9 C&P Placement Heads
9.5 Settings 9.5.2 Overview of Settings on the C&P6/12
178 Student Guide SIPLACE D-Series (FSE)
Belt tension of the Z axis Belt tension measurement de-
vice
Belt tension 280 +/- 5 Hz
Z axis top stop Gauge for Z axis end stopper -
star gauge [03019865-xx]
Correct position is necessary to
determine the zero point correc-
tion.
Air blast tubes on the star Check with your eyes Check the distance between in-
cremental encoder and air blast
tubes.
Adjustment of air blast supply Feeler gauge Air blast tubes should be approx.
0.7 mm over the frame of the cir-
cular arc guide
Adjustment of air blast placement Compressed air testing device 150 mbar on open 9x4 nozzle
Air blast setting on reject circuit Compressed air testing device250 mbar
Belt tension setting for drive belt
replacement
DP belt adjustment aid Achieved with spring tension of
tool
Description Tools and equipment Values
9 C&P Placement Heads
9.5.2 Overview of Settings on the C&P6/12 9.6 Room for Your Sketches and Notes
Student Guide SIPLACE D-Series (FSE) 179
9.6
9.6 Room for Your Sketches and Notes
Room for Your Sketches and Notes
