021A SERVO MOTOR [P30B06040DXS22E] J7054063E DOG SENSOR J6102011A CABLEVEYOR-X[HSP 0450-3BN-50R 14LINK] J9061425B MOUSE EXTEND CABLE ASSY [SKE0003] J6102012B CABLE…
X
-Y Frame Ass’y
35 Page
SAMSUNG TECHWIN
Part Photo
J1201035 HEX SUPPORT [M310 (BOLT-NUT)]
J1300463 C-RING [10mm (HOLE)]
J1300170 SOCKET HEAD SCREW
J1300468
SPRING WASHER [M3]
J1300416
HEX NUT [M6 (BLACK)]
J2101350
MECHALOCK FASTNER [0133-631006]
X
-Y Frame Ass’y
36 Page
SAMSUNG TECHWIN
Part Photo
J3108021A
SERVO MOTOR [P30B06040DXS22E]
J7054063E DOG SENSOR
J6102011A
CABLEVEYOR-X[HSP 0450-3BN-50R 14LINK]
J9061425B
MOUSE EXTEND CABLE ASSY [SKE0003]
J6102012B
CABLEVEYOR-Y[HSP 0450-3BN-95R 19LINK]
X
-Frame Ass’y
37 Page
SAMSUNG TECHWIN
