3 Overview 3.4.1 General Overview of Assemblies 3.4 Assemblies Student Guide SIPLACE D-Series (FSE) 29 3.4.1 3 . 4 . 1 G e n e r a l O v e r v ie w o f A s s e m b lie s General Overview of Assemblies Overview of the mod…

3 Overview

3.4 Assemblies 3.3.2 Conveyor Options

28 Student Guide SIPLACE D-Series (FSE)

3.3.2

3.3.2 Conveyor Options

Conveyor Options

Conveyor equipment: Dual conveyor

Conveyor equipment: dual conveyor in single conveyor mode

Conveyor equipment: single conveyor

3.4

3.4 Assemblies

Assemblies

See also

 5 Energy and Compressed Air Supply [ ➙ 77]

Conveyor/

Option

D4/D4i D3 D2/D2i D1/D1i

With dual conveyor

Standard

(Length x width)

50x50mm-

368x216mm

50x50mm-

450x216mm

50x50mm-

460x216mm

50x50mm-

460x216mm

Wide board

(Length x width)

50x50mm-

368x242mm

50x50mm-

450x250mm

50x50mm-

460x242mm

50x50mm-

460x242mm

Long board option 50x50mm-

610x216mm

50x50mm-

610x216mm

50x50mm-

610x216mm

50x50mm-

610x216mm

Long board option

and wide board

50x50mm-

610x216mm

50x50mm-

610x216mm

50x50mm-

610x216mm

50x50mm-

610x216mm

Conveyor/

Option

D4/D4i D3 D2/D2i D1/D1i

With dual conveyor in single conveyor mode

Standard

(Length x width)

50x50mm-

368x380mm

50x50mm-

450x380mm

50x50mm-

460x380mm

50x50mm-

460x380mm

Wide board

(Length x width)

50x50mm-

368x430mm

50x50mm-

450x450mm

50x50mm-

460x430mm

50x50mm-

460x430mm

Long board option 50x50mm-

610x216mm

50x50mm-

610x216mm

50x50mm-

610x216mm

50x50mm-

610x216mm

Long board option

and wide board

50x50mm-

610x216mm

50x50mm-

610x216mm

50x50mm-

610x216mm

50x50mm-

610x216mm

Conveyor/

Option

D4/D4i D3 D2/D2i D1/D1i

With single conveyor

Standard

(Length x width)

50x50mm-

368x460mm

50x50mm-

450x460mm

50x50mm-

460x460mm

50x50mm-

460x460mm

Wide board

(Length x width)

50x50mm-

368x508mm

50x50mm-

450x508mm

50x50mm-

460x508mm

50x50mm-

460x508mm

Long board option 50x50mm-

610x460mm

50x50mm-

610x460mm

50x50mm-

610x460mm

50x50mm-

610x460mm

Long board option

and wide board

50x50mm-

610x508mm

50x50mm-

610x508mm

50x50mm-

610x508mm

50x50mm-

610x508mm

3 Overview

3.4.1 General Overview of Assemblies 3.4 Assemblies

Student Guide SIPLACE D-Series (FSE) 29

3.4.1

3.4.1 General Overview of Assemblies

General Overview of Assemblies

Overview of the modules

Legend

1 Machine frame 7 Extension kit on the PCB output side

2 PCB conveyor (flexible dual conveyor) 8 Gantry 3

3 Extension kit on the PCB input side 9 Monitor (2x)

4 Tape cutter , empty tape duct (4x) 10 Keyboard (2x)

5 Gantry 1 11 Gantry 4

6 Gantry 2

3 Overview

3.4 Assemblies 3.4.2 Sectors

30 Student Guide SIPLACE D-Series (FSE)

3.4.2

3.4.2 Sectors

Sectors

Sector 1:

▪ Transport control TSP 301

▪ CAN interface CAN Bus baudrate 500 KBit/s for S tables

▪ Assembly A3 CAN terminating resistor for S table location 1

▪ Vision DC/DC converter illumination digital camera gantry 1 - 4 (03002280-02)

▪ Terminal X100 power supply

▪ Pneumatic switch for changeover table 1

Sector 2:

▪ CAN I/O module 2 with CAN interface 500 KBit/s for S tables

▪ Assembly A3 CAN terminating resistor for S table location 2

▪ 3x fuse 24 V

▪ Relay K1 station – compressed air shutoff

▪ Terminal X200 power supply

▪ Pneumatic switch for changeover table 2

Sector 3:

▪ CAN interface CAN Bus baudrate 500 KBit/s for S tables

▪ Assembly A3 CAN terminating resistor for S table location 3

▪ Terminal X300 power supply

▪ Pneumatic switch for changeover table 1

Sector 4:

▪ CAN I/O module 2 with CAN interface 500 KBit/s for S tables

▪ Assembly A3 CAN terminating resistor for S table location 4

▪ 3x fuse 24 V

▪ Terminal X400 power supply

▪ Pneumatic switch for changeover table 1

SIPLACE D4 sectors

Legend

1. Sector 1

2. Sector 2

3. Sector 3

4. Sector 4

5. Transport direction
