C onveyor Ass’y 93 Page SAMSUNG TECHWIN Part Photo J7053196C PCB GUIDE R.C J7153017A CYL. VRACKET J7153004D PCB GUIDE F.L, R.R J7159010C CLAMP SENSOR J7153010B ADJUST SHAFT J7500003B BACK UP PIN
C
onveyor Ass’y
92 Page
SAMSUNG TECHWIN
Part Photo
J1301672 BEARING [6804]
J3108032A AC SERVO MOTOR[P20B10100DXS00E]
J2101750
STOPPER WIDTH [0135-641024]
J6701018B STOPPER CYLINDER 1 [WTS1030-RS2]
J3104013A CV STEP MOTOR [4S56Q-03076S]
J7053120B STOPPER BRACKET-M
C
onveyor Ass’y
93 Page
SAMSUNG TECHWIN
Part Photo
J7053196C PCB GUIDE R.C
J7153017A CYL. VRACKET
J7153004D PCB GUIDE F.L, R.R
J7159010C CLAMP SENSOR
J7153010B ADJUST SHAFT
J7500003B BACK UP PIN
C
onveyor Ass’y
94 Page
SAMSUNG TECHWIN
Part Photo
J9053047A HOLE FIXER ASS'Y
J9061415C CONV STEP MOTOR CABLE ASS'Y[QA2-CD02-1]
