13 Head Modularity 13.3 Head Modularity D4/D4i Student Guide SIPLACE D-Series (FSE) 235 Camera modularity D3 13.3 1 3 . 3 H e a d M o d u la r it y D 4 / D 4 i Head Modularity D4/D4i Head Modularity D4/D4i Camera modular…
13 Head Modularity
13.2 Head Modularity D3
234 Student Guide SIPLACE D-Series (FSE)
Reconfiguration kits and extension sets for D2/D2i
Camera modularity D2/D2i
13.2
13.2 Head Modularity D3
Head Modularity D3
Head Modularity D3
D1/D1i P&P SST 25 FLIPCHIP-Kamer-
aoption
1.0 x 0.5 to 16 x 16 mm single
measurement
SC/MC 603 (Di –
SC/MC
605.03SP2)
D1/D1i P&P SST 33 X camera option 0.5 x0.3 to 55 x45 mm single
measurement
SC/MC 604 (Di –
SC/MC
605.03SP2)
D1 P&P Koplanaritätsoption SST17
ILD2200
für QFP und SOxx Bauelemen-
te ab 0,3 mm Beinchenraster
SC/MC 603 (Di
not supporting)
Machine Placement head 1 gantry 1 Placement head 2 gantry 2 From SW version
D2/D2i regular With C&P6 head
00119861-xx
With C&P6 head
00119861-xx
SC/MC 603 (Di –
SC/MC
605.03SP2)
D2/D2i regular With C&P12 head
00119860-xx
With C&P12 head
00119860-xx
SC/MC 603 (Di –
SC/MC
605.03SP2)
D2/D2i regular With C&P6 or 12 head With C&P6 or 12 head SC/MC 603 (Di –
SC/MC
605.03SP2)
Machine Placement head camera Comments From SW version
D2/D2i C&P6 head SST 29 only (Di – SST30) 0.5 x 0.3 to 27 x 27 mm SC/MC 603 (Di –
SC/MC
605.03SP2)
D2/D2i C&P12
head
SST 28 standard 1 x 0.5 to 18.7 x 18.7 mm SC/MC 603 (Di –
SC/MC
605.03SP2)
D2/D2i C&P12
head
SST 29 high resolution (Di –
SST30)
0.5 x 0.3 to 18.7 x 18.7 mm SC/MC 603 (Di –
SC/MC
605.03SP2)
NOTICE
Cause of Hazard
For detailed information about the work to be performed and the calibration of the Head Mod-
ularity option, refer to the assembly instructions "Head Reconfiguration Kits D1/D1i/D2/D2i"
[00195427-xx].
Machine Placement head camera Comments From SW version
Machine Placement head 1
in PA1
Placement head 2
in PA1
Placement head in
PA2
From SW version
D3 C&P6/12-Kopf C&P6/12-Kopf C&P6/12-Kopf SC/MC 602
D3 C&P6/12-Kopf C&P6/12-Kopf Twin Head SC/MC 602
D3 C&P6/12-Kopf Twin Head Twin Head SC/MC 603
D3 Twin Head C&P6/12-Kopf Twin Head SC/MC 603
D3 Twin Head Twin Head Twin Head SC/MC 603
13 Head Modularity
13.3 Head Modularity D4/D4i
Student Guide SIPLACE D-Series (FSE) 235
Camera modularity D3
13.3
13.3 Head Modularity D4/D4i
Head Modularity D4/D4i
Head Modularity D4/D4i
Camera modularity D4/D4i
13.4
13.4 Servo Positions D4/D4i/D2/D2i
Servo Positions D4/D4i/D2/D2i
Servo assignment D4/D4i/D2/D2i
Machine Placement head camera Comments From SW version
D3 C&P6 head SST 29 only 0.5 x 0.3 to 27 x 27 mm SC/MC 602
D3 C&P12 head SST 28 standard 1 x 0.5 to 18.7 x 18.7 mm SC/MC 602
D3 C&P12 head SST 29 high resolution 0.5 x 0.3 to 18.7 x 18.7 mm SC/MC 602
D3 TWIN head SST 25 FLIPCHIP 1.0 x 0.5 to 16 x 16 mm single
measurement
SC/MC 602
D3 TWIN head SST 33 0.5 x0.3 to 55 x45 mm single
measurement
SC/MC 602
D3 TWIN an
Portal 3
Koplanaritätsoption SST17
ILD2200
für QFP- und SOxx-Bauele-
mente ab 0,3 mm Beinchen-
raster
SC/MC 603
Machine Placement head 1 in PA1 or PA2 From SW version
D4/D4i C&P12 head SC/MC 602 (Di –
SC/MC 605.03SP2)
Machine Placement head camera Comments From SW version
D4/D4i C&P12
head
SST 28 standard 1 x 0.5 to 18.7 x 18.7 mm SC/MC 602 (Di –
SC/MC
605.03SP2)
D4/D4i C&P12
head
SST 29 high resolution (Di - -
SST30)
0.5 x 0.3 to 18.7 x 18.7 mm SC/MC 602 (Di –
SC/MC
605.03SP2)
D4/D4i C&P12
head
SST 38 extremely high reso-
lution (Di – SST30)
0.1 x 0.05 to 16 x 16 mm SC/MC 604 (Di –
SC/MC
605.03SP2)
Servo positions for
each level
D4/D4i D2/D2i
C&P type
PA1
C&P type
PA2
C&P type P&P type (next
generation)
x Gantry 1 Gantry 2 Gantry 1 Gantry 1
A9 Star 1 Star 2 Star 1 Z-axis 1
A11 Z-axis 1 Z-axis 2 Z-axis 1 --
Y Gantry 1 Gantry 2 Gantry 1 Gantry 1
A13 -- -- -- D axis 1
A15 -- -- -- --
x Gantry 4 Gantry 3 Gantry 2 Gantry 2
A10 Star 4 Star 3 Star 2 Z-axis 2
A12 Z-axis 4 Z-axis 3 Z-axis 2 --
13 Head Modularity
13.5 D/Di-Series Servo Positions
236 Student Guide SIPLACE D-Series (FSE)
13.5
13.5 D/Di-Series Servo Positions
D/Di-Series Servo Positions
Servo positions for D1/D1i machine
Servo positions for D2/D2i machine
Y Gantry 4 Gantry 3 Gantry 2 Gantry 2
A14 DP axis G1 DP axis G2 DP axis G1 D axis 2
A16 DP axis G4 DP axis G3 DP axis G2 --
Servo positions for
each level
D4/D4i D2/D2i
C&P type
PA1
C&P type
PA2
C&P type P&P type (next
generation)
Head servo
positions
C&P & P&P combination
at one D1/D1i gantry
/for D1/D1i single head
with C&P module
/for D1/D1i single head
with P&P module
A9 A11 SDS 60/1Z1
P&P mod-
ule.
SDS 60/
3Z1 C&P
module
--- SDS 60/
3Z1
SDS 60/1Z1
00353446-
04
---
A13 A15 SDS 60/
0.5D1 P&P
module
TBS 120/
3S1 C&P
module
--- TBS 120/
3S1
SDS 60/
0.5D1
00353447-
03
---
A10 A12 --- --- --- --- --- ---
A14 A16 SDS 60/1D1
C&P module
--- SDS 60/1D1 --- --- ---
Uneven axis
servo num-
bers for first
gantry(ies) of
PA
For C&P12 For C&P6 For TWIN (next genera-
tion)
Segment 2 Segment 1
A9 A11 TBS 120/
3S1
00353445-
04
SDS 60/
3Z1
03002141-
02
TBS 120/
3S1
00353445-
04
SDS 60/
3Z1
03002141-
02
SDS 60/1Z1
00353446-
04
SDS 60/
1Z1
00353446-
04
A13 A15 --- --- --- --- SDS 60/
0.5D1
00353447-
03
SDS 60/
0.5D1
00353447-
03
No DP servo in upper
area
No DP servo in upper
area
Even axis
servo num-
bers for sec-
ond
gantry(ies+)
of PA
For C&P12 For C&P6 For TWIN
Segment 2 Segment 1
