11 Component Handling 11.4.5 Feeder Modules 11.4 Pneumatic Tape Cutter Student Guide SIPLACE D-Series (FSE) 209 11.4.5 1 1 . 4 . 5 F e e d e r M o d u le s Feeder Modules S Feeder Any position possible a t the D/Di-serie…
11 Component Handling
11.4 Pneumatic Tape Cutter 11.4.4 Empty Tape Duct
208 Student Guide SIPLACE D-Series (FSE)
The jumper for the CAN bus addressing must be set according to the corresponding location in the ma-
chine.
11.4.3.1
11.4.3.1 FSE Note
FSE Note
11.4.4
11.4.4 Empty Tape Duct
Empty Tape Duct
The empty tape duct acts as a base for further modules:
▪ The removable nozzle reject container (3)
▪ The installation surface (5) for the C&P nozzle changer
▪ The nozzle stripping unit (4)
Jumper setting on the tape cutter unit (example of D4/D4i
shown)
Legend
1. X12 – Jumper for location code of cutter:
1a: Gantry 1
1b: Gantry 2
1c: Gantry 3
1d: Gantry 4
2. X5 – Voltage supply to valve (left)
3. X8 – Proximity switch for stroke cylinder out (left)
4. X7 – Proximity switch for stroke cylinder in (left)
5. X4 – CAN bus connection
6. X2 – Voltage supply for cutter +24 V and +5 V
7. X9 – Proximity switch for stroke cylinder in (left)
8. X10 – Proximity switch for stroke cylinder out (right)
9. X6 – Voltage supply to valve (right)
NOTICE
This tape cutter works at 500kbit/s CAN bus with the G01xxxxx eSW and at the 1Mbit/s CAN
bus with the G02xxxxx eSW.
A new tape cutter control unit (with downwards compatibility) (currently only available for X ma-
chines) can also perform nozzle changer control. The eSW to be loaded is the G03xxxxx.
Empty-tape duct with component reject container (D4/D4i
shown as example)
Legend
1. Inlet slot for empty tape
2. Outlet slot for the empty tape above the pneumatic
tape cutter
3. Nozzle reject container
4. Nozzle reject station
5. assembly surface for the nozzle changer
The empty tape duct receives empty tapes from the feed-
ers at the inlet gap (1) and guides these from the outlet
gap (2) to the cutting position of the pneumatic cutter.
This is where the tape is cut up and falls down the waste
slide, into the component trolley waste tape container.
Für die WPC4-Option ist ein auf 5 Fördererpositionen re-
duzierter Leergurtleitkanal verfügbar.
The empty tape duct is fixed to the pneumatic tape cutter
with four screws.
11 Component Handling
11.4.5 Feeder Modules 11.4 Pneumatic Tape Cutter
Student Guide SIPLACE D-Series (FSE) 209
11.4.5
11.4.5 Feeder Modules
Feeder Modules
S Feeder Any position possible at the D/Di-series locations.
Linear feeder Any position possible at the D/Di-series locations.
Waffle pack trays Carrier 51 (8,5 Feederplätze) /30 (5 Feederplätze) on COT 1 der D1/D1i.
only with disambled nozzle changers the C&P-Kopf
11 Component Handling
11.5 Room for Your Sketches and Notes 11.4.5 Feeder Modules
210 Student Guide SIPLACE D-Series (FSE)
11.5
11.5 Room for Your Sketches and Notes
Room for Your Sketches and Notes
